Screws 10 x 1/2 FH Hx Pin TR SMS 18-8 (100 pcs)
Manufacturer Resources
Product Specs
- Division:
- Electrical H1
- Product Group:
- Fasteners
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Screws
Metallics TP508SFC – Frequently Asked Questions
1) What size and type of screw is the Metallics TP508SFC?
It's a #10 x 1/2 inch sheet metal screw with a flat head, driven by a tamper-resistant hex pin drive, in 18-8 stainless steel. Sold 100 pieces to the box.
2) Do I need a special driver for the hex pin tamper-resistant screws on the TP508SFC?
Yes. The hex pin drive has a post in the center of the hex recess, so a standard hex/Allen key will not seat. You need a pin-in-hex security bit sized to the recess. Plan on having those bits on the truck before the install, since a standard hex set won't drive or remove them.
3) Will the TP508SFC stainless screws hold up outdoors or in a damp location?
18-8 stainless (the common 300-series austenitic grade) gives good general corrosion resistance for exterior covers, damp interiors, and coastal-adjacent work. It is not the choice for direct, continuous salt-spray immersion, where a 316 fastener is the better call.
4) Are these sheet metal screws self-drilling?
No. The TP508SFC is a plain sheet metal screw (type AB/A style point, not a self-drilling tapper), so you drill or punch a pilot hole in the sheet first and let the screw thread cut. If you need to go through gauge steel without pre-drilling, you want a self-drilling point instead.
5) What are these #10 tamper-resistant screws typically used for on electrical work?
Flat head #10 security sheet metal screws at 1/2 inch length are the standard way to lock down cover plates, enclosure and box covers, device plates, and panel trims in public or high-traffic areas where you don't want the cover coming off with a common driver. The flat head countersinks flush so nothing snags.
6) How many Metallics TP508SFC screws come in a box?
100 pieces per box, all one size (#10 x 1/2 inch). For a building standardizing on security cover plates, that is enough for roughly 25 four-screw covers per box.
How fast can I get the Metallics TP508SFC delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Metallics TP508SFC come with a warranty?
Absolutely. The Metallics TP508SFC is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Metallics TP508SFC?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
Why buy the Metallics TP508SFC from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support,
and
rewards on
every order.
Our team is always ready to help you choose the right product for your project.
