Ty-Rap Identification Cable Ties 7.24in Natural Polyamide with Steel Barb Lock

Ty-Rap Identification Cable Ties 7.24in Natural Polyamide with Steel Barb Lock

Professional Cable Management with Integrated Identification

Ty-Rap identification cable ties deliver reliable bundling and labeling solutions for professional electrical installations. These 7.24-inch natural polyamide ties feature stainless steel barb locking mechanism and integrated identification tags positioned adjacent to the bundle for clear marking and organization in demanding applications.

Professional Features & Benefits

• 7.24-inch Length with 45mm Max Bundle Diameter: Accommodates a wide range of cable bundle sizes for versatile installation applications.
• Stainless Steel Barb Lock Mechanism: Provides secure 220N minimum holding force for reliable long-term performance in professional environments.
• Integrated Identification Tag: Adjacent text strip placement enables clear cable marking and organization without additional labeling components.
• Natural Polyamide Construction: Halogen-free material offers durability and chemical resistance across -40 to +85°C operating temperature range.
• UL E49405 Listed: Meets rigorous safety standards with V-2 flammability rating for code-compliant electrical installations.
• Steel Nose Band Closure: Internal toothing design with 4.81mm band width ensures consistent engagement and holding strength.

Technical Specifications

• Band Closure: Steel nose
• Band Width: 4.81mm
• Brand Label: Ty-Rap
• Brand Name: Ty-Rap
• Etim: EC000046 Cable tie
• Flammability According To Ul94: V-2
• Halogen Free: Y
• Idea Granular Category Code Igcc: 5040 >> I.D. Ties
• Igcc: 5040 I.D. Ties
• Inner Quantity: 1000
• Length Belt Tape Tie: 184.15mm
• Lock Mechanism: Stainless Steel Barb
• Lock Type: Stainless Steel Barb
• Material Quality: Polyamide PA
• Max Bundle Diameter: 45mm
• Mil Approval: Y
• Min Holding Force: 220N
• Operating Temperature: -40-+85°C
• Outer Dimensions Inches: 21.2x13.7x9.6
• Outer Quantity: 10000
• Product Color: Natural colour
• Product Details: Identification Tie
• Product Length: 7.24 in ; 184 mm
• Product Model: Internal toothing
• Product Type: Identification
• Product Width: 0.189 in ; 4.8 mm
• Reflective Fluorescent: N
• Solvable Fastener: N
• Standard: UL E49405
• Standards: UL E49405
• Surface Protection: Untreated
• Text Strip: Adjacent to bundle
• Tie Thickness: 1.41mm
• Transparent: N
• Ul Approval: Y
• Unspsc: 39121703 Cable ties
• Uv Stable Acc Astm D6779: N
• Vg Approval: N
• Weight Uom: 1.25 lbs. per 1000
• Department: Elecrtical

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Electrical Panel Organization
• Data Center Cable Management
• Industrial Control Systems
• Commercial Building Infrastructure
• Telecommunications Equipment
• Manufacturing Facility Wiring
• Maintenance and Service Applications

Why Choose Ty-Rap Quality?

Ty-Rap identification cable ties combine proven polyamide construction with UL E49405 listing and MIL approval for reliable performance in professional applications. The halogen-free material and V-2 flammability rating ensure code compliance, while the wide operating temperature range from -40 to +85°C provides dependable service across diverse environmental conditions.
