Stanley Security Grade 1 Heavy Duty Narrow Exit Trim, NL Lever ANSI 09, Less Cylinder
The Stanley Security QET280 is a Grade 1 Heavy-Duty Narrow Stile Exit Trim, engineered to provide robust performance and security in commercial environments. This trim is designed for use with Stanley's QED200 Series exit devices, ensuring durability and reliability in high-traffic areas.
Function
-
Function Type: Night Latch Lever (ANSI 09)
-
Operation: Lever always locked; key retracts latch for entrance, operating similarly to a storeroom function.
-
Cylinder Configuration: Sold as "Less Cylinder," allowing for customization with user-specified cylinders
-
Lever Design: Available in multiple styles, including Sierra (E), Summit (M), and Slate (A).
-
Base Material: Constructed from high-quality brass or bronze, ensuring long-lasting durability and resistance to wear.
-
Mounting: Designed for commercial installation, compatible with narrow stile doors.
Applications
-
Educational Institutions: Classrooms and administrative offices.
-
Healthcare Facilities: Hospitals and clinics.
-
Commercial Buildings: Offices and retail spaces.
-
Public Sector Buildings: Government offices and libraries
Manufacturer Resources
Product Specs
- Series:
- QET
- Grade:
- Grade 1
- Product Group:
- Exit Devices and Trim
- Product Subgroup:
- Exit Devices Trim
- Product Type:
- Cylindrical Locks
- Commercial/Residential:
- Commercial
- Lock Type:
- Exit Device Trim
- Product Attribute:
- Exit Devices Trim
- Product Function:
- Classroom/Storeroom
- Product Function:
- Office/Privacy/Apartment
- Cylinder Classification:
- Conventional Cylinder
- Product Category:
- Electronic Locks
- Department:
- Door Hardware
Stanley Security QET280 E 626 LC – Frequently Asked Questions
1) Does the Stanley QET280 exit trim work with QED200 Series exit devices?
Yes. The QET280 narrow exit trim is built for Stanley's QED200 Series exit devices. It is the trim half only, so you need the QED200 device on the door already or on the same order. It will not turn a device from another manufacturer into a keyed-entry opening.
2) How does the ANSI 09 night latch function on the Stanley QET280 actually operate at the door?
The lever is always locked from the outside. A key retracts the latch so an authorized person can pull the door open, and the lever itself never unlocks the opening. From the inside, the exit device always allows free egress. Behavior is essentially storeroom function on an exit device, which is why it suits classrooms, storerooms, and back-of-house doors in offices and retail.
3) Will this exit trim fit an aluminum storefront door with a narrow stile?
That is exactly what the QET280 is cut for. It is a narrow stile trim, so the escutcheon is sized to fit the slim vertical rail on aluminum storefront and glass front doors. On a wide stile hollow metal or wood door the narrow trim will mount but will look undersized against the stile, and a wide stile trim is the better match there.
4) I want keyless or credential access on my exit device instead of a keyed lever. What should I look at?
The QET280 is strictly mechanical, key in, key out. If you want to drop keys entirely, the Schlage CO-100 standalone electronic exit device trim is Grade 1 classroom/storeroom with an onboard keypad reader for 1-3/4 inch doors. For mobile credentials, the Schlage XE360EW22S is a Grade 1 wireless exit trim with Bluetooth and NFC that pairs with a Von Duprin 22 SVR device. Note both are 1-3/4 inch door products, so they are not a drop-in for a thin aluminum storefront stile the way the narrow Stanley trim is.
5) What is the difference between the Stanley QET280 narrow exit trim and the Schlage XE360EW22S exit trim?
Both are Grade 1 exit device trim, but they credential differently. The Stanley QET280 is mechanical night latch lever trim (ANSI 09) supplied less cylinder, so the key retracts the latch and the lever is otherwise always locked, and you specify a conventional cylinder separately. The Schlage XE360EW22S is a wireless trim with a smart Bluetooth and NFC mobile reader and an interior pushbutton LED with indicator, and it is built for the Von Duprin 22 SVR device. Choose the QET280 when the opening is keyed mechanically on a Stanley QED200 device; choose the XE360 when credentials need to be issued and revoked electronically.
6) I need an exit trim with a keypad instead of a key cylinder - what should I use instead of the Stanley QET280?
The Schlage CO-100-993M-70-KP is a standalone electronic mortise exit device trim with a keypad reader in a Grade 1 classroom/storeroom function. It replaces the key-in-lever entry method of the Stanley QET280, which is night latch lever trim requiring a separately ordered conventional cylinder. Note the CO-100 trim is a mortise exit device trim rated for 1-3/4 inch doors, while the QET280 is narrow stile trim for Stanley QED200 series devices, so the device beneath the trim is not the same.
7) What lever styles and finishes does the Stanley QET280 exit trim come in?
Three lever designs: Slate (A), Sierra (E), and Summit (M). Each is offered in four finishes, 605 bright brass, 613 oil rubbed bronze, 626 satin chrome, and 690 painted duranodic bronze. For storefront work 690 is the usual pick because it matches dark anodized aluminum, and 626 is the standard commercial choice on institutional openings.
8) Is the Stanley QET280 trim heavy duty enough for a school or hospital entrance?
It is a Grade 1 heavy duty trim, the top ANSI/BHMA durability tier and the one specified for high traffic commercial and institutional openings. The escutcheon and lever are brass or bronze base material. Stanley lists it for classrooms and administrative offices, hospitals and clinics, offices and retail, and government buildings and libraries.
9) Can the Schlage CO-100 or XE360 exit trim be used on a narrow stile aluminum door in place of the Stanley QET280?
Treat them as different openings. The Stanley QET280 is specifically narrow stile exit trim built for Stanley QED200 series devices. The Schlage CO-100-993M-70-KP is a mortise exit device trim listed for 1-3/4 inch doors, and the XE360EW22S is matched to the Von Duprin 22 SVR device and also listed at 1-3/4 inch door thickness. Both are Grade 1 like the QET280, but neither is described as narrow stile trim, so confirm the stile width and the existing device family before substituting.
10) If I am standardizing trim across a building, can I mix lever designs and finishes on the same order?
Yes. Slate, Sierra, and Summit are all available in the same four finishes, so you can run one lever design building-wide and vary finish by entrance, or hold one finish and vary the lever by department. Every unit is the same ANSI 09 night latch function, so keying and operation stay consistent no matter which design you pick.
11) If I want the exit trim lever style and finish to match other doors, does the Stanley QET280 or a Schlage electronic trim give more options?
The Stanley QET280 is the one built around appearance matching: it comes in Slate (A), Sierra (E), and Summit (M) lever designs, each offered in 605 bright brass, 613 oil rubbed bronze, 626 satin chrome, and 690 painted duranodic bronze. The Schlage CO-100-993M-70-KP is a keypad reader trim and the XE360EW22S carries an interior pushbutton with LED indicator, so both are shaped by their electronics rather than by a selectable lever design.
