Schneider Electric QO Series 1...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$631.00
Schneider Mini Circuit Breaker, QO, 1 Pole, 120VAC, 22kA, Bolt On

Schneider Electric QO Series 1-Pole 20A 120VAC GFCI Miniature Circuit Breaker with Bolt-On Mounting

(No reviews yet) Write a Review

Model: QOB120VHGFI

In Stock (leaves warehouse same day if ordered before 3pm ET)

$631.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schneider Electric QO Series 1-Pole 20A 120VAC GFCI Miniature Circuit Breaker with Bolt-On Mounting

Professional Ground Fault Circuit Interrupter Protection

The Schneider Electric QO Series miniature circuit breaker delivers reliable 20A electrical protection with integrated GFCI functionality for 120VAC single-pole applications. This bolt-on mounting circuit breaker features pressure plate electrical connections and compact 0.75" width design, providing professional-grade earth leakage protection in a single space configuration. Built for commercial market applications with halogen-free construction and 22kA interrupting capacity.

Professional Features & Benefits

  • 20A Line Rated Current: Provides precise overcurrent protection for residential and commercial branch circuits with reliable trip characteristics.
  • GFCI Protection: Integrated ground fault circuit interrupter functionality protects against electrical shock hazards and meets safety code requirements.
  • Bolt-On Mounting: Secure mechanical connection ensures reliable panel installation and prevents accidental disconnection during service.
  • Pressure Plate Connections: Professional electrical termination system provides consistent contact pressure and reduces installation time.
  • Compact 0.75" Width: Single-space design maximizes panel capacity while maintaining full protection capabilities.
  • Halogen-Free Construction: Environmentally responsible materials reduce toxic emissions and support green building initiatives.
  • 15-Year Average Life Duration: Extended service life reduces maintenance costs and provides long-term reliability for critical applications.

Technical Specifications

  • Ambient Air Temperature For Operation: 40 °C
  • Average Life Duration: 15 year(s)
  • Carbon Footprint: 18.70024213
  • Carbon Footprint Kg Co2 Eq Total Life Cycle: 18.70024213
  • China Rohs In Scope: No
  • China Rohs Label: 1
  • Circuit Breaker Application: not rated
  • Country Of Origin: Mexico
  • Device Type: LV equipment - Low voltage circuit breaker
  • Distribution Carbon Footprint: 0.029262
  • Electrical Connection: pressure plate
  • End Of Life Carbon Footprint: 0.04146
  • Energy Efficiency Optimized: FALSE
  • Environmental Disclosure: ENVPEP2111016
  • Eoli Availability Display: No need of specific recycling operations
  • Eu Rohs Directive: Compliant
  • Field Service Division: PPIBS
  • Function Option: Standard
  • Function Option Id: STANDARD
  • Green Premium Status For Reporting: Green Premium product
  • H And D Domain: Safety
  • H And D Enrichment Assignment: yes
  • H And D Enrichment Class 3: Earth leakage protection devices
  • H And D Enrichment Class 4: GFCI
  • H And D Enrichment Function: GFCI
  • H And D Subrange: COM
  • Halogen Content Performance: Halogen free product
  • Halogen Free Status: Halogen free product
  • Halogene Performance: Halogen free product
  • Installation Carbon Footprint: 0.000056652
  • Legacy Weee Scope: In
  • Line Rated Current: 20 A
  • Manufacturing Carbon Footprint: 1.32522
  • Market Segmentation: Commercial
  • Market Segmentation Id: COMMERCIAL
  • Mercury Free: Yes
  • Mounting Mode: bolt-on
  • Number Of Spaces Required: 1
  • Package Weight Lbs: 226.796 g
  • Packaging Made With Recycled Cardboard: No
  • Packaging Without Single Use Plastic: Yes
  • Poles Description: 1P
  • Product Availability: Stock - Normally stocked in distribution facility
  • Product Contributes To Saved And Avoided Emissions: No
  • Product Depth: 2.91 in
  • Product Height: 4.13 in
  • Product Or Component Type: miniature circuit-breaker
  • Product Width: 0.75 in
  • Range Of Product: QO
  • Reach Compliance Directive: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status: Reference contains Substances of Very High Concern above the threshold
  • Reach Full Compliance Status Id: CONTAINS_SVHC
  • Reach Regulation: Reference contains Substances of Very High Concern above the threshold
  • Recycled Metal Content At Cr Level: 0%
  • Relationshiptype: Compatible relationship
  • Return Indicator: Y
  • Returnability: Yes
  • Rohs Eur Conformity Date: 2534
  • Rohs Eur Full Compliance Status: Compliant
  • Rohs Eur Full Compliance Status Id: COMPLIANT
  • Rohs Eur In Scope: Yes
  • Rohs Eur Status: Compliant
  • Rohs Exemption Information: Yes
  • Scope Perimeter: Outside of Europe
  • Serviceability: No
  • Sustainable Packaging: No
  • Take Back: No
  • Tier: 1
  • Tier Id: 1
  • Total Lifecycle Carbon Footprint: 19 kg CO2 eq.
  • Toxic Heavy Metal Free: Yes
  • Traceability: No
  • Use Carbon Footprint: 17.30424348
  • Wd Status: 1 - GSC certified
  • With Recycled Cardboard: No
  • Without Single Use Plastic: Yes
  • Department: Electrical

Professional Applications

  • Commercial Building Electrical Panels
  • Residential Service Panels
  • Industrial Control Panels
  • Healthcare Facility Electrical Systems
  • Educational Institution Power Distribution
  • Retail and Office Building Protection
  • Multi-Unit Residential Properties

Why Choose Schneider Electric Quality?

Schneider Electric QO Series circuit breakers deliver proven reliability with 15-year average life duration and comprehensive safety certifications. The halogen-free construction and Green Premium product status demonstrate environmental responsibility, while RoHS compliance and mercury-free design ensure regulatory adherence. Professional-grade pressure plate connections and bolt-on mounting provide secure, long-lasting installation for critical electrical protection applications.

Manufacturer Resources

Product Specs

Ambient Air Temperature For Operation:
40 °C
Average Life Duration:
15 year(s)
Carbon Footprint:
18.70024213
Carbon Footprint Kg Co2 Eq Total Life Cycle:
18.70024213
China Rohs In Scope:
No
China Rohs Label:
1
Circuit Breaker Application:
not rated
Country Of Origin:
Mexico
Device Type:
LV equipment - Low voltage circuit breaker
Distribution Carbon Footprint:
0.029262
Electrical Connection:
pressure plate
End Of Life Carbon Footprint:
0.04146
Energy Efficiency Optimized:
FALSE
Environmental Disclosure:
ENVPEP2111016
Eoli Availability Display:
No need of specific recycling operations
Eu Rohs Directive:
Compliant
Field Service Division:
PPIBS
Function Option:
Standard
Green Premium Status For Reporting:
Green Premium product
H And D Domain:
Safety
H And D Enrichment Assignment:
yes
H And D Enrichment Class 3:
Earth leakage protection devices
H And D Enrichment Class 4:
GFCI
H And D Enrichment Function:
GFCI
Halogen Content Performance:
Halogen free product
Installation Carbon Footprint:
0.000056652
Legacy Weee Scope:
In
Line Rated Current:
20 A
Manufacturing Carbon Footprint:
1.32522
Market Segmentation:
Commercial
Mercury Free:
Yes
Mounting Mode:
bolt-on
Number Of Spaces Required:
1
Package Weight Lbs:
226.796 g
Packaging Made With Recycled Cardboard:
No
Packaging Without Single Use Plastic:
Yes
Poles Description:
1P
Product Availability:
Stock - Normally stocked in distribution facility
Product Contributes To Saved And Avoided Emissions:
No
Product Depth:
2.91 in
Product Height:
4.13 in
Product Or Component Type:
miniature circuit-breaker
Product Width:
0.75 in
Range Of Product:
QO
Reach Full Compliance Status:
Reference contains Substances of Very High Concern above the threshold
Recycled Metal Content At Cr Level:
0%
Relationshiptype:
Compatible relationship
Rohs Eur Conformity Date:
2534
Rohs Exemption Information:
Yes
Serviceability:
No
Sustainable Packaging:
No
Take Back:
No
Tier:
1
Total Lifecycle Carbon Footprint:
19 kg CO2 eq.
Toxic Heavy Metal Free:
Yes
Traceability:
No
Use Carbon Footprint:
17.30424348
Wd Status:
1 - GSC certified
With Recycled Cardboard:
No
Without Single Use Plastic:
Yes
Department:
Electrical
Product Type:
Miniature Circuit-Breaker
Product Group:
Circuit Breakers

Schneider QOB120VHGFI – Frequently Asked Questions

1) Will a QOB120VHGFI bolt-on breaker fit my Square D QO load center?
The QOB120VHGFI is a bolt-on breaker, not a plug-on, so it needs a panel with bolt-on mounting rails. QOB breakers land in QO-family panelboards prepped for bolt-on, typically NQ style panelboards. If your panel is a plug-on QO load center with a stab bus, this one will not seat on it. Check the interior before ordering.
2) Can I use this QO GFCI breaker on a 240V circuit?
No. This is a 1-pole, 120VAC device for single-pole 120V branch circuits. A 240V load needs a 2-pole GFCI breaker instead.
3) Does this breaker protect people or just the circuit?
Both. It is a GFCI breaker, so on top of 20A overcurrent protection it provides earth leakage protection against shock. Putting it in the panel protects the entire branch circuit, every outlet and fixture downstream, rather than just the one receptacle a GFCI outlet covers.
4) Should I use a GFCI breaker or a GFCI receptacle for a kitchen or bath circuit?
A GFCI receptacle only protects itself and anything wired downstream of its load terminals. This 20A QO GFCI breaker sits at the panel and protects the whole 20A branch circuit from the first device on. Use the breaker where the circuit feeds hard-wired equipment, outdoor or hard-to-reach outlets, or where you want one test point in the panel instead of hunting for a tripped receptacle.
5) What kind of wire terminations does this QO breaker use?
Pressure plate connections. You strip the conductor and clamp it under the plate, no lug prep or ring terminals needed. GFCI breakers also carry a coiled white pigtail that lands on the panel neutral bar, and the circuit neutral goes to the breaker, not the neutral bar.
6) Does this Schneider breaker meet RoHS and green building material requirements?
It is EU RoHS compliant, halogen free, mercury free and free of toxic heavy metals, and Schneider classifies it as a Green Premium product with published environmental disclosure ENVPEP2111016. One caveat for procurement specs that screen on REACH: the reference contains Substances of Very High Concern above the threshold. Total lifecycle carbon footprint is stated at 19 kg CO2 eq. Country of origin is Mexico.
7) What is the exact part number to order for a Schneider QO 1-pole 20A bolt-on GFCI breaker?
Order Schneider Electric QOB120VHGFI. That is the QO range, 1-pole, 20A, 120VAC, bolt-on, GFCI, high interrupting version. The UPC is 785901520719.
8) What are the physical dimensions of the QO 20A GFCI breaker?
It measures 0.75 in wide, 4.13 in high and 2.91 in deep. The 0.75 in width is the standard single QO pole pitch, and the 2.91 in depth is worth checking against your panel cover clearance on shallow or flush-mounted enclosures.
9) Can a tripped QO GFCI breaker be repaired or rebuilt?
No. The QOB120VHGFI is a non-serviceable sealed device. If the GFCI sensing electronics fail or it will not reset with the circuit clear, you replace the breaker. Average life duration is stated at 15 years, so facilities standardizing a panel should plan replacement rather than repair.
