Spears Schedule 40 PVC 22-1/2° Socket Elbow

Spears Schedule 40 PVC 22-1/2° Socket Elbow

(No reviews yet) Write a Review

Model: 416-007

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1.77
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Spears 416-007 3/4" PVC 22-1/2° Socket Elbow, Schedule 40

The Spears 416-007 is a 3/4" PVC 22-1/2° socket elbow manufactured to Schedule 40 specifications, giving contractors and installers a dependable fitting for changing pipe direction without the sharper turn of a standard 90° or 45° elbow. Built from solid PVC material, this elbow features socket (SOC) connections on both ends for a solvent-weld joint that resists leaks under normal operating pressure. The 3/4" trade size and Schedule 40 wall thickness make it compatible with standard Schedule 40 PVC pipe and fittings commonly used in pressure piping, plumbing, and conduit systems. As part of the Spears line of PVC fittings, the 416-007 is engineered for consistent dimensional accuracy so it fits and bonds reliably during installation. Spears manufactures this fitting for professional installers who need a precise, code-compliant PVC elbow for demanding piping projects.

Key Features

  • Trade Size: 3/4" sizing for standard PVC pipe runs and conduit systems requiring a compact fitting.
  • Durable PVC Construction: Solid PVC material resists corrosion, chemical attack, and degradation compared to metallic fittings.
  • Socket (SOC) Connection: Solvent-weld socket ends on both openings create a strong, leak-free bonded joint.
  • 22-1/2° Bend Angle: Provides a gradual directional change, useful when a full 90° or 45° turn is more than the run requires.
  • Schedule 40 Dimensions: Matches standard Schedule 40 PVC pipe wall thickness for consistent fit-up and pressure handling.
  • Consistent Manufacturing: Precision-molded for dimensional accuracy and reliable solvent-cement bonding during installation.
  • Compact Design: The 22-1/2° elbow angle offers a smaller footprint change than a 90° elbow while still redirecting pipe flow.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • PVC Pressure Piping Systems
  • Plumbing and Irrigation Installations
  • Directional Changes in Schedule 40 PVC Pipe Runs
  • Electrical and Non-Metallic Conduit Systems
  • Municipal and Agricultural Water Systems
  • New Construction and Retrofit/Repair Projects

Why Spears?

Spears PVC fittings, including the 416-007, are manufactured from solid PVC material to Schedule 40 dimensions, giving installers a dependable solvent-weld solution for redirecting pipe runs without oversized bends. The socket (SOC) connections on this 22-1/2° elbow are designed to form a secure, leak-free joint when properly solvent-welded, supporting long-term performance in pressure piping and plumbing applications. Choosing Spears means specifying a PVC fitting built to consistent Schedule 40 standards for professional installations.

Product Specs

Grade:
Schedule 40
Product Material:
PVC
Angle:
22-1/2°
Product Type:
Elbow
Connection Type:
Socket
Product Group:
PVC & CPVC Fittings
Department:
Plumbing
Product Subgroup:
Pipe Fittings

Spears 416-007 – Frequently Asked Questions

1) What sizes does the Spears 416 Schedule 40 PVC 22-1/2 degree elbow come in?
Two trade sizes: 1/2 inch, part number 416-015, and 3/4 inch, part number 416-007. Both are socket by socket, solvent weld on each end.
2) When should I use a 22-1/2 degree PVC elbow instead of a 45 or 90?
Use the 22-1/2 degree elbow when the run needs a slight offset, not a hard turn: routing around an obstruction, easing a line back onto grade, or making a shallow jog in a trench. A 45 changes direction twice as much and a 90 squares the run off entirely. Two 22-1/2s stacked give you a 45 with a longer, gentler sweep, which is often easier to pull pipe into than one sharp fitting.
3) Can I thread pipe into this 22-1/2 degree PVC elbow?
No. Both ends are sockets for solvent welding, with no threads. If you need a threaded transition at that point, run a short piece of pipe out of the elbow into a separate PVC male or female adapter.
4) Is a Spears 22-1/2 degree PVC socket elbow suitable for pressure water lines?
It is built for PVC pressure piping, plumbing and irrigation, and municipal or agricultural water systems. The solvent welded socket joint is what carries the pressure, so joint prep matters: clean, primed sockets and full cement coverage.
5) Will a 1/2 inch 416 elbow fit Schedule 80 PVC pipe?
No. Schedule 80 pipe has the same outside diameter but the fitting is dimensioned and rated as Schedule 40, so pairing them is a mismatch on wall thickness and rating even though the socket will physically accept the pipe. Use a Schedule 80 fitting on a Schedule 80 system.
6) Can I use this PVC elbow for non-metallic electrical conduit runs?
Conduit systems are among the listed applications for the 416 elbow, and the shallow 22-1/2 degree bend is useful for easing a conduit run around an obstruction without a sharp turn that fights the pull. Confirm your local electrical code accepts the fitting for the specific installation.
7) Where can I get the laying length and socket depth for the Spears 416 elbow?
Spears publishes a PVC Schedule 40 fittings dimensions and weights sheet along with a Schedule 40 dimensions sheet, both attached to the 416 elbow. Those give the socket entrance, socket depth and center-to-end figures you need to lay out a run before cutting pipe.
