Sta-Kon RBC727M VIN INS HDTY RNG TRM 16-14 TAPE BLU

The RBC727M takes 16 to 14 AWG stranded or solid copper wire. The blue insulation is the standard color code for that gauge range, so on a panel where crews work by color, blue sleeve means 16-14 AWG. For 22-18 AWG you need a red-coded terminal and for 12-10 AWG a yellow one.

Vinyl. The RBC727M is a vinyl insulated heavy-duty ring terminal, so the sleeve is flexible PVC rather than the stiffer nylon used on high-temperature or high-vibration terminals. Vinyl is fine for general control panel, appliance, and automotive-style terminations; if the termination sits next to a heat source or will flex repeatedly, specify a nylon insulated ring terminal instead.

Use the ring style, like the RBC727M, anywhere the connection must not pull free if the screw loosens: motor studs, ground lugs, battery posts, and vibration-prone equipment. The closed ring captures the fastener completely. A spade or fork terminal slides in and out without removing the screw, which is faster for service work on terminal strips but can back out under vibration. Pick ring for permanence, fork for serviceability.

Crimp it with an insulated-terminal crimping tool using the blue nest, matched to the 16-14 AWG range. Sta-Kon terminals are designed around a controlled-cycle crimp tool, and using the wrong die or plain pliers deforms the barrel and gives you a connection that passes a tug test but fails later. No other hardware is required to make the termination; the terminal goes under an existing stud or screw.

Order Sta-Kon RBC727M. That single model number covers the blue vinyl insulated heavy-duty ring terminal for 16-14 AWG wire, supplied in tape form for reel-fed or production crimping rather than loose bulk pieces.

On the RBC727M it refers to the barrel and tongue construction, a thicker gauge than a standard commercial-grade ring terminal, which is what lets it hold up to repeated torquing on a stud or screw terminal. Buyers standardizing a fleet of panels usually pick the heavy-duty version for anything that gets serviced regularly.

Yes. Country of origin on the RBC727M ring terminal is the United States, which matters for government, transit, and institutional jobs carrying a domestic-content requirement on the submittal.

The RBC727M comes tape mounted, which feeds a bench or pneumatic applicator for volume work. If you are doing a handful of terminations in the field with a hand crimper, loose bulk terminals are easier to work with; the tape strip is aimed at panel shops and assembly runs where terminals are fed in sequence.
