Spec Sheet
Product Specs
- Actuator:
- Type C, Extended
- Actuator Color:
- Orange
- Legend:
- Blank legend
- Letter Size:
- 1/8 inch high
- Notes:
- Use with E30AF through AK, AL through AM, and DG through DM operators
- Product Category:
- Button
- Series:
- E30
- Used With:
- Pushbutton, square multifunction
- Department:
- Electrical
- Product Type:
- 30.5 mm, Square Multifunction Watertight/Oiltight
- Product Length:
- .1 IN
- Product Details:
- 30.5 mm, Square Multifunction Watertight/Oiltight
- Product Height:
- 5 IN
- Product Weight:
- .3 LB
- Product Width:
- 4 IN
B-LINE E30KC800 – Frequently Asked Questions
1) Which E30 operators does the B-Line E30KC800 pushbutton button fit?
The E30KC800 button is made for B-Line E30 series operators in the E30AF through AK, AL through AM, and DG through DM ranges. It is a square multifunction pushbutton button, so it goes on a square multifunction 30.5 mm operator body, not a selector switch or pilot light head.
2) Is the B-Line E30KC800 a complete pushbutton, or do I need to order more parts?
It is the button only. To build a working station you also need the matching E30 square multifunction operator body from the E30AF-AK, AL-AM or DG-DM ranges, plus the contact blocks for your circuit. Buying this alone gets you a replacement or color change on an existing operator.
3) Can I swap just the button color on an existing E30 station without replacing the operator?
That is exactly what this part is for. The orange Type C extended button drops onto a compatible E30 square multifunction operator, so you can change a button face or replace a damaged one without pulling the operator, contact blocks or wiring out of the panel.
4) What actuator style and color is the B-Line E30KC800?
Type C extended actuator in orange. The extended style stands proud of the operator bezel so it can be hit quickly or with a gloved hand, and orange is typically used for an alert or attention function rather than start (green) or stop (red).
5) Does the E30KC800 come with text or a legend marked on it?
It ships blank. The E30KC800 has no legend printed on the button face, so if your panel needs START, STOP, JOG or a custom marking you will need a legended version or a separate legend plate. When legend is supplied on this style, the character height is 1/8 inch.
6) Can the E30KC800 be used on a washdown or oily machine panel?
Yes. It is part of the E30 30.5 mm watertight/oiltight square multifunction line, which is the type specified for machine tool and process panels exposed to coolant, cutting oil and hose-down. The sealing is a function of the operator it mounts to, so keep the assembly in the same watertight/oiltight family.
