Strut Clamp 1 pc 1-1/2" - 1-1/4" (Box 50)
Features
- One Piece Strut Clamps For EMT/Rigid Conduit
- Requires only a screwdriver or nutdriver for installation
- No screws or bolts to drop
- Soft wide saddle supports cable conduit & pipes
Additional Notes
- other sizes and quantities available by request
Manufacturer Resources
Product Specs
- Arra Compliant:
- C
- Buy American Compliant:
- C
- Division:
- Electrical H1
- Fastener Length:
- 1/1/02
- Fastener Width:
- 1/1/02
- Language Code:
- EN
- Order Minimum Imperial:
- 50
- Order Minimum Uom Imperial:
- CT
- Pack Type:
- Box
- Product Group:
- Electrical Hardware
- Product Height:
- 3.25 in
- Product Length:
- 7.25 in
- Product Weight:
- 9.5 lbs
- Product Width:
- 6.75 in
- Sub Division:
- Electrical-E H2
- Department:
- Electrical
- Product Subgroup:
- Conduit Clamps
- Product Type:
- Strut Clamp
- Type2:
- Strut Clamp
- Product Finish:
- Galvanized
- Product Details:
- Strut Clamp
- Product Material:
- Steel
Metallics 1PSC150 – Frequently Asked Questions
1) What conduit size does the Metallics 1PSC150 strut clamp hold?
The 1PSC150 is sized for 1-1/2 inch EMT or 1-1/4 inch rigid conduit. Metallics one piece strut clamps are built to that dual designation because EMT and rigid of those trade sizes share the same outside diameter, so one saddle covers both. If you are running a different trade size, you need a different clamp in the series.
2) Do I need extra bolts or nuts to mount a Metallics 1PSC150 strut clamp to the channel?
No separate hardware. It is a one piece clamp, so there are no loose screws, bolts or spring nuts to assemble or drop off a ladder. Installation takes a screwdriver or nutdriver and nothing else, which is why these go up fast on long overhead runs.
3) Does the Metallics 1PSC150 strut clamp meet Buy American and ARRA requirements for a federally funded job?
Yes. The 1PSC150 is flagged as both Buy American compliant and ARRA compliant, which is what a government, school district or transit procurement officer needs on the submittal.
4) How many Metallics 1PSC150 clamps come in a box, and can I buy fewer?
They ship as a box of 50, and 50 is the order minimum, counted in each. That is the smallest quantity sold, so plan the run in multiples of 50.
5) Is a galvanized strut clamp like the 1PSC150 okay for a damp or unheated space?
The 1PSC150 is steel with a galvanized finish, which is the normal choice for parking garages, mechanical rooms, loading docks and other damp or unconditioned interior locations. For direct coastal exposure or corrosive process areas, stainless strut hardware is the usual step up.
6) Should I use a strut clamp or a one hole strap for supporting conduit?
A strut clamp like the 1PSC150 is for conduit carried on channel, so the run is supported off a trapeze or wall mounted strut rather than fastened straight to the structure. If you are anchoring conduit directly to masonry, deck or stud, a one hole or two hole strap is the right part instead. The advantage of the strut clamp is that it slides anywhere along the channel, so spacing and future additions are easy to adjust.
7) Will a strut clamp damage or dent the conduit it holds?
The clamp uses a soft wide saddle, so the load is spread across the conduit wall instead of pinching a narrow band. That matters most on thin wall EMT and on cable or pipe runs, where a narrow strap can crush or deform the run when tightened down.
8) How much does a box of 50 Metallics 1PSC150 strut clamps weigh?
A box of 50 comes in at 9.5 lbs, with the carton measuring 7.25 by 6.75 by 3.25 inches. Useful if you are staging several sizes on a cart or shipping to a job trailer.
