Von Duprin 22NL 3 Grade 1 Rim Exit Device, Wide Stile Pushpad, 36", Nightlatch Pull, Escutcheon Pull, Hex Key Dogging

Von Duprin 22NL 3 Grade 1 Rim Exit Device Wide Stile Pushpad 36" with Nightlatch Pull and Hex Key Dogging

(No reviews yet) Write a Review

Model: 22NL-3 689
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$760.00
$505.88
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Von Duprin 22NL 3 Grade 1 Rim Exit Device Wide Stile Pushpad 36" with Nightlatch Pull and Hex Key Dogging

Commercial-Grade Panic Exit Hardware for Single and Double Door Applications

The Von Duprin 22NL 3 is a Grade 1 Rim Exit Device engineered for demanding commercial environments including clinic/healthcare, multi-family, and retail/commercial markets. Ideal for back door employee entrances and parking garage stairwells, this 36" wide stile pushpad device is UL Listed for Panic Exit Hardware and meets ANSI A156.3, 2008 Grade 1 standards. Compatible with all types of single and double doors with mullion, the 22 Series fits door stiles as narrow as 3 13/16" (97 mm) and covers stock hollow metal doors with 161* cutouts. The device is non-handed for simplified installation flexibility.

Professional Features & Benefits

  • ANSI Grade 1 Certification: Meets ANSI A156.3, 2008 Grade 1 standards and is UL Listed for Panic Exit Hardware, ensuring code-compliant performance in commercial and institutional applications.
  • Wide Stile Compatibility: Fits door stiles as narrow as 3 13/16" (97 mm), accommodating a broad range of door configurations including hollow metal doors with 161* cutouts.
  • Precise Dimensional Specifications: Center case dimensions of 4 1/4" (108 mm) x 1 3/8" (41 mm) x 2 3/8" (60 mm); mechanism case dimensions of 2" (51 mm) x 3 3/4" (95 mm); device centerline from finished floor at 39 13/16" (1011 mm), or 39 11/16" (1008 mm) with mullion.
  • Deadlocking Latch Bolt: Features a deadlocking latch bolt with a 3/4" (19 mm) throw for reliable door security and positive latching performance.
  • Push Bar Projection: Push bar neutral projection of 3 3/4" (95 mm) and depressed projection of 3" (76 mm) for ergonomic, code-compliant egress operation.
  • Hex Key Dogging Standard: Ships with hex key dogging as standard, with a less dogging (LD) option available for applications requiring alternative configurations.
  • Multi-Function Versatility: Ships ready for all functions including EO, DT, NL, TP, K, and L, providing maximum flexibility for varied access control requirements.
  • Flexible Device Lengths: Available in 3' (914 mm) and 4' (1219 mm) lengths to accommodate standard commercial door widths.
  • Comprehensive Electric Options: Compatible with LX latchbolt monitor switch, RX pushpad monitor switch, RX2 double pushpad monitor switch, ALK alarm exit kit, and CON Allegion Connect for electrified access control integration.
  • Mechanical Options Available: Supports GBK glass bead kit and AX accessible device options for expanded application suitability.
  • Included Fasteners: Includes 1 3/4" (44 mm) and 2 1/4" (57 mm) fasteners and sex bolts (SNB) for wood and metal doors; optional SNB available for the device.
  • Strike Included: Comes with a 299 dull black strike for complete out-of-box installation readiness.

Technical Specifications

  • Subcategory: Parts and Accessories
  • Product Group: Exit Device Trims
  • Product Subgroup: Parts and Accessories
  • Product Category: Exit Device
  • Department: Door Hardware

Professional Applications

  • Clinic and Healthcare Facilities
  • Multi-Family Residential Buildings
  • Retail and Commercial Establishments
  • Parking Garage Stairwells and Emergency Exits
  • Back Door and Employee Entrance Applications
  • Educational Institutions
  • Government and Municipal Buildings

Why Choose Von Duprin Quality?

Von Duprin 22 Series Rim Exit Devices are built to meet the rigorous demands of commercial door hardware applications, carrying UL Listing for Panic Exit Hardware and ANSI A156.3, 2008 Grade 1 certification for verified performance and code compliance. The non-handed design, multi-function capability, and broad compatibility with electric and mechanical options make the 22NL 3 a versatile solution for a wide range of commercial and institutional environments. Engineered for dependable, long-term performance where reliable egress hardware is essential.

Manufacturer Resources

Von Duprin 98/99 Series Catalog

Product Specs

Subcategory:
Parts and Accessories
Product Group:
Exit Device Trims
Product Subgroup:
Parts and Accessories
Product Category:
Exit Device
Department:
Door Hardware

Von Duprin 22NL-3 689 – Frequently Asked Questions

1) Will the Von Duprin 22NL rim exit device fit a narrow aluminum stile door?
The 22 Series is a wide stile device, but it goes down further than most: it fits stiles as narrow as 3 13/16 inches (97 mm). Anything narrower than that needs a true narrow stile device instead. On hollow metal, it covers stock doors with 161 cutouts, so you are not patching the old cylindrical prep.
2) Can a rim exit device like the 22NL be used on a pair of doors?
Yes, with a mullion. A rim device latches into a strike on the frame or mullion, so on a pair you need a removable or fixed mullion between the leaves for the 22 to have something to catch. The 22 Series works on all types of single and double doors with mullion. If you cannot have a mullion in the opening (moving wide equipment through it, for example), you want a vertical rod device instead, not this one. Centerline height from finished floor is 39 13/16 inches, or 39 11/16 inches when used with a mullion.
3) What does the NL in Von Duprin 22NL mean, and what trim comes with it?
NL is the nightlatch function: the outside pull with a cylinder retracts the latch for entry, while the inside pushpad always allows free egress. The 22NL 3 ships with the nightlatch pull (escutcheon style). You still need to supply the mortise cylinder to key it into your system. The device body itself ships ready for all functions, EO (exit only), DT (dummy trim), NL, TP, K, and L.
4) Will the 22 rim device latch into my existing rim strike?
It comes with its own 299 dull black strike, and that is what the device is set up to latch into. The latchbolt is deadlocking with a 3/4 inch (19 mm) throw. Unless your existing strike is a matching rim strike at the same height, plan on installing the 299 that ships in the box.
5) Can you hold the 22NL unlocked during business hours?
Yes. Hex key dogging is standard, so you depress the pushpad and set it with the hex key to keep the latch retracted for daytime traffic, then release it at close. If the opening is fire rated, dogging is not permitted and you order the LD (less dogging) option instead.
6) Does the 22NL exit device need to be ordered handed?
No. The 22 Series is non-handed, so one device covers either swing. You do not have to determine hand before ordering, and stocking one unit covers both leaves of a pair.
7) How much does a 22 Series pushpad stick out into the doorway?
Push bar neutral projection is 3 3/4 inches (95 mm), dropping to 3 inches (76 mm) when depressed. That figure matters when you are checking clearance in a tight stairwell or vestibule where the door swings against a wall or adjacent equipment. Center case measures 4 1/4 x 1 3/8 x 2 3/8 inches and the mechanism case 2 x 3 3/4 inches.
8) What device length do I order for a 36 inch door?
The 22NL 3 is the 3 foot (914 mm) device, sized for door widths up to 36 inches. A 4 foot (1219 mm) size covers wider leaves. Order by the actual door width, not the frame opening.
9) Can the 22 Series rim device be tied into an access control or alarm system?
Yes. Electric options include the LX latchbolt monitor switch, RX pushpad monitor switch, RX2 double pushpad monitor switch, the ALK alarm exit kit for local alarm on unauthorized use, and CON Allegion Connect. These are ordered as options on the device, so specify them up front rather than trying to add them later in the field.
10) Do I need to buy fasteners or sex bolts separately for a wood door?
No. The device ships with 1 3/4 inch (44 mm) and 2 1/4 inch (57 mm) fasteners plus sex bolts (SNB) covering wood and metal doors. On a wood door, use the sex bolts to through-bolt the device. Optional SNB is available for the device as well.
11) What finishes does the Von Duprin 22NL come in for matching existing doors?
Four finishes: 526 chrome powdercoat, 622 flat black coated, 689 aluminum painted, and 695 dark bronze painted. For a property standardizing a building, 689 is the usual match to clear anodized aluminum storefront and 695 to dark bronze storefront.
12) Is there an option for the 22 device on a glass door or for accessibility requirements?
Mechanical options include the GBK glass bead kit, used where the device mounts on a door with glass stops in the way, and the AX accessible device option. Both are specified at order time with the device.
