UNINSUL CU TUBE TERM No16 BOLT M10
Manufacturer Resources
Product Specs
- Country Of Origin:
- Germany (DE)
- Product Subgroup:
- General Terminals
- Product Type:
- Non-Insulated Ring Terminal
- Wire Size:
- 16 mm²
- Department:
- Electrical
- Product Group:
- Wire Termination
- Product Color:
- Metallic
- Product Material:
- Copper
Sta-Kon T16-10-TB – Frequently Asked Questions
1) What wire size does the Sta-Kon T16-10-TB ring terminal take?
The T16-10-TB is sized for 16 mm2 conductor. It is a metric-sized tubular copper lug, so match it to metric cable rather than an AWG build. 16 mm2 sits between 6 AWG and 4 AWG, so an AWG conductor will either be loose or will not enter the barrel.
2) Is the Sta-Kon T16-10-TB insulated?
No. It is a non-insulated (bare) copper tube terminal, so the barrel and tongue are exposed metal after crimping. If the lug sits where phase-to-phase or phase-to-ground clearance is tight, sleeve it with adhesive-lined heat shrink or use an insulated lug instead.
3) Should I use a tubular copper lug or a stamped ring tongue terminal?
A tube terminal like the T16-10-TB has a seamless copper barrel that accepts stranded cable fully and is crimped with a hex or indent die, which is what you want on larger power conductors such as 16 mm2. Stamped ring tongues with a rolled barrel are intended for small control wiring and plier-type crimpers. For panel feeders, motor leads, and battery or busbar landings, the tube lug is the correct type.
4) Will the T16-10-TB work on aluminum cable?
No. It is a copper lug with no stated aluminum or bimetallic rating, so use it on copper conductors only. Aluminum terminations need an AL9CU rated or bimetallic lug.
5) What is the exact part number and who makes the M10 16 mm2 copper tube terminal?
Part number T16-10-TB from Sta-Kon, described as an uninsulated copper tube terminal for No. 16 (16 mm2) conductor with an M10 bolt hole. Country of origin is Germany.
