Product Specs
- Country Of Origin:
- Canada
- Csa Cert :
- LR21001
- Ip Rating:
- IP20
- Product Height:
- 36
- Product Material:
- Mild Steel
- Product Weight:
- 70 lbs
- Product Width:
- 24
- Reach Compliant:
- Yes
- Rohs Compliant:
- Yes
- Standards:
- csa, ul
- Type Rating:
- type-1
- Ul File :
- E65324
- Usmca Compliant:
- Yes
- Product Depth:
- 10
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Subgroup:
- Enclosures
- Product Type:
- Screw-Cover Enclosure
Hammond Manufacturing CS362410 – Frequently Asked Questions
1) Can the Hammond CS362410 enclosure be mounted outdoors or in a washdown area?
No. The CS362410 is a Type 1 enclosure with an IP20 rating, which means indoor use only and no protection against water or dust ingress. It is finger-safe against solid objects but nothing more. For outdoor, rain, or hose-down locations you need a Type 3R, 4, or 4X enclosure instead.
2) Does the CS362410 come with knockouts for conduit?
No knockouts. The CS362410 ships as a blank box, so every conduit entry has to be punched or drilled on site exactly where your runs land. That is the point of a no-KO box for a custom layout, but it does mean you need a punch set or hole saw and the right connectors on the truck.
3) Is the Hammond CS362410 UL and CSA listed for a commercial inspection?
Yes, both. It carries UL file E65324 and CSA certification LR21001, as a Type 1 enclosure. Those are the file numbers an inspector or submittal reviewer will want cited.
4) Is this Hammond junction box steel or plastic, and will it take a painted finish?
Mild steel. It is a fabricated steel screw cover enclosure, so it will accept field paint or touch-up, supports the weight of mounted components and DIN rail, and can be drilled and tapped for internal panels. If you need non-conductive or corrosion-resistant construction, look at a fiberglass or stainless enclosure instead.
5) How heavy is the CS362410, and does it need more than one person to hang?
70 lbs empty. At 36 x 24 inches and that weight, plan on two people and lag or through-bolt into studs, strut, or masonry anchors rated well above 70 pounds before you add conductors and devices.
6) Is a screw cover box the right choice, or should I be using a hinged door enclosure?
A screw cover like the CS362410 is for enclosures you open rarely, pull boxes, splice points, gutter transitions. The cover comes fully off, which is handy when you are landing conductors but awkward overhead or in a tight corridor. If an operator or technician is in the box regularly, a hinged cover enclosure is the better pick. Either way this one is indoor, Type 1 only.
7) Does the Hammond CS362410 meet RoHS, REACH and USMCA requirements for a government or institutional order?
Yes on all three. The CS362410 is RoHS compliant, REACH compliant, and USMCA compliant, and it is manufactured in Canada. That covers the usual environmental and trade-origin boxes on a public or institutional submittal package.
8) What part number do I order to match an existing 36x24x10 Hammond screw cover box?
CS362410 is the manufacturer part number, and it is the 36 x 24 x 10 inch no-knockout screw cover size in mild steel. If you are standardizing a building on one box size, that number keeps the hole pattern and cover interchange consistent across openings.
