BEST BB95 Forged Brass Full Surface Olive Knuckle Hinge with Removable Pin

BEST BB95 Forged Brass Full Surface Olive Knuckle Hinge with Removable Pin

Professional Standard Weight Hinge with Distinctive Olive Knuckle Design

The BEST BB95 is a standard weight olive knuckle hinge constructed from forged brass for exceptional durability and aesthetic appeal. Designed for doors ranging from 1-3/8" to 1-3/4" thickness, this versatile hinge features a removable pin design and anti-friction bearing assembly for smooth operation. The distinctive olive knuckle style adds an elegant touch while providing reliable performance for both interior and exterior door applications in residential and light commercial settings.

Professional Features & Benefits

• Door Thickness Compatibility: Designed specifically for 1-3/8" (35 mm) to 1-3/4" (44 mm) doors for versatile installation options.
• Forged Brass Construction: Heavy-duty forged brass material provides exceptional durability and corrosion resistance for long-lasting performance.
• Anti-Friction Bearing Assembly: Equipped with precision bearing assembly for smooth, quiet operation and extended service life.
• Removable Pin Design: Removable pin configuration allows for easy door removal and maintenance when needed.
• Template Hole Locations: Pre-engineered hole patterns with template guidance ensure accurate installation and proper alignment.
• Versatile Application Range: Suitable for hollow metal or wood doors and frames in offices, restaurants, recreational buildings, and residences.
• Handed Configuration: Available in right or left hand configurations to meet specific door swing requirements.
• Professional Installation Spacing: Edge of hinge should be positioned 1/4" (6.4 mm) from door face regardless of door thickness for optimal performance.

Technical Specifications

• Commercial/Residential: Commercial
• Corner Style: Square Corners
• Department: Door Hardware
• Duty Level: Medium Duty
• Hinge Pin Type: Removable
• Product Category: Door Hinges and Pivots
• Product Group: Door Hinges and Pivots
• Product Model: BB95
• Product Subgroup: Specialty Hinges
• Product Type: Olive Knuckle Hinges
• Series: Olive Knuckle Hinges
• Subcategory: Hinges

Installation & Operation

1. Review manufacturer specifications and verify door preparation requirements including door thickness between 1-3/8" and 1-3/4", and determine proper handing (right or left hand).
2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces, ensuring hinge edge is positioned 1/4" from door face.
3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions for proper hinge leaf mortising.
4. Install all mounting hardware and secure the hinge leaves to door and frame per manufacturer torque specifications.
5. Insert removable pin and adjust hinge alignment for proper door swing operation and smooth movement throughout the full range of motion.
6. Test hinge operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Restaurant and Hospitality Venues
• Recreational and Community Buildings
• Residential Properties

Why Choose BEST Quality?

BEST BB95 olive knuckle hinges deliver professional-grade reliability with forged brass construction and anti-friction bearing assembly for smooth, long-lasting operation. The medium duty rating and standard weight design provide dependable performance for average frequency doors in demanding commercial and residential applications. Engineered for versatile installation on both hollow metal and wood doors where distinctive styling and reliable function are essential.
