Schlage PM175 Grade 1 Half Dummy Trim with Lock Case Mortise Lock, Non-Keyed

Schlage PM175 Grade 1 Half Dummy Trim with Lock Case Mortise Lock, Non-Keyed

(No reviews yet) Write a Review

Model: PM175 ATHA 626
$297.00
$186.03
Selected Finish is
Selected Lever Style is
Selected Rose/Escutcheon Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$297.00
$186.03
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schlage PM175 Grade 1 Half Dummy Trim with Lock Case Mortise Lock, Non-Keyed

Overview

Grade 1, Mortise Locks Purpose-built to serve the commercial real estate, retail, multifamily and hospitality industries, Schlage Performance Series™ locks feature exceptional quality and style at a highly competitive price point. The PM Series offers 26 functions, including three electrified, and four mortise deadbolt functions, all made to meet Schlage’s rigorous quality standards. With popular levers and finish options, Schlage's full key system security line up, and its durable design, you can meet needs for both security and style. They are made to suite with other Allegion products to present a quality, complete door hardware solution and provide a consistent user experience throughout your building or complex. Better yet, you can suite the PM Series mortise locks with the PT Series tubular locks, as they share lever and rose styles.



PM010 - Passage Latch

  • Levers only-both sides; latchbolt only
  • Latchbolt retracted by lever from either side at all times
  • Inside lever always free for immediate egress



Chassis

  • Case: Cold Rolled Steel (CRS) with corrosion resistant zinc dichromate plating
  • Case size: 4-7/16" x 6-1/16" x 1" (113 mm x 154 mm x 25 mm) Note: PM and L Series case and cover holes differ.
  • Spacing: lever to cylinder 3-7/8" (98 mm);  lever to thumbturn hub 2-11/16" (68 mm)
  • Door thickness: 1-3/4" (44 mm) standard; 1-3/8" (35 mm) minimum; fits doors up to 2-1/2" thick - specify door thickness if  over 1-3/4" and position in door (Available EE only)
  • Field reversible handing



Trim Options

  • 10 lever designs made of zinc
  • N escutcheons: 7-7⁄8” x 2-1⁄2” x 7⁄16” (200 mm x 64 mm x 11 mm); wrought brass
  • Roses: A 2-1/8" (54 mm), B 2-9/16" (65 mm), C 2-5/8" (67 mm) - brass
  • Thumbturn style is ADA qualified



Latches, Armors, Strikes

  • Backset: 2-3/4" (70 mm) only
  • Armor: Standard - 1-1⁄4" x 8" x 7⁄32" (32 mm x 203 mm x 6 mm); Optional - 1-1⁄16" x 8" x 7⁄32"  (27 mm x 203 mm x 6 mm)
  • Deadbolt: 1" (25 mm) throw stainless steel
  • Latch: 3⁄4" (19 mm) throw stainless steel with anti-friction tongue
  • Strike: ANSI curved lip strike 1-1⁄4" x 4-7⁄8" (32 mm x 124 mm) standard; dust box included
  • Strike lip length: 1-3⁄16" (30 mm); optional strike lip lengths - 7⁄8", 1", 1-1⁄2", 1-3⁄4", and 2"



DOWNLOADS & RESOURCES

Product Information



Related Product Information



Technical resources



Manufacturer Resources

Product Specs

Subcategory:
Mortise Locks
Product Group:
Mechanical Locks
Series:
PM Series
Grade:
Grade 1
Keyed Function:
Non-Keyed
Handle Type:
Lever
Standard Strike:
10-072 1-1/4" x 4-7/8" Square Corner Strike, Box (1-3/16" Lip Length)
Warranty:
5 Year Limited
Keyed:
No
ANSI/BHMA:
F01
Product Subgroup:
Mortise Locks and Trim
Product Type:
Mortise Locks
Commercial/Residential:
Commercial
Lock Type:
Mortise
Lock Function:
Dummy
IMAP Policy:
Yes
Product Attribute:
Mortise Locks
Electronic:
No
Product Model:
PM010
Product Function:
Half Dummy Trim with Lock Case
Door Hand Direction:
Field Reversible
Door Thickness Range:
1-3/4"
Product Category:
Mechanical Locks
Backset (Distance):
2-3/4"
Department:
Door Hardware

Schlage PM175 ATHA 626 – Frequently Asked Questions

1) What exactly does a Schlage PM175 half dummy give you, and does it actually latch?
Nothing latches. The PM175 is dummy trim with a lock case behind it, so you get a fixed lever on one face of the door and a mortise case that fills the pocket. It is non-keyed and has no working latchbolt operation. Use it on the inactive leaf of a pair, or on a door held closed by a roller catch or magnet, where you want the lever to look and feel like the operating hardware on the rest of the openings.
2) Will the Schlage PM175 dummy fit a 1-3/4 inch door, and what about thicker doors?
1-3/4 inches (44 mm) is the standard door thickness for the PM Series, with 1-3/8 inches (35 mm) the minimum. The case will go into doors up to 2-1/2 inches thick, but over 1-3/4 inches you have to specify the door thickness and the position of the lock in the door when you order.
3) How big a mortise pocket does the PM Series lock case need?
The case measures 4-7/16 x 6-1/16 x 1 inch (113 x 154 x 25 mm). One thing to watch on a retrofit: Schlage notes the PM Series case and cover hole pattern differs from the L Series, so an existing L Series pocket is not a straight drop-in for the mounting holes even though the pocket size is close.
4) Can I match this dummy lever to the working locks on the rest of my building?
That is the point of it. The PM Series runs 10 lever designs (Athens, Broadway, Latitude, Longitude, Neptune, Playa, Rhodes, Selena, Tubular and Two) in six finishes: 613 Oil Rubbed Bronze, 619 Satin Nickel, 622 Matte Black, 625 Bright Chrome, 626 Satin Chrome and 643E Aged Bronze. Schlage also builds the PM mortise line to suite with the PT Series tubular locks, which share the same lever and rose styles, so a dummy on a mortise-prepped leaf can match a tubular lock down the hall.
5) I need a working passage lever, not a dummy. What is the right PM Series function?
For a door that actually needs to latch, go to the PM010 passage latch: levers both sides, latchbolt only, retracted from either side at all times, with the inside lever always free for egress. The PM175 dummy has no latch at all. If you want a passage function from another brand, the Falcon MA101 is a Grade 1 heavy duty mortise passage lock that is also field reversible, and the Hager 3810S and 3810E are Grade 1 passage mortise locks on a 2-3/4 inch backset with rose and escutcheon trim respectively.
6) What is a good alternative to the Schlage PM175 dummy mortise trim on the active leaf that actually needs to latch?
The PM175 is a half dummy - its lock function is dummy and it is non-keyed, so the lever is fixed and there is no latching. For the leaf that has to latch without keying, the Falcon MA101 is a Grade 1 heavy-duty mortise passage lock with field reversible operation, and the Hager 3810S is a Grade 1 passage mortise lock with rose trim and a 2-3/4 inch backset, the same backset the PM175 uses. A common pairing on a double door is a working passage lock on the active leaf and the dummy trim on the inactive leaf so both levers look identical.
7) Is the Falcon MESC600DT dummy trim a substitute for the Schlage PM175?
No - they solve different openings. The Falcon MESC600DT is a dummy escutcheon lever trim made for M9900 Series exit devices, so it mounts to a door already carrying an exit device. The Schlage PM175 is a half dummy mortise trim supplied with a mortise lock case and a 2-3/4 inch backset, for a door prepped with a standard mortise pocket. Choose by what the door is prepped for, not by the word dummy.
8) If the door needs privacy or a locking function instead of a fixed dummy lever, what mortise locks cover that?
The Schlage PM175 is non-keyed with a dummy function, so it neither latches nor locks. For privacy on a restroom or bedroom door, the Hager 3840S is a Grade 1 privacy mortise lock with a 2-3/4 inch backset for 1-3/4 to 2 inch doors, and the Cal-Royal NM8440 is a Grade 1 privacy mortise lockset with deadbolt for 1-3/4 inch doors. For a keyed storeroom opening, the Cal-Royal NM8080 is Grade 1 with an interchangeable core option and the Accentra 8805FL is a Grade 1 storeroom mortise lock from the 8800 Series.
9) Will the Schlage PM175 fit a door prepped for a 2-1/2 inch backset mortise lock like the Baldwin 6301?
No. The PM175 is 2-3/4 inch backset only. The Baldwin 6301 entry/apartment and 6310 entry/storeroom mortise lock bodies use a 2-1/2 inch backset, so a pocket cut for those sits the case closer to the door edge than the PM175 needs. On a 2-1/2 inch backset prep, stay with the Baldwin bodies; on a 2-3/4 inch ANSI prep, the PM175 and the 2-3/4 inch backset Hager 3800 Series locks line up.
10) Why would I put a mortise dummy in a door instead of a cheaper surface-mounted dummy lever?
Because of the door prep. A mortise dummy drops into the same mortise pocket, 2-3/4 inch backset prep and trim footprint as the working PM Series mortise locks around it, so an inactive leaf or a closet door keeps the identical lever projection, rose size and feel as the live openings. A surface dummy screws to the face and reads differently. If the door is already prepped for a mortise lock, or you are matching a run of PM Series openings, the PM175 is what keeps the elevation consistent.
11) Do I have to order a hand for the PM175, or can the installer sort it out on site?
Handing is field reversible on the PM Series, so the installer can set it on the door rather than committing on the purchase order. That matters most when a property manager is buying a batch across mixed openings and does not want to track left and right hand counts.
12) What are my options if I want a decorative mortise dummy for a residential-looking entry instead of a commercial lever?
The PM175 is built for commercial openings, so the trim reads as commercial lever hardware. If you are after an ornamental residential mortise dummy, Emtek offers dummy mortise entrance locksets in several designs, including the 3019 Brisbane, 3102 Memphis, 3104 Hamilton and 3106 Manhattan.
13) Can the PM175 be electrified or take a card reader later?
No. The PM175 is a mechanical, non-electronic dummy with no keying and no electrical option. The PM Series as a whole includes three electrified functions, but not this one. If you need access control on that opening, look at a purpose-built electronic mortise lock such as the Schlage CO-100 standalone mortise lock with keypad reader, or the Schlage Electronics LEMD ENGAGE Series Grade 1 wireless mortise lock with a 125kHz proximity reader.
14) How does the Schlage PM175 half dummy compare with Emtek mortise dummy locksets?
Both are dummy function. The Emtek 3019 Brisbane, 3102 Memphis, 3104 Hamilton and 3106 Manhattan are mortise entrance locksets in dummy configuration, each tied to a specific decorative design family. The Schlage PM175 is a Grade 1 commercial half dummy trim supplied with a lock case, offered in ten lever designs including Athens, Rhodes, Latitude and Neptune, with A, C and D roses or the N escutcheon. If the rest of the building is on Schlage Performance Series trim, the PM175 keeps the lever and rose profile consistent; if the door is part of a decorative residential-style suite, the Emtek dummies match those designs instead.
15) For a behavioral health or anti-ligature opening, is the Schlage PM175 the right mortise trim?
The PM175 is a Grade 1 commercial half dummy with a standard lever trim and is not built as a ligature resistant device. For those openings the TownSteel MRX-L-01 is a Grade 1 heavy duty anti-ligature lever mortise lockset in passage function and the MRX-A-01 is a Grade 1 heavy duty passage mortise lockset with ligature resistant arch trim in satin stainless steel, both for 1-3/4 inch doors. The Marks USA 5PDN is a Grade 1 ligature resistant hospital passage push/pull paddleset for doors that need no lever at all.
16) We want keypad or credential access on the door - what replaces the PM175 there?
The PM175 is a mechanical, non-electronic dummy trim, so it carries no credential capability. For electronic mortise openings, the Schlage CO-100-MS is a Grade 1 heavy duty standalone keypad mortise lock for 1-3/4 inch doors, the Schlage Electronics LEMD-GRW is a Grade 1 ENGAGE Series wireless mortise lock with a 125 kHz proximity reader and a 3 hour fire rating, and the TownSteel FME-2000 is a Grade 1 heavy duty classroom mortise lockset with RFID for 1-3/4 inch doors. If only the inactive leaf needs matching trim, the PM175 still covers that leaf alongside any of these.
17) Is a dummy mortise lock still a Grade 1 product, and does it come with a strike?
The PM175 carries a Grade 1 rating and an ANSI/BHMA F01 function designation. Because it is dummy trim there is no latch to keep, so a strike is not part of the operating hardware here. The standard strike associated with the PM Series working functions is the 10-072 square corner strike, 1-1/4 x 4-7/8 inches with a 1-3/16 inch lip and a dust box.
18) Is the lever on the PM175 solid brass?
The levers are zinc. The trim plates behind them are brass: the N escutcheon is wrought brass and the A, B and C roses are brass. The lock case itself is cold rolled steel with a corrosion resistant zinc dichromate plating.
