Concealed Vandal-Resistant Power Transfer Solution

SDC PTH Series Electrified Power Transfer Hinges provide a concealed and vandal-resistant method for running wires from the frame to doors equipped with electric locks and exit devices. Available in three conductor configurations (PTH-4 four conductor, PTH-10 ten conductor, and PTH-2+4 six conductor), these 4-1/2"; x 4-1/2"; standard weight hinges feature 5-knuckle construction and are rated for 800,000 endurance cycles for demanding commercial applications.

Professional Features & Benefits

• Multiple Conductor Options: Available in PTH-4 (four conductor), PTH-10 (ten conductor), and PTH-2+4 (six conductor) configurations for various wiring requirements.
• Heavy-Duty Endurance Rating: Tested to 800,000 cycles for long-term reliability in high-traffic commercial applications.
• Standard Hinge Dimensions: 4-1/2"; x 4-1/2"; size with 5-knuckle design provides robust mounting and operation.
• Concealed Wiring Protection: Vandal-resistant design protects electrical connections while maintaining clean door appearance.
• Complete Cable Assembly: Includes 5' cable for flexible installation and connection requirements.
• Wire Replacement Warranty: Manufacturer warranty coverage specifically includes wire replacement for added confidence and protection.
• Commercial-Grade Construction: Standard weight hinge design engineered for demanding commercial door applications with electrified hardware.

Technical Specifications

• Commercial/Residential: Commercial
• Department: Door Hardware
• Electronic: Yes
• Endurance Cycles: 800,000
• PDF:SDC Full Catalog: https://zensupply.com/content/pdf/lcn/CondensedHardwareBrochure
• Product Category: Door Hinges and Pivots
• Product Dimension: 4-1/2"; x 4-1/2";
• Product Group: Door Hinges and Pivots
• Product Model: PTH-4, PTH-10, PTH-2+4
• Product Subgroup: Electrified Hinges
• Product Type: Electrified Hinges
• Series: PTH Series
• Subcategory: Power Transfer Devices

Professional Applications

• Commercial Office Buildings with Access Control
• Educational Facilities with Electrified Hardware
• Healthcare Institutions with Security Systems
• Retail Establishments with Electronic Locks
• Industrial Facilities with Automated Access
• Government Buildings with Integrated Security
• Multi-Tenant Properties with Electronic Access

Why Choose SDC Quality?

SDC PTH Series power transfer hinges deliver professional-grade reliability with standard weight 5-knuckle construction rated for 800,000 endurance cycles. Wire replacement warranty coverage provides added confidence for critical electrified door applications. Engineered for demanding commercial applications where concealed wiring protection and dependable electrical continuity are essential.
