Intermatic FD30MWC Spring Wound Countdown Timer, Decorator Style, 125-277 VAC, 50/60 Hz, SPST, 30 Minute Max, Without Hold, White

Intermatic FD30MWC Decorator Spring Wound Countdown Timer 125-277 VAC 30 Minute SPST White

(No reviews yet) Write a Review

Model: FD30MWC
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$120.69
$55.08
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Intermatic FD30MWC Decorator Spring Wound Countdown Timer 125-277 VAC 30 Minute SPST White

Professional Energy Management & Load Control Solution

The Intermatic FD30MWC Decorator Spring Wound Countdown Timer delivers reliable automatic load control with 125-277 VAC compatibility and 30-minute maximum timing. This SPST spring wound timer requires no electricity to operate and automatically limits ON time for energy consuming loads, breaking the circuit at the end of each timing cycle. The decorator style design replaces any standard or decorator single- or multi-gang wall switch with quick and easy installation.

Professional Features & Benefits

  • 30-Minute Maximum Timer: Provides precise automatic shutoff control for energy management and load protection applications.
  • 125-277 VAC Compatibility: Works with both residential and commercial voltage systems for versatile installation options.
  • Spring Wound Operation: Requires no electricity to operate, ensuring reliable performance even during power fluctuations.
  • SPST Configuration: Single-pole single-throw design provides simple circuit control with automatic breaking at timing cycle end.
  • Universal Load Compatibility: Works with incandescent, fluorescent, CFL, and LED lighting loads without neutral connection requirements.
  • Decorator Style Design: Professional appearance integrates seamlessly with standard or decorator wall switch installations.
  • Teeter-Type Terminals: Time-saving front terminal connections simplify installation and maintenance procedures.

Technical Specifications

  • Applications: Air Movement & Ventilation;Indoor Lighting Control;Outdoor Lighting Control;Motor Control
  • Country Of Origin: Tunisia
  • Depth: 1.25 in
  • Input Voltage Rating Range S : 125-277 VAC, 50/60 Hz
  • Marketing Description: The FD Series Decorator Countdown Timers are designed to replace any standard or decorator style wa
  • Product Color: White
  • Product Height: 4.125 in
  • Product Length: NA NA
  • Product Weight: NA lbs
  • Product Width: 1.75 in
  • Warranty Period: 1-Year limited

Professional Applications

  • Air Movement & Ventilation Control
  • Indoor Lighting Control Systems
  • Outdoor Lighting Management
  • Motor Control Applications
  • Commercial Building Automation
  • Residential Energy Management
  • Industrial Load Control

Why Choose Intermatic Quality?

Intermatic delivers proven reliability with this 1-year limited warranty spring wound countdown timer, featuring durable construction and professional-grade performance. The white decorator style finish and universal voltage compatibility ensure long-lasting service across diverse commercial and residential applications.

Manufacturer Resources

Product Specs

Application:
Air Movement & Ventilation;Indoor Lighting Control;Outdoor Lighting Control;Motor Control
Country Of Origin:
Tunisia
Input Voltage Rating Range S :
125-277 VAC, 50/60 Hz
Marketing Description:
The FD Series Decorator Countdown Timers are designed to replace any standard or decorator style wa
Product Color:
White
Product Height:
4.125 in
Product Length:
NA NA
Product Weight:
NA lbs
Product Width:
1.75 in
Warranty Period:
1-Year limited
Product Depth:
1.25 in

Intermatic FD30MWC – Frequently Asked Questions

1) Does the Intermatic FD30MWC spring wound timer need a neutral wire?
No neutral is required. The FD30MWC is a mechanical spring wound SPST timer, so it needs no electricity to run the timing mechanism, and it switches incandescent, fluorescent, CFL and LED loads without a neutral connection. That makes it a straight swap into older switch boxes where only a hot and a switch leg are present.
2) Will a spring wound timer fit in a standard single gang switch box with a decorator plate?
Yes. The FD30MWC is built to drop into any standard or decorator style single gang or multi gang wall switch opening and uses a decorator (rocker style) plate. The body measures 4.125 in high, 1.75 in wide and 1.25 in deep, so it clears a normal switch box without crowding adjacent devices in a multi-gang bank.
3) Can I use the FD30MWC on a 277 volt commercial lighting circuit?
Yes. It is rated 125-277 VAC, 50/60 Hz, so the same device works on 120 V residential circuits and on 277 V commercial lighting branch circuits. One part number covers both, which is useful if you are standardizing a mixed-voltage building.
4) Does this 30 minute timer have a hold position to leave the load on indefinitely?
No. The FD30MWC is the without-hold version. The dial winds up to 30 minutes maximum and the contacts open at the end of the cycle every time, with no way to park it in a continuous ON position. If you need occupants to be able to hold a fan or light on indefinitely, you need a hold-feature model instead.
5) What is a good timer for a bathroom exhaust fan that keeps getting left running?
A spring wound countdown timer like the FD30MWC handles exactly that. Winding the dial runs the fan for up to 30 minutes and then the circuit breaks on its own, so nothing is left running after the tenant leaves. Intermatic lists air movement and ventilation among its applications, along with indoor and outdoor lighting control and motor control.
6) Is 30 minutes enough, or should I get a longer spring wound timer?
Thirty minutes is the full range on the FD30MWC, and it suits bathroom and locker room fans, closet and utility lighting, and short-run motor loads. For a shower-room heater, a sauna, or exterior lighting someone needs on through dusk, pick a longer-duration FD Series model (the family runs to longer maximums) rather than asking occupants to rewind this one.
7) How are the wires connected on the Intermatic FD30MWC, screws or pigtails?
It uses teeter-type front terminals, so you land the conductors on the face of the device rather than wrestling side screws or splicing to pigtails in the box. On an SPST hookup that is two conductors, line and load, which keeps the install quick on a retrofit.
8) Will the white decorator timer match the rest of my white rocker switches?
The FD30MWC is white in a decorator profile, so it sits behind the same decorator/rocker style wall plates as your existing devices and reads as part of the bank rather than a utility add-on. That matters when you are putting these in guest bathrooms or leased offices.
9) Is the Intermatic FD30MWC the right part number to order, and what does the MPN cover?
FD30MWC is the manufacturer part number and the only configuration sold under it: 30 minute maximum, SPST, 125-277 VAC, white, decorator style, without hold. There are no finish or duration options to specify on this number.
