Topaz Lighting EMT Special Rad...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$270.57
Topaz Lighting EMT Special Radius Elbow

Topaz Lighting EMT Special Radius Elbow

(No reviews yet) Write a Review

Model: TOP-8836

In Stock (leaves warehouse same day if ordered before 3pm ET)

$270.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Topaz Lighting Schedule 40 PVC 45° Special Radius Elbow, Plain End

The Topaz Lighting Schedule 40 PVC 45° Special Radius Elbow is engineered to enable smooth, reliable connections between straight lengths of conduit while accommodating virtually any design configuration change in your raceway system. Available in 1-1/2" trade size with a 24" radius and a 45° angle, this elbow is manufactured from rugged, noncorrosive, and nonconductive Schedule 40 PVC, making it an ideal solution for both above-ground and below-ground electrical conduit installations. The cleanly finished plain spigot ends on both sides ensure straightforward, secure assembly with standard Schedule 40 PVC conduit and fittings. Topaz Lighting offers one of the largest selections of Schedule 40 PVC Special Radius Elbows, giving contractors and engineers the flexibility to meet demanding project specifications.

Key Features

  • Trade Size & Dimensions: 1-1/2" trade size with a 24" special radius and 45° angle, providing generous sweep for low-friction wire pulling and smooth conduit routing.
  • Durable Construction: Manufactured from Schedule 40 PVC — rugged, noncorrosive, and nonconductive — delivering long-lasting performance in demanding environments without risk of rust or galvanic corrosion.
  • 45° Special Radius Configuration: The 45° angle and extended 24" radius accommodate complex layout changes and long conduit runs, reducing wire-pulling tension compared to standard-radius elbows.
  • Plain Spigot Ends: Both ends feature clean, plain spigot finishes for easy solvent-cement joining to standard Schedule 40 PVC conduit and fittings, ensuring a secure, code-compliant connection.
  • Above & Below Ground Suitability: Rated for use in both above-ground and below-ground conduit installations, offering versatility across a wide range of commercial, industrial, and utility applications.
  • Nonconductive Material: PVC construction provides inherent electrical nonconductivity, eliminating the need for bonding or grounding of the fitting itself.

Certifications & Compliance

  • cULus Approved
  • Schedule 40 PVC — Suitable for Above and Below Ground Use

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Typical Applications

  • Commercial and Industrial Electrical Conduit Raceway Systems
  • Underground Conduit Installations and Duct Banks
  • Above-Ground Exposed Conduit Runs Requiring Direction Changes
  • Utility and Infrastructure Electrical Distribution Projects
  • New Construction and Renovation Electrical Rough-In Work
  • Corrosive or Moisture-Prone Environments Where Metallic Conduit Is Unsuitable

Why Topaz Lighting?

Topaz Lighting is recognized for carrying one of the largest selections of Schedule 40 PVC Special Radius Elbows, ensuring contractors and engineers can source the exact fitting needed for any project configuration. Each elbow is manufactured from rugged, noncorrosive, and nonconductive Schedule 40 PVC and carries cULus approval, confirming compliance with North American electrical safety standards. Topaz Lighting's commitment to quality materials and broad product availability makes them a trusted partner for professional electrical installations across commercial, industrial, and utility sectors.

Product Specs

Product Type:
Elbow
Conduit Type:
PVC Schedule 40
Connection Type:
Plain End (Spigot)
Listing:
cULus Approved
Department:
Electrical
Product Group:
Conduit & Raceway
Product Subgroup:
Conduit Bodies & Fittings
Product Material:
PVC

Topaz Lighting TOP-8836 – Frequently Asked Questions

1) Are the ends on the Topaz 8836 PVC elbow threaded or plain?
Plain end, spigot on both sides. The Topaz 8836 special radius elbow is joined with solvent cement into standard Schedule 40 PVC conduit and couplings, so no thread engagement and no bushings are involved. Clean and prime both spigots and the mating socket before cementing.
2) What size and angle does the Topaz 8836 special radius elbow come in?
The 8836 is the 3 inch, 90 degree configuration of the Topaz special radius elbow line.
3) Can a Topaz PVC special radius elbow be direct buried, or is it above ground only?
Both. The Topaz Schedule 40 PVC special radius elbow is rated for above-ground and below-ground conduit installations, which covers duct bank and direct-buried runs as well as exposed raceway. PVC will not rust or set up galvanic corrosion, so it holds up in wet and chemically aggressive locations where steel conduit fittings do not.
4) Do I need to bond or ground this PVC elbow?
No. PVC is nonconductive, so the fitting itself takes no bonding jumper. Equipment grounding for the circuit is carried by the equipment grounding conductor pulled in the raceway, not by the conduit.
5) Why use a special radius elbow instead of a standard sweep on a long conduit run?
A special radius elbow gives a much wider sweep than a standard factory bend, which lowers sidewall pressure and pulling tension on the conductors. On long runs, large feeder cable, or anywhere the pull already has several bends in it, that wider radius is what keeps the pull inside tension limits and protects the jacket. For a short run with small conductors, a standard radius elbow is usually enough.
