3/8 INCH CONN,AC/FLEX,DC,CLMP
Manufacturer Resources
Product Specs
- Product Type:
- AC/MC/Flex Connector
- Selling Unit Of Measure:
- each
- Standards:
- UL e1383, CSA 12798
- Department:
- Electrical
- Product Group:
- Conduit & Raceway
- Product Subgroup:
- Flexible Conduit & Fittings
- Product Type2:
- Clamp Type Connectors
- Product Size:
- 3/8 Inch
- Product Color:
- Grey
- Product Material:
- Zinc Die Cast
Steel City XC 280 – Frequently Asked Questions
1) What cable does the Steel City XC 280 connector work with?
The XC 280 is a 3/8 inch clamp-style connector for armored cable (AC/BX) and flexible metal conduit, and it is also rated for use in direct current applications. The 3/8 inch size is the trade size of the flex or armored cable it clamps, not a conduit thread size.
2) Is the Steel City XC 280 UL listed?
Yes. The connector carries UL file e1383 and CSA 12798, so it is accepted on both sides of the border for AC and flexible metal conduit terminations.
3) Does the XC 280 come with an insulated throat, or do I need anti-short bushings?
There is no insulation on this connector, so for armored cable you still install the red anti-short bushing at the cut end of the BX before landing it in the clamp. If your spec calls for an insulated throat fitting, this is not the one.
4) Is the XC 280 a two screw clamp connector or a squeeze connector?
It is a two screw strap type clamp connector. The cable is captured under a strap tightened by two screws, which is the style inspectors expect on AC and flex terminations where a single squeeze screw is not wanted.
5) What is the XC 280 connector body made of, and can I use it outdoors?
The body is zinc die cast with a grey finish and carries no insulating liner or throat insert. Zinc die cast connectors of this style are dry location, indoor fittings; for wet or damp locations you want a connector specifically listed for that use.
6) Can I order the XC 280 for a DC circuit application?
Yes, the XC 280 is designated for DC use as well as standard AC and flex terminations, which matters on solar, telecom, and battery room work where fittings have to be identified for direct current.
7) Is the XC 280 sold individually or in a bag?
It is sold each, so quantity you order is the number of connectors you get. Order one per cable termination, and remember each connector needs a 1/2 inch knockout in the box or enclosure to land in.
