Eaton Type LA Tri-Pac Circuit Breaker Trip Unit, Three-Pole, 200A

Eaton Type LA Tri-Pac Circuit Breaker Trip Unit, Three-Pole, 200A

(No reviews yet) Write a Review

Model: LA3200PT

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,748.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Type LA Tri-Pac Circuit Breaker Trip Unit, Three-Pole, 200A

The Eaton Type LA Tri-Pac circuit breaker trip unit is a three-pole, 200A thermal-magnetic trip unit rated 600 Vac / 250 Vdc, engineered for use within Eaton's Type LA Tri-Pac frame circuit breaker system. This trip-unit-only component features an interchangeable thermal-magnetic trip type with a magnetic trip range of 1000-2000A and carries a 200 kAIC interrupt rating at 600 Vac, making it well suited for demanding industrial and commercial power distribution systems. The unit is UL 489 certified for code-compliant performance in professional electrical installations.

Key Features

  • Amperage Rating: 200A trip unit for dependable overcurrent protection in three-pole circuits.
  • Three-Pole Configuration: Three-pole design supports balanced multi-phase circuit protection.
  • Voltage Rating: Rated 600 Vac / 250 Vdc for a wide range of power distribution applications.
  • Interchangeable Thermal-Magnetic Trip Type: Field-interchangeable trip unit design for the Type LA Tri-Pac frame.
  • Magnetic Trip Range: Adjustable 1000-2000A magnetic trip range for tailored circuit protection.
  • Interrupt Rating: 200 kAIC at 600 Vac for high fault-current withstand capability.
  • Compact Footprint: Measures 5.3 in wide x 5.3 in high x 10.1 in deep for straightforward panel integration.

Certifications & Compliance

  • UL 489 Certified

Technical Specifications

  • Circuit Breaker Type: LA
  • Type: Trip unit only
  • Number of Poles: Three-pole
  • Amperage Rating: 200 A
  • Voltage Rating: 600 Vac, 250 Vdc
  • Magnetic Trip Range: 1000-2000A
  • Trip Rating: 1000-2000 A
  • Interrupt Rating: 200 kAIC at 600 Vac
  • Trip Type: Interchangeable thermal-magnetic
  • Circuit Breaker Frame Type: Trip unit
  • Product Width: 5.3 in
  • Product Height: 5.3 in
  • Product Length/Depth: 10.1 in
  • Certifications: UL 489

Typical Applications

  • Industrial Power Distribution Panelboards
  • Commercial Switchgear and Load Centers
  • Type LA Tri-Pac Frame Circuit Breaker Servicing and Upgrades
  • Three-Phase Motor and Feeder Circuit Protection
  • Retrofit Trip Unit Replacement in Existing Installations

Why Eaton?

Eaton's Type LA Tri-Pac trip units are built for reliable, code-compliant circuit protection, backed by UL 489 certification and a 200 kAIC interrupt rating at 600 Vac. The interchangeable thermal-magnetic trip design gives electrical professionals flexible, field-serviceable overcurrent protection for demanding three-pole, 200A power distribution applications.

Manufacturer Resources

Product Specs

Product Width:
5.3 in
Magnetic Trip Range:
1000-2000A
Voltage Rating:
600 Vac, 250 Vdc
Amperage Rating:
200A
Product Length/Depth:
10.1 in
Circuit Breaker Frame Type:
Trip unit
Product Height:
5.3 in
Product Type:
Circuit Breaker
Number Of Poles:
Three-pole
Trip Rating:
1000-2000 A
Interrupt Rating:
200 kAIC at 600 Vac
Circuit Breaker Type:
LA
Trip Type:
Interchangeable thermal-magnetic
Certifications:
UL 489
Department:
Electrical
Configuration:
3-Pole
Series:
Type LA Tri-Pac
Standards:
UL 489
Product Group:
Circuit Protection
Product Subgroup:
Circuit Breakers
Product Length:
10.1 in
Product Weight:
3 lb

Eaton LA3200PT – Frequently Asked Questions

1) Is the Eaton LA3200PT a complete circuit breaker or just the trip unit?
It is the trip unit only. The LA3200PT is the interchangeable thermal-magnetic trip unit that installs into an Eaton Type LA Tri-Pac frame breaker. You do not get a breaker frame, so if you are building a new installation from scratch you need the LA Tri-Pac frame as well. If you are re-rating or servicing a breaker that is already in the panel, this is the part that changes the rating.
2) What breaker frame does the LA3200PT trip unit fit?
The Eaton Type LA Tri-Pac frame, and only that frame. The trip unit is coded LA and is part of Eaton's Tri-Pac interchangeable trip system, so it will not drop into a different Eaton frame family or another manufacturer's breaker. Confirm the existing breaker is an LA Tri-Pac before ordering.
3) Will a 200A LA trip unit work on a 480V three-phase feeder?
Yes. The trip unit is rated 600 Vac, which covers 480Y/277 and 480 V delta three-phase systems, and it is a three-pole unit for balanced three-phase circuits. It also carries a 250 Vdc rating for DC applications.
4) What does the 1000-2000A magnetic trip range mean on a 200A trip unit?
That is the instantaneous (short-circuit) pickup, not the continuous rating. The unit carries 200A continuously on thermal overload protection, and its magnetic element is adjustable from 1000A to 2000A, roughly 5x to 10x the 200A rating. That adjustment is what lets you ride through motor inrush on a three-phase motor or feeder circuit without nuisance tripping while still clearing a genuine fault.
5) Can I change the amp rating of an existing LA Tri-Pac breaker instead of replacing the whole breaker?
That is exactly what the Tri-Pac design is for. The trip unit is field-interchangeable, so on an existing LA Tri-Pac frame you swap the trip unit to re-rate the breaker rather than pulling and replacing the entire breaker. The LA3200PT sets that frame at 200A, three-pole. For any other amperage you order the matching LA trip unit instead.
6) Is a 200 kAIC interrupt rating enough for a high fault-current service?
200 kAIC at 600 Vac is at the top end of what molded-case breaker assemblies are rated for, so it suits service-entrance and industrial switchgear locations where the available fault current is high. The number you need to beat is the available fault current from your utility or engineered short-circuit study at that point in the system.
7) Is the Eaton LA Tri-Pac trip unit UL listed for branch circuit protection?
It is UL 489 certified. UL 489 is the standard for molded-case circuit breakers used as branch-circuit and feeder overcurrent protection, which is what inspectors and institutional specs call for on panelboard and switchgear work. That is the only listing stated for this unit.
8) How much room do I need in the panel for the LA3200PT?
Plan for 5.3 in wide by 5.3 in high with 10.1 in of depth. The depth is the number that usually decides it, so check the gutter and cover clearance behind the deadfront before you commit, particularly in older switchgear sections.
9) What is the exact Eaton part number for the 200A three-pole LA Tri-Pac trip unit?
Eaton LA3200PT. In the numbering, LA is the frame family, 3 is the pole count and 200 is the amp rating, so a distributor or MRO storeroom can cross-check it against the nameplate on the breaker being serviced.
