TRIMCO 1741 1" DIAMETER PUSH BAR E MOUNTING STANDARD OVERVIEW
1741 1" Diameter Push Bar E Mounting Standard. 1" dia. Push Bar E Mounting Standard.
Trimco’s 1700 Series Push/Pull Bars & Sets are manufactured in the United States from solid stainless steel, bronze or brass. These heavy duty bars are available with a multitude of mounting options for most applications including steel, wood and glass doors. Available in most architectural finishes, the Trimco 1700 Series Bars are also offered with a fOCAL designer series option.
Buy the TRIMCO 1741 Series today to add a stylish hardware for your home!
TRIMCO 1741 1" DIAMETER PUSH BAR PRODUCT FEATURES
- Manufactured in the United States from solid stainless steel, bronze and brass.
- Options include 3/4″, 1″ and 1-1/4″ diameter material and 10″, 12″ or 18″ pulls.
- fOCAL designer option available.
- Multiple mounting options for metal, wood and glass doors.
- Must specify CTC on bars. Custom sizes and finishes also available.
APPLICATIONS
- Commercial & Industrial Buildings
- Government & Military Facilities
- Multifamily & Mixed-Use
- Public Buildings & Facilities
- Retail & Strip Malls
TRIMCO 1741 SERIES COLOR VARIATIONS
Trimco 1741 1" Diameter Push Bar E Mounting Standard Bright Brass (605)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Satin Brass (606)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Oil Rubbed Bronze (613)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Dark Oxidized Satin Bronze (613E)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Matte Black (622)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Bright Chrome (625)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Satin Chrome (626)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Satin Aluminum (628)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Bright Stainless Steel (629)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Satin Stainless Steel (630)
Trimco 1741 1" Diameter Push Bar E Mounting Standard Healthy Hardware Steralloy Silver (710CU)
TRIMCO 1700 SERIES COLLECTION
Trimco 1729 3/4" Diameter Push/Pull Bar Set 10" CTC Straight Pull
Trimco 1731 1" Diameter Push/Pull Bar Set 10" CTC Straight Pull
Trimco 1732 1" Diameter Push/Pull Bar Set 12" CTC Straight Pull
Trimco 1737 1" Diameter 90º Offset Push/Pull Bar Set 10" CTC Offset Pull
Trimco 1738 1" Diameter 90º Offset Push/Pull Bar Set 12" CTC Offset Pull
Trimco 1740 3/4" Diameter Push Bar E Mounting Standard
Trimco 1741 1" Diameter Push Bar E Mounting Standard
Trimco 1745 1-1/4" Diameter Push Bar E Mounting Standard
Trimco 1746 1-1/4" Diameter Push/Pull Bar Set 18" CTC Straight Pull
Trimco 1746-1 1-1/4" Diameter Push/Pull Bar Set 12" CTC Straight Pull
Trimco 1747 1-1/4" Diameter 90º Offset Push/Pull Bar Set 18" CTC Offset Pull
Trimco 1747-1 1-1/4" Diameter 90º Offset Push/Pull Bar Set
RESOURCES & DOWNLOADS
Manufacturer Resources
Product Specs
- Commercial/Residential:
- Commercial
- Product Group:
- Door Trim and Accessories
- Product Subgroup:
- Door Pulls, Push and Pull Plates
- Product Type:
- Door Pulls
- Subcategory:
- Door Pulls, Push and Pull Plates
- Healthy Hardware:
- Yes
- Product Diameter:
- 1"
- Product Dimension:
- 1" Diameter
- Product Category:
- Door Trim and Accessories
- Department:
- Door Hardware
Trimco TRI-1741E-12.605 – Frequently Asked Questions
1) What mounting options does the Trimco 1741 push bar come in, and which one do I need for a glass door?
The 1741 push bar is offered in two mounting styles, E-Mount and G-Mount. Trimco's 1700 Series bars carry mounting options covering steel, wood and glass doors, so the door substrate is what drives the choice. Pick the mounting first, then the length and finish, because all three are separate selections on the order.
2) What lengths does the Trimco 1741 push bar come in?
Five lengths: 12, 18, 24, 30 and 36 inches. On a standard commercial entrance, a 30 or 36 inch bar spans most of the door width and gives a push point that works whether someone hits it high or low. Shorter 12 and 18 inch bars suit narrow leaves and interior openings. Trimco requires CTC to be specified on bars, so confirm your center-to-center along with the length.
3) Will the Trimco 1741 match the other door hardware finishes in my building?
Eleven architectural finishes are available on the 1741: bright brass (605), satin brass (606), oil rubbed bronze (613), dark oxidized satin bronze (613E), matte black (622), bright chrome (625), satin chrome (626), satin aluminum (628), bright stainless (629), satin stainless (630) and Healthy Hardware Steralloy Silver (710CU). Those BHMA finish numbers are the same codes used across commercial door hardware, so 630 on this bar lines up with 630 on your closers, hinges and plates.
4) Do I need a push bar or a push/pull bar set for my door?
A push bar like the 1741 mounts on the push side only. If you need a pull on the opposite face of the same door, Trimco's 1700 Series covers that with bar sets instead: the 1731 (1 inch, 10 inch CTC straight pull) and 1732 (1 inch, 12 inch CTC straight pull) in the same 1 inch diameter, or the 1737 and 1738 if you want a 90 degree offset pull at 10 or 12 inch CTC. Single-acting entrances usually get a push on one side and a pull on the other, so order the set rather than two separate pieces.
5) What do I have to specify when ordering a Trimco 1741 push bar?
Four things: diameter is fixed at 1 inch on the 1741, then you choose mounting (E-Mount or G-Mount), length (12, 18, 24, 30 or 36 inches) and finish. Trimco also states that CTC must be specified on bars, so the center-to-center dimension goes on the order. Custom sizes and finishes outside the standard list are available from Trimco if the opening needs them.
6) I need a pull that clears the door face for gloved hands or ADA. Is the Trimco 1741 the right pick?
The 1741 is a straight bar on E or G mounting, not an offset. If you need extra knuckle clearance or an ADA compliant offset, look at the Ives 8145EZHD, a 45 degree offset pull with heavy duty mounting hardware that ABH lists as ADA compliant in the EZ series, or the Ives 8102HD, a heavy duty straight pull with 1-1/2 inch clearance stated. Within Trimco's own 1700 Series, the 1737 and 1738 are 90 degree offset push/pull bar sets at 10 and 12 inch CTC.
7) What is the closest equivalent to a Trimco 1741 push bar in a 1 inch round bar from another maker?
The Ives 8103HD is the nearest match on bar section: it is a heavy duty straight door pull with a 1 inch round bar and through bolt mounting, and the Trimco 1741 is likewise a 1 inch diameter push bar. The Trimco 1741 is a single push bar offered in 12, 18, 24, 30 and 36 inch sizes with E-Mount or G-Mount, so the practical difference is that the Trimco covers a longer size range on one part number while the Ives 8103HD is specified as a through bolt pull. ABH also builds a 1.00 inch diameter straight flat end commercial door pull as the AB3300.
8) The door needs an offset pull rather than a straight push bar - what should be used instead of the Trimco 1741?
The Trimco 1741 is a straight 1 inch diameter push bar, so an opening that calls for an offset requires a different part. The Ives 8169 is a C style offset solid door pull in 1 inch diameter with heavy duty mounting, which keeps the same bar diameter while changing the geometry. The Ives 8145EZHD is a 45 degree offset pull with heavy duty mounting hardware, described as an ADA compliant EZ series pull. ABH offers offset pulls as the AB3310 flat end and the AB3330 round end, the latter with custom length options.
9) What is the Trimco 1741 push bar made of and is it heavy enough for a high traffic entrance?
Trimco's 1700 Series bars are made in the United States from solid stainless steel, bronze or brass, and Trimco calls them heavy duty. They are specified into commercial and industrial buildings, government and military facilities, multifamily and mixed use, public buildings and retail. Solid bar stock rather than tube is what holds up when a door gets hit hundreds of times a day.
10) Is the Trimco 1741 push bar suitable for a healthcare facility?
The 1741 is offered in Healthy Hardware Steralloy Silver (710CU), a copper-bearing finish option, and Trimco flags the bar as Healthy Hardware. That is the finish specifiers reach for on patient room and corridor doors where hand contact surfaces matter. The other ten finishes are standard architectural finishes with no antimicrobial claim attached.
11) What is a good alternative to the Trimco 1741 if I want a 1 inch round pull from another brand?
The Ives 8103HD is the closest cross-brand equivalent, a heavy duty straight door pull in 1 inch round with through bolt mounting. The ABH AB3300 is another 1.00 inch diameter straight pull, with flat ends rather than the Trimco profile. If you want an offset rather than a straight bar, the Ives 8169 is a C style offset solid pull in 1 inch diameter. All three are 1 inch bar stock, so grip feel is comparable and the difference is end style, offset and mounting method.
12) Does the Trimco 1741 push bar come as a back-to-back set for both sides of the door?
No. The 1741 is a single push bar in E Mounting Standard, one face of the door. For a true back-to-back arrangement mounted through the door, the Deltana SSPOBB24 24 inch back-to-back modern offset pulls or the SSPORBB24 24 inch back-to-back round offset pulls are configured that way out of the box. Within Trimco's 1700 Series, pairing a push with a pull means ordering one of the push/pull bar sets, such as the 1746 at 18 inch CTC in 1-1/4 inch diameter.
13) For a single 12 inch pull on a light commercial door, what is a simpler alternative to the Trimco 1741?
The Deltana SSP1210 is a 12 inch contemporary pull, single side, which covers a one face application at the same 12 inch length the Trimco 1741 offers as its shortest size. Sure-Loc also builds single sided long pulls in three bar profiles: the PL-1RD round, the PL-1SQ square, and the PL-1KN knurled, and the round and square are offered with concealed or thru bolt mounting. The Trimco 1741 is a commercial product in a 1 inch diameter bar with E-Mount and G-Mount options.
14) Is there a slimmer bar than the Trimco 1741 for a lighter door?
The Trimco 1741 uses a 1 inch diameter bar. For a lighter section, the ABH AB7200 is a solid stainless steel flat end pull handle in 7/8 inch diameter with through-bolt mounting, and the Ives 8102HD is a heavy duty straight pull built on a 3/4 inch round bar with 1-1/2 inch clearance. Both step the bar down from the 1 inch section while staying in a straight pull format.
15) Which of these pulls is offered in an antimicrobial finish for a healthcare or hospitality door?
The Trimco 1741 is offered in 710CU Healthy Hardware Steralloy Silver alongside its standard architectural finishes such as Matte Black 622 and Satin Stainless Steel 630, and it carries the Healthy Hardware designation. Comparable straight and offset pulls including the Ives 8103HD, the ABH AB3300 and the Sure-Loc PL-1RD are specified on bar profile and mounting rather than on a copper alloy touch surface, so for a touch surface requirement the 710CU option on the Trimco 1741 is the one that answers it.
16) Which pull should be specified when the length has to be something other than a standard size?
The Trimco 1741 is stocked in 12, 18, 24, 30 and 36 inch sizes, and Trimco states that custom sizes and finishes are available and that CTC must be specified on bars. Among other makers, the ABH AB3330 offset round end pull is offered with custom length options. Both routes handle a nonstandard length; the difference is that the Trimco 1741 is a straight bar and the ABH AB3330 is an offset round end.
