Stanley Security 50" Wire Harness, Terminated at Both Ends

Stanley Security 50" Wire Harness, Terminated at Both Ends

(No reviews yet) Write a Review

Model: WH-50

In Stock (leaves warehouse same day if ordered before 3pm ET)

$46.79
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Stanley Security 50" Wire Harness, Terminated at Both Ends

The Stanley Security WH-50 is a 50-inch wire harness, terminated at both ends with plug connectors, designed for use with electrified lever and exit device hardware. It’s part of Stanley’s “Quick Connect / Wire Harness” line. The WH-50 enables reliable routing of power through doors and frames, reducing installation complexity and improving performance for electrified hardware installations. It’s widely used in combination with Stanley, BEST, and Precision brand electrified components.

Specifications

Specification Details
Model / Part Number WH-50
Length 50 inches; terminated at both ends with plug connectors
Type Wire harness for electrified door hardware / exit devices
Finish / Condition Standard wire insulation; not painted (default)
Purpose / Compatibility Designed to connect electrified exit devices, BEST locks, Precision brand hardware, and Stanley lever or hinges using plug-in end compatibility
Availability In stock in commercial hardware outlets; lead times may vary depending on shipping region

Applications & Benefits

  • Eliminates the need for custom wiring or field-splicing by using plug-terminated ends, which reduces installation time and risk of wiring errors.

  • Provides a reliable path for power through door assemblies for electrified exit devices, locks, or hinges.

  • The 50-inch length allows for routing over standard door frame heights with slack for connectors.

  • Compatible with Stanley’s Quick Connect system and other electrified hardware lines, making it versatile for retrofits or new installations.

Manufacturer Resources

Product Specs

Subcategory:
Wire Harness
Product Group:
Wire Harness
Product Subgroup:
Wire Harness
Product Type:
Wire Harness
Commercial/Residential:
Commercial
Product Category:
Wire Harness
Department:
Door Hardware

Stanley Security WH-50 – Frequently Asked Questions

1) What is the Stanley Security WH-50 wire harness used for?
The WH-50 is a 50-inch wire harness with plug connectors factory-terminated on both ends, used to carry power through a door and frame to electrified hardware such as electrified exit devices, electrified locks, and electrified hinges. Because both ends are already terminated, you plug it in rather than splicing wire in the field, which cuts install time and removes a common source of wiring errors.
2) Will a Stanley WH-50 harness plug into BEST or Precision electrified hardware?
Yes. The WH-50 is part of Stanley's Quick Connect / Wire Harness line and is specified for plug-in connection to Stanley, BEST, and Precision brand electrified components, including electrified exit devices, BEST locks, and Stanley electrified levers or hinges.
3) Is 50 inches of wire harness long enough to get from the electric hinge up to a door-mounted exit device?
The 50-inch length is intended to cover routing over standard door frame heights with slack left for the connectors, so it is the length most installers reach for on a typical opening where power transfers at the hinge or frame and terminates at hardware in the door. Measure your actual run from the transfer point to the device connector before committing, since raceway path and door height drive the real number.
4) Can I use the WH-50 on a retrofit, or is it only for new door prep?
Both. The plug-terminated ends let it drop into an existing electrified opening as a replacement harness, and it is equally used on new installations where the door is prepped for a Quick Connect style harness run. What matters is that the hardware on each end takes the plug connector rather than loose leads.
5) Do I need to order anything else with the wire harness, or does it complete the connection?
The harness itself is the complete 50-inch run with connectors on both ends, so no splicing kit or field connectors are needed for the harness. You still need the power transfer path and the electrified device at each end, since the harness only links components that already accept its plug connectors.
6) Is the Stanley WH-50 harness rated for commercial openings or is it a residential part?
It is a commercial door hardware item, built for electrified exit device and electrified lock applications in commercial buildings rather than residential use. That fits the typical job for it: institutional, multi-family, and office openings with access control at the door.
7) Does the WH-50 come painted or finished to match the door?
No. It ships with standard wire insulation and is not painted. The harness is meant to be concealed inside the door and frame raceway, so there is no architectural finish option to specify.
8) Are there different versions of the Stanley WH-50 to choose from?
No options to sort through. The WH-50 is sold as a single configuration, a 50-inch harness terminated at both ends, so length is the only thing to confirm against your opening.
