Square D Homeline 30-Space 60-Circuit Convertible Main Lugs Load Center

Square D Homeline 30-Space 60-Circuit Convertible Main Lugs Load Center

(No reviews yet) Write a Review

Model: HOM816L125PGC

In Stock (leaves warehouse same day if ordered before 3pm ET)

$108.01
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Square D Homeline 30-Space 60-Circuit Convertible Main Lugs Load Center

The Square D Homeline 30-Space 60-Circuit Convertible Main Lugs Load Center delivers dependable single-phase power distribution for residential and light commercial electrical systems, and this platform is offered across a Motor FLA range from 125A to 225A to match a variety of service capacities. This NEMA 1 indoor-rated load center features a Plug-on Neutral (PoN) convertible main lugs design rated 120/240 V AC with a 10 kA short-circuit current rating, and accepts AWG 6...AWG 1 copper or AWG 6...AWG 2/0 aluminum conductors across the family. Backed by UL Listing (file E-6294), this Homeline load center is built for fast installation and long-term reliability in new construction or panel upgrade projects.

Key Features

  • Configuration: 30 spaces / 60 circuits for expanded single-phase 3-wire circuit capacity.
  • Motor FLA Range: Available in 125A and 225A ratings to fit different service sizing needs.
  • Convertible Main Lugs: PoN (Plug-on Neutral) convertible mains design with lugs electrical connection.
  • Wire Range: Accepts AWG 6...AWG 1 copper or AWG 6...AWG 2/0 aluminum conductors for efficient power transfer.
  • Durable Construction: Welded sheet steel enclosure with tin plated aluminum busbar for long service life.
  • Rated Voltage: 120/240 V AC operational voltage rating.
  • Short-Circuit Rating: 10 kA short circuit current rating for equipment overload and short-circuit protection.
  • Grounding Bar: Provided grounding bar (1) included for code-compliant grounding.
  • Combination Cover: Combination flush/surface cover finished in baked enamel gray.

Certifications & Compliance

  • UL Listed, file E-6294
  • NEMA 1 Indoor Enclosure
  • Rated for ambient operation from -5 °C to 40 °C

Technical Specifications

  • Voltage Rating: 120/240VAC
  • Configuration: NEMA 1 Enclosure
  • Product Material: Welded Steel
  • Motor FLA Options: 125A, 225A

Typical Applications

  • Residential Electrical Panel Upgrades and New Construction
  • Circuit Breaker and Load Center Installations
  • Indoor Single-Phase Power Distribution
  • Service Panel Replacement and Renovation Projects

Why Square D?

Square D Homeline load centers pair a welded sheet steel enclosure and tin plated aluminum busbar with UL Listed construction to deliver code-compliant, reliable circuit protection across the 125A-225A Motor FLA range. The convertible main lugs design and combination flush/surface cover simplify installation, making this Homeline load center a trusted choice for professional electricians and contractors on residential and light commercial projects.

Manufacturer Resources

Product Specs

Product Type:
Load Center
Series:
Homeline
Product Finish:
Baked Enamel Gray
Voltage Rating:
120/240VAC
Connection Type:
Lugs
Configuration:
NEMA 1 Enclosure
Listing:
UL Listed
Product Material:
Welded Steel
Department:
Electrical
Product Group:
Power Distribution
Amperage Rating:
125A-225A
Product Subgroup:
Panelboards & Load Centers
Product Depth:
3.74 in
Product Width:
14.25 in

Square D HOM816L125PGC – Frequently Asked Questions

1) Can a Homeline main lugs load center be converted to a main breaker panel later?
Yes. The Homeline 30-space load center uses a convertible main lugs design, so the mains can be changed from lugs to a main breaker by adding the appropriate main breaker kit. That is the point of the convertible chassis: you can wire it as a feed-through or sub panel now and add a main device if the service arrangement changes. The factory connection as supplied is lugs.
2) What wire size can I land on the lugs of the Square D Homeline 30-space load center?
The lugs take AWG 6 through AWG 1 copper, or AWG 6 through AWG 2/0 aluminum. If your feeder is larger than 2/0 aluminum or 1 copper, this is the wrong panel for that conductor and you need a larger-lug load center.
3) Which Homeline part number do I order, HOM3060L225PGC or HOM816L125PGC?
Two ratings are offered: HOM3060L225PGC at 225A and HOM816L125PGC at 125A. Match the part number to the service or feeder ampacity you are protecting upstream. Both are Plug-on Neutral main lugs convertible panels at 120/240V AC.
4) What is the closest Eaton equivalent to the Square D Homeline convertible main lugs load center for an indoor panel?
The Eaton BR main lug only loadcenter BRP24L125GW is the nearest indoor counterpart. Like the Homeline convertible main lugs load center, it is a main-lug-only unit in a NEMA 1 enclosure with an aluminum bus, rated 125A. The Square D Homeline uses a welded steel enclosure with a tin plated aluminum busbar and is offered in 125A and 225A, so if the service calls for 225A the Homeline covers it while the BR unit named here is a 125A device. Homeline accepts Homeline breakers and the BR panel accepts BR breakers, so the breaker inventory does not carry over.
5) The panel is going on an exterior wall outdoors. What should I use instead of the Homeline convertible main lugs load center?
Use an outdoor-rated enclosure instead. The Homeline convertible main lugs load center is a NEMA 1 indoor enclosure and is not intended for a wet exterior location. For outdoor mounting, the Eaton CH 125A main lug loadcenter comes in a NEMA 3R enclosure with a copper bus, and the ABB ReliaHome PAM load center is a NEMA 3R aluminum enclosure with plug-on neutral. Both are rain-tight styles suited to exterior walls; the Homeline is the indoor choice.
6) Will a 3.74 inch deep load center fit in a 2x4 stud wall flush mounted?
The enclosure is 3.74 inches deep and 14.25 inches wide, so it sits within the 3-1/2 inch depth of a 2x4 stud bay with a slight proud edge handled by the combination flush/surface cover. The width also clears a standard 16 inch on-center stud bay. The supplied cover works for either a flush or a surface installation, so you do not order a separate trim.
7) Does 30 spaces really mean 60 circuits in this Homeline panel?
Yes. The chassis has 30 spaces and is rated for 60 circuits, meaning tandem (twin) Homeline breakers can be used in the permitted positions to reach 60 poles. Single-pole full-size breakers alone give you 30 circuits.
8) What short-circuit current rating does this Homeline load center have, and is that enough for my service?
It carries a 10 kA short-circuit current rating at 120/240V AC. For typical residential and light commercial single-phase services fed from a utility transformer at normal distances, 10 kA is the common requirement. If your available fault current calculation exceeds 10 kA at the panel location, you need a higher-SCCR panelboard.
9) Is a ground bar included with the Square D Homeline 30-space load center, or do I buy it separately?
One grounding bar ships with the panel, so you can bond equipment grounding conductors without a separate kit. If you are using it as a sub panel with a large number of grounds, a second bar may be wanted, but one is supplied.
10) Is this panel single-phase or three-phase?
Single-phase, 3-wire, 120/240V AC. It is for residential and light commercial distribution and will not serve a 3-phase load. For 208Y/120 three-phase work you need a three-phase panelboard instead.
11) What is Plug-on Neutral and does it change how I wire AFCI and GFCI breakers?
Plug-on Neutral means the neutral connection is made through the busbar when the breaker snaps into place, so Homeline PoN AFCI and GFCI breakers do not need a neutral pigtail run to the neutral bar. That cuts wire congestion in the gutter and speeds up a panel full of combination AFCIs. Use Homeline PoN breakers to get the benefit.
12) I want a copper bus panel instead of aluminum. What should I look at?
The Homeline 30-space uses a tin plated aluminum busbar. If the spec calls for copper bus, the Eaton CH 125A main lug loadcenter is a copper bus unit, in a NEMA 3R enclosure. Note that moves you to CH breakers and an outdoor-rated box.
13) Is there a copper bus alternative to the Square D Homeline load center?
Yes. The Eaton CH 125A main lug loadcenter uses a copper bus, while the Square D Homeline convertible main lugs load center uses a tin plated aluminum busbar. The CH unit is housed in a NEMA 3R enclosure, so it is the outdoor-style option, whereas the Homeline is a NEMA 1 indoor unit finished in baked enamel gray. Specifying copper bus also means specifying CH breakers rather than Homeline breakers.
14) Will the gray finish match the other Homeline panels already in my building?
The cover is baked enamel gray, the standard Homeline finish, so it reads consistently alongside existing Square D Homeline panels in a mechanical room or apartment corridor. The enclosure itself is welded sheet steel.
15) I only need a small indoor panel, not 30 spaces. What is a simpler option than the Homeline convertible main lugs load center?
For a smaller indoor circuit count, the Eaton BR main lug only loadcenter BRP24L125GW is the lighter-duty indoor choice, rated 125A with an aluminum bus in a NEMA 1 enclosure. The Square D Homeline convertible main lugs load center is built for expanded capacity at 30 spaces and 60 circuits with a convertible mains design, and its 125A version is the comparable rating if you want to stay in the Homeline breaker family.
