Panduit EV18-10FB-Q StrongHold...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.49
$28.57
Panduit EV18-10FB-Q StrongHold, EV18-10FB-Q Loose Piece Fork, Red, Vinyl, 1/5" Stud, 22-18 AWG, PK25

Panduit EV18-10FB-Q StrongHold Fork Terminal, 22-18 AWG, Red Vinyl Insulated, #10 Stud

(No reviews yet) Write a Review

Model: EV18-10FB-Q

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.49
$28.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit EV18-10FB-Q StrongHold Fork Terminal, 22-18 AWG, Red Vinyl Insulated, #10 Stud

The Panduit EV18-10FB-Q StrongHold Fork Terminal is a red vinyl insulated, tin-plated copper connector engineered for 22-18 AWG wire applications terminating on a #10 stud. Rated to a maximum of 600V and 221°F operating temperature, this fork terminal is UL Listed and CSA Certified for dependable performance in panel wiring, control circuits, and grounding connections. Each package contains loose piece terminals ready for professional crimping.

Key Features

  • Wire Range: Accepts 22-18 AWG conductors for versatile electrical connection applications.
  • #10 Stud Compatibility: Sized for secure mechanical and electrical connection to standard #10 studs.
  • Tin-Plated Copper Construction: Delivers excellent conductivity and long-term corrosion resistance.
  • Red Vinyl Insulation: Provides color-coded wire identification and electrical protection up to 221°F.
  • 600V Maximum Voltage Rating: Supports standard electrical system voltages with reliable insulation performance.
  • Funnel Entry Barrel Design: Eases wire insertion and promotes consistent, repeatable crimping.

Certifications & Compliance

  • UL Listed (UL587-H)
  • CSA Certified (CSA LR31212)
  • RoHS Compliant

Technical Specifications

  • Color Code: Red
  • Maximum Copper Conductor Size AWG: 18
  • Minimum Copper Conductor Size AWG: 22
  • Maximum Voltage V: 600
  • Maximum Operating Temperature F: 221
  • Minimum Operating Temperature F: 221
  • Stud Hole Size In: #10
  • Insulation Diameter Mm: 3.8
  • Overall Width Mm: 8.9
  • Tongue Width Mm: 8.9
  • Wire Strip Length Mm: 7.9
  • Std Pkg Qty: 25

Typical Applications

  • Electrical Panel Connections
  • Control Circuit Wiring
  • Equipment Grounding Applications
  • Industrial Machinery Connections
  • Commercial Building Systems
  • Maintenance and Repair Operations

Why Panduit?

Panduit StrongHold fork terminals combine tin-plated copper construction with red vinyl insulation to deliver UL Listed and CSA Certified performance for demanding electrical environments. RoHS compliance and a funnel entry barrel design support reliable, code-compliant wire termination for professional installations.

Manufacturer Resources

Product Specs

Barrel Length In :
0.47
Barrel Length Mm :
11.8
Barrel Type:
Funnel Entry
Base Material:
Copper
Color Code:
Red
Country Of Origin:
Mexico
Ean:
6.13056E+11
Finish Coating:
Tin-Plated
Flammability Rating:
UL587-H
Fork Type:
Standard
Gtin Carton:
5.06131E+13
Gtin Package:
6.13056E+11
Hazardous Material Flag:
N
Insulation Diameter In :
0.15
Insulation Diameter Mm :
3.8
Insulation Material:
Vinyl
Maximum Copper Conductor Size Awg :
18
Maximum Copper Conductor Size Awg Sol :
18
Maximum Copper Conductor Size Awg Str :
18
Maximum Metric Conductor Size Mm :
1
Maximum Operating Temperature C :
105
Maximum Operating Temperature F :
221
Maximum Voltage Kv :
0.6
Maximum Voltage V :
600
Maximum Wire Insulation Diameter In :
0.15
Maximum Wire Insulation Diameter Mm :
3.8
Maximum Wire Size Awg :
18
Mercury Content Indicator:
N
Min Order Qty:
250
Minimum Copper Conductor Size Awg :
22
Minimum Copper Conductor Size Awg Sol :
22
Minimum Copper Conductor Size Awg Str :
22
Minimum Metric Conductor Size Mm :
0.5
Minimum Operating Temperature C :
105
Minimum Operating Temperature F :
221
Minimum Voltage Kv :
0.6
Minimum Voltage V :
600
Minimum Wire Size Awg :
22
Overall Length In :
0.93
Overall Length Mm :
23.6
Overall Width In :
0.35
Overall Width Mm :
8.9
Packaging Type:
Loose Piece
Pallet Quantity:
0
Pallet Volume:
0
Pallet Weight:
0
Product Segment:
IEI
Product Type:
Fork Terminal
Reach Status:
N
Rohs Compliant:
Compliant
Seam Type:
Butted
Standard Carton Volume Ft3:
0.1031
Standard Carton Weight Pounds:
0.675
Standard Package Volume Ft3:
0.0103
Standard Package Weight Pounds:
0.0675
Std Carton Height In:
4.35
Std Carton Height Mm:
110.49
Std Carton Length In:
9.1
Std Carton Length Mm:
231.14
Std Carton Width In:
4.4
Std Carton Width Mm:
111.76
Std Ctn Qty:
250
Std Package Height In:
0.6
Std Package Height Mm:
15.24
Std Package Length In:
4.55
Std Package Length Mm:
115.57
Std Package Width In:
3.15
Std Package Width Mm:
80.01
Std Pkg Qty :
25
Std Pkg Uom:
Piece
Stud Hole Size In :
#10
Stud Hole Size Mm :
4.8
Stud Size:
#10
Tongue Length In :
0.47
Tongue Length Mm :
11.8
Tongue Thickness In :
0.03
Tongue Thickness Mm :
0.8
Tongue Width In :
0.35
Tongue Width Mm :
8.9
Wire Strip Length In :
16-May
Wire Strip Length Mm :
7.9
Department:
Electrical
Product Group:
Wiring Devices
Pack Size:
25

Panduit EV18-10FB-Q – Frequently Asked Questions

1) Is this fork terminal rated for 600V control panel wiring?
Rated to 600V maximum, with a 105 C (221 F) operating temperature on the vinyl insulation. That covers typical control circuits, panel wiring and equipment grounding. It carries a UL587-H flammability rating and is RoHS compliant.
2) How much insulation should I strip before crimping this Panduit red fork terminal?
Strip 7.9 mm of jacket. The barrel is 11.8 mm long with a funnel entry, so the strip length lets the conductor bottom out without copper standing proud past the crimp. Look down the inspection side of the barrel after crimping and confirm strands are visible at the end.
3) How many Panduit EV18-10FB-Q terminals come in a pack, and what is the minimum order?
They come loose piece, 25 to a package, 250 per standard carton. Minimum order quantity is 250, so you are buying by the carton rather than the single bag.
4) Should I use a fork terminal or a ring terminal on my panel screws?
Use the fork when you want to land or pull a wire without fully removing the screw, which is most terminal block and panel work. Use a ring where vibration or code practice calls for a captive connection that cannot slip out under a loosened screw, such as many equipment ground points. The EV18-10FB-Q is a standard fork type sized for a #10 stud on 22-18 AWG.
5) Will a tin-plated copper terminal hold up on grounding connections in a damp industrial plant?
The body is copper with a tin plating, which is the normal choice for corrosion resistance on a crimp lug and keeps contact resistance low over time. The barrel is a butted seam rather than brazed, so it should be crimped with a die matched to a 22-18 AWG insulated terminal, not squashed with pliers.
