Steel Crimp Connector, Model 410 18-10 AWG, Keg of 10,000
30-610 - spec sheet
Features
- UL listed to 486C and CSA certified to C22.2 #188; comply with Federal Specification W-S-610E
- Three models cover a wire range from 18 AWG to 4 AWG
- Long-zinc plated steel sleeves maximize contact area with conductors
30-610 - spec sheet
Manufacturer Resources
Spec Sheet
Product Specs
- Product Group:
- Wire Connectors & Terminals
- Department:
- Electrical
- Product Subgroup:
- Wire Connectors
- Ideal Hand Tools U L Listed For Models 410 411 412:
- 30-425, 30-429, 30-430
- parent sku:
- IDL-30-610
- Product Type:
- Crimp Splice
Ideal Industries 30-610 – Frequently Asked Questions
1) What wire sizes does the IDEAL 30-610 Model 410 crimp connector handle?
The Model 410 steel crimp sleeve covers 18 AWG through 10 AWG conductors. If your splice is heavier than 10 AWG, you need a larger sleeve in the family: the 410, 411 and 412 models together span 18 AWG down to 4 AWG.
2) Which crimp tool do I need for IDEAL Model 410 sleeves?
Use an IDEAL hand tool that is UL listed for the 410, 411 and 412 sleeves: tool numbers 30-425, 30-429 and 30-430. Crimping these sleeves with a generic plier is what gets a splice failed on inspection, since the UL listing covers the sleeve and the approved tool together.
3) Is the IDEAL 30-610 crimp sleeve UL listed and CSA certified for commercial work?
It is UL listed to 486C and CSA certified to C22.2 #188, and it complies with Federal Specification W-S-610E. The federal spec compliance is the one that matters on government and institutional jobs where the submittal calls it out by number.
4) Do IDEAL 410 steel crimp sleeves work on both copper and insulated splices in a junction box?
These are bare long zinc-plated steel sleeves, so they carry no insulation of their own. The long sleeve body maximizes contact area with the conductors, but you have to insulate the finished splice separately with tape or a cap. If you want an insulated splice in one step, a twist-on wire connector is the simpler choice for 18-10 AWG branch circuit work.
5) How many connectors come in the IDEAL 30-610 keg?
Part number 30-610 is a keg of 10,000 Model 410 sleeves. That is a bulk production pack, aimed at panel shops, fixture assembly, and crews doing repetitive splicing. For a small punch list, buy a smaller count of the same 410 sleeve rather than a keg.
6) Can I splice two different wire gauges together with the IDEAL Model 410?
Yes, as long as every conductor going into the sleeve falls in the 18 to 10 AWG range and the total conductor fill matches what the approved IDEAL tool die is listed for. The sleeve itself is rated across that 18-10 band, so a 14 to 12 AWG combination is within range; a 10 to 8 AWG combination is not and needs the larger sleeve in the series.
