Schneider 9080LBA Series Panel Terminal Block Assemblies, Selectable Number of Poles

Schneider Electric 9080LBA Series Power Distribution Block Assembly with Selectable Poles

(No reviews yet) Write a Review

Model: 9080LBA165112

In Stock (leaves warehouse same day if ordered before 3pm ET)

$254.33
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric 9080LBA Series Power Distribution Block Assembly with Selectable Poles

Professional Power Distribution Solution for Electrical Panel Applications

The Schneider Electric 9080LBA Series Power Distribution Block Assembly delivers reliable electrical distribution with selectable pole configuration for versatile panel applications. This surface mount power distribution block provides professional-grade performance with 65 kA short circuit current rating and operates across a wide ambient temperature range from -40 to 302°F, ensuring dependable service in demanding electrical environments.

Professional Features & Benefits

  • 65 kA Short Circuit Current Rating: Provides robust protection and reliable performance under high fault current conditions for enhanced system safety.
  • Wide Operating Temperature Range (-40 to 302°F): Ensures consistent operation across extreme environmental conditions for versatile installation flexibility.
  • Surface Mount Design: Simplifies installation and maintenance with accessible mounting configuration for efficient panel integration.
  • Selectable Pole Configuration: Offers flexible connection options to accommodate various electrical distribution requirements and system designs.
  • 9080LB Series Platform: Part of proven Schneider Electric distribution block family with established reliability and compatibility standards.
  • RoHS Compliant Construction: Meets environmental compliance standards with mercury-free and toxic heavy metal-free design for safe installation.
  • Standard Function Option: Provides reliable baseline performance characteristics suitable for general power distribution applications.

Technical Specifications

  • Ambient Air Temperature For Operation: -40-302 °F
  • China Rohs In Scope: No
  • China Rohs Label: 1
  • Country Of Origin: United States
  • Eoli Availability Display: No need of specific recycling operations
  • Eu Rohs Directive: Compliant
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Legacy Weee Scope: In
  • Manufacturer: Schneider Electric
  • Mercury Free: Yes
  • Mounting Support: surface mount
  • Packaging Made With Recycled Cardboard: Yes
  • Packaging Without Single Use Plastic: No
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Or Component Type: Power Distribution Block
  • Range Of Product: 9080LB
  • Reach Compliance Directive: Free of Substances of Very High Concern above the threshold
  • Reach Free Of Svhc: Yes
  • Reach Free Shvc: Yes
  • Reach Full Compliance Status: Free of Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: NOT_CONTAINING_SVHC
  • Reach Regulation: Free of Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 1909
  • Rohs Eur Full Compliance Status: Compliant
  • Rohs Eur Full Compliance Status Id: COMPLIANT
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant
  • Rohs Exemption Information: Yes
  • Short Circuit Current: 65 kA
  • Sustainable Packaging: No
  • Take Back: No
  • Tier: 2
  • Tier Id: 2
  • Toxic Heavy Metal Free: Yes
  • With Recycled Cardboard: Yes
  • Without Single Use Plastic: No
  • Department: Electrical

Professional Applications

  • Electrical Panel Power Distribution
  • Commercial Building Electrical Systems
  • Industrial Control Panel Applications
  • Multi-Circuit Distribution Requirements
  • Professional Electrical Installations
  • Maintenance and Retrofit Projects

Why Choose Schneider Electric Quality?

Schneider Electric power distribution blocks deliver proven reliability with comprehensive environmental compliance including RoHS directive compliance and mercury-free construction. The 9080LB series represents established engineering excellence with surface mount design for professional installation efficiency and wide temperature operation range for demanding applications.

Manufacturer Resources

Product Specs

Ambient Air Temperature For Operation:
-40-302 °F
China Rohs In Scope:
No
China Rohs Label:
1
Country Of Origin:
United States
Eoli Availability Display:
No need of specific recycling operations
Eu Rohs Directive:
Compliant
Function Option:
Standard
Legacy Weee Scope:
In
Mercury Free:
Yes
Mounting Support:
surface mount
Packaging Made With Recycled Cardboard:
Yes
Packaging Without Single Use Plastic:
No
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Or Component Type:
Power Distribution Block
Range Of Product:
9080LB
Reach Free Of Svhc:
Yes
Reach Full Compliance Status:
Free of Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
1909
Rohs Exemption Information:
Yes
Short Circuit Current:
65 kA
Sustainable Packaging:
No
Take Back:
No
Tier:
2
Toxic Heavy Metal Free:
Yes
With Recycled Cardboard:
Yes
Without Single Use Plastic:
No
Department:
Electrical
Product Type:
Power Distribution Block
Product Group:
Electrical Mounting Hardware & Accessories

Schneider 9080LBA165112 – Frequently Asked Questions

1) Will a Schneider 9080LBA distribution block take 500 kcmil feeder wire?
Yes, on the larger builds. The 9080LBA range runs from small blocks with a single #14-2/0 main (9080LBA162101) up to mains rated (1) #4-500 kcmil or (2) #6-500 kcmil. If you are landing a 500 kcmil feeder into a 3-pole block, look at 9080LBA365106 (one #4-500 kcmil main per pole, six #14-2/0 branches) or 9080LBA365208 (two #6-500 kcmil mains, eight #14-2/0 branches). Match the main lug range to your incoming conductor first, then check that the branch count covers your outgoing circuits.
2) Do I need a 1-pole or 3-pole Schneider 9080LBA block for a three phase panel?
Three phase feeders need the 3-pole version, which gives you three electrically isolated pole assemblies in one block. The 9080LBA range covers both: 1-pole units like 9080LBA165112 and 9080LBA165202, and 3-pole units like 9080LBA363106 and 9080LBA365202. Some contractors do gang three 1-pole blocks instead when panel layout is awkward, but the 3-pole assembly keeps the phase spacing as built and is one mounting operation rather than three.
3) What short circuit current rating does the Schneider 9080LBA power distribution block carry?
65 kA short circuit current rating. That is the figure to check against the available fault current at the point in your system where the block lands, and it is what lets these go into commercial and industrial panels fed from larger services rather than just light control work.
4) How many branch circuits can I land on one Schneider 9080LBA block?
Branch capacity varies a lot across the 9080LBA builds, so pick by circuit count. At the low end, 9080LBA162101 gives a single #14-2/0 branch per pole. The high-density ones give twelve: 9080LBA165112 takes twelve #14-2 branches off a #4-500 kcmil main, and 9080LBA165212 takes twelve #14-4 branches off two #6-500 kcmil mains. In between there are four-branch (9080LBA362104), six-branch (9080LBA363206) and eight-branch (9080LBA365208) configurations. Count your outgoing circuits and their wire sizes before choosing.
5) I need to replace one 9080LB block in an existing panel. How do I identify the right one?
Work from the catalog number stamped on the block, which starts 9080LBA. The digit after LBA gives poles (1 or 3), and the trailing digits identify the lug arrangement, for example 9080LBA362104 is a 3-pole with one #14-2/0 main and four #14-4 branches per pole. If the label is unreadable, count the poles, count the branch lugs, and note the largest conductor landed on the main, then match those three against the configurations. All 9080LBA assemblies share the 65 kA short circuit rating and the surface mount footprint style.
6) Is there a 9080LBA block that takes two incoming feeders into the same pole?
Yes. Several configurations have dual main lugs per pole for paralleled or dual-source feeds: 9080LBA165202 and 9080LBA365202 take two #4-350 kcmil mains, 9080LBA3652021 and 9080LBA365208 take two #6-500 kcmil mains, and 9080LBA363206 takes two #14-2/0 mains. The single-main versions such as 9080LBA363101 will only accept one conductor per pole, so double-lugging them is not an option.
7) Can a 9080LBA block be used in an unheated outdoor enclosure or a hot equipment room?
Operating ambient range is -40 to 302 degrees F, which covers unheated northern exteriors and hot mechanical or process spaces alike. The block itself is not the weather barrier though, so the enclosure it sits in still has to suit the location.
8) How does the Schneider 9080LBA mount inside a panel?
Surface mount. The assembly fastens flat to the panel backplate or subpanel rather than clipping onto DIN rail, so plan for through-holes or tapped standoffs in the back pan and leave bending room for the main conductors ahead of the lugs.
9) Is the Schneider 9080LBA RoHS and REACH compliant for a spec that requires it?
It meets the EU RoHS directive, is free of Substances of Very High Concern above the REACH threshold, and is built mercury free and free of toxic heavy metals. Country of origin is the United States, which matters on public work with domestic sourcing language in the contract.
10) What is the difference between 9080LBA165202 and 9080LBA165212?
Both are 1-pole blocks with two main lugs, but they split power very differently. The 165202 has two #4-350 kcmil mains and two #4-350 kcmil branches, so it is a large-conductor tap or splice point. The 165212 has two #6-500 kcmil mains feeding twelve #14-4 branches, which is the one you want when a single big feeder has to break out to a dozen smaller circuits.
