Manufacturer Resources
P 60 1/2 2 AL Spec Sheet
Product Specs
- Inner Quantity:
- 1
- Unspsc:
- 39121307 Floor boxes
- Product Group:
- Boxes & Enclosures
- Product Details:
- Flush Service
- Floor Maintenance:
- Dry
- Mounting Opening:
- Round
- Standards:
- UL E2969
- Product Type:
- Floor Boxes
- Cover Mounting Opening:
- Y
- Department:
- Electrical
- Product Subgroup:
- Floor Boxes
- Outer Quantity:
- 4
Steel City P 60 1/2 2 AL – Frequently Asked Questions
1) Can the Steel City P 60 1/2 2 floor box service fitting be used in an area that gets wet mopped?
No. The P 60 1/2 2 flush service fitting is rated for dry floor maintenance only, so keep it out of areas that get wet mopped, washed down, or see standing water. For a lobby or corridor that is damp mopped on a schedule, specify a fitting carrying a wet-location floor maintenance rating instead.
2) Does the P 60 1/2 2 service fitting mount in a round floor box opening?
Yes. The mounting opening on the P 60 1/2 2 is round, so it seats in a round cover opening rather than a rectangular one. If the box already in your slab has a rectangular service opening, this fitting is not the one to order.
3) What does a flush service fitting like the Steel City P 60 actually do in a floor box?
It is the above-slab trim piece, not the box. The P 60 1/2 2 finishes the floor box opening flush with the finished floor and provides the service opening for the device, so you still need the floor box itself set in the pour, plus the device and any conduit. Flush is the choice when nothing can project above the floor line in a walking path; a pedestal or above-floor fitting is what you use where a cord or data drop has to come up off the floor.
4) What is the difference between the Steel City P 60 1/2 2 and the P 60 1/2 2 AL?
Same flush service fitting, two material choices. The P 60 1/2 2 is the standard material version and the P 60 1/2 2 AL is aluminum. Pick the aluminum one where you want the lighter, corrosion-resistant body or need it to match other aluminum floor box trim in the slab; otherwise the standard version is the base part.
5) How many Steel City P 60 1/2 2 fittings come in a carton?
They are sold as single pieces, with four to a master carton. Useful if you are ordering by the box for a multi-floor tenant fit-out rather than a one-off replacement.
6) Where can I get the dimensional drawing for the Steel City P 60 1/2 2 before I commit to the opening size?
Steel City publishes a spec sheet for both versions, one for the standard P 60 1/2 2 and a separate one for the aluminum P 60 1/2 2 AL. Those are the documents to pull for the dimensional layout and opening detail when you are coordinating the slab penetration with the concrete contractor.
