Von Duprin 9857-F/9957-F Surfa...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$3,850.00
$2,549.32
Von Duprin 9857-F/9957-F Surface Three-point Latch Fire Exit Device - 3-Foot
Brand:
Von Duprin
Category:
Exit Devices and Trim
Product Group:
Exit Devices and Trim
Series:
98/99 Series
Grade:
Grade 1
Fasteners:
Included for wood or metal doors 1-3/4" and 2-1/4" thick
Projection:
3-13/16"
Door Thickness:
1-3/4"
Handing:
Non-Handed
Product Subgroup:
Exit Devices - Vertical Rod
Product Type:
Exit Devices - Three-Point Latch
Subcategory:
Surface Three-Point Latch Exit Devices
Latch Throw:
Deadlocking anti-friction top and bottom bolt, 5/8" throw, Deadlocking rim bolt, 3/4" throw
Fire Rated:
Yes
Function:
EO/DT/NL (field selectable). For TP, K or L remove NL drive screw from device.
Commercial/Residential:
Commercial
Style:
Push Pads
Size:
36"
Stile Type:
Wide Stile
Center Case Dimensions:
8" x 2-3/4" x 2-3/8"

Von Duprin 9857-F/9957-F Surface Three-point Latch Fire Exit Device - 3-Foot

(No reviews yet) Write a Review

Model: VON-9857-F/9957-F-3
$3,850.00
$2,549.32
Selected Finish is
Selected Case Style is
  • ADDER-VON-98/99-LEVERS=06 Lever (Default of "L" Trim Options)
  • ADDER-VON-98/99-LEVERS=03 Lever
  • ADDER-VON-98/99-LEVERS=07 Lever
  • ADDER-VON-98/99-LEVERS=17 Lever
  • ADDER-VON-98/99-LEVERS=LAT - Latitude Lever
  • ADDER-VON-98/99 Series-[MECHANICAL OPTIONS]=GBK: 1/4" 98/99 Surface Vertical (98/99GBK-SV)

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3,850.00
$2,549.32
Adding to cart… The item has been added
Free Shipping on orders over $149
Need a quote? Click Add to Quote. It's quick and easy. We'll send you a free quote!
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
Brand:
Von Duprin
Category:
Exit Devices and Trim
Product Group:
Exit Devices and Trim
Series:
98/99 Series
Grade:
Grade 1
Fasteners:
Included for wood or metal doors 1-3/4" and 2-1/4" thick
Projection:
3-13/16"
Door Thickness:
1-3/4"
Handing:
Non-Handed
Product Subgroup:
Exit Devices - Vertical Rod
Product Type:
Exit Devices - Three-Point Latch
Subcategory:
Surface Three-Point Latch Exit Devices
Latch Throw:
Deadlocking anti-friction top and bottom bolt, 5/8" throw, Deadlocking rim bolt, 3/4" throw
Fire Rated:
Yes
Function:
EO/DT/NL (field selectable). For TP, K or L remove NL drive screw from device.
Commercial/Residential:
Commercial
Style:
Push Pads
Size:
36"
Stile Type:
Wide Stile
Center Case Dimensions:
8" x 2-3/4" x 2-3/8"
9857-F/9957-F SURFACE THREE-POINT LATCH FIRE EXIT DEVICE OVERVIEW

9857-F/9957-F Fire exit three-point latching device are UL listed for fire exit hardware. See page 67 for detailed information on UL listed fire exit hardware label and door opening size information. Devices are ANSI A156.3 – 2008 Grade 1. The 9857-F device has a smooth mechanism case and the 9957-F device has a grooved case. The three-point latch device is non-handed except when the following device option is used: SS (signal switch) or WS (windstorm). Vertical rod and latch guards are available to protect the bottom rod of the exit device from damage by impacts of carts or gurneys passing through doors.


98/99 SERIES OVERVIEW

The 98/99 Series devices are wide stile heavy-duty push pads. Architectural design elements differ between the 98 and the 99.

The 98 Series device has a smooth mechanism case, while the 99 Series has a grooved mechanism case. The 98/99 Series have all been certified to the highest industry standards and are used in schools, hospitals and government buildings.



FEATURES & BENEFITS

  • The breadth of available options allows for tailoring to any facility’s needs.
  • Designed for high use and abuse in institutional applications like schools, hospitals and government facilities.
  • A variety of field-configurable options available.
  • Retrofit kits available to keep up with changing technology.



SPECIFICATIONS

Specifications and certifications are specific to each configuration. See the 98/99 Series catalogs for more information.

  • ANSI/BHMA A156.3 2014 Grade 1 certified
  • ANSI/UL 10C (fire-rated only)
  • ANSI/UL 305
  • CAN/ULC-S104 (fire-rated only)
  • CAN/ULC-S132



DEVICE TYPE

The 98/99 Series offers a solution for any single, double and double egress door. All devices can be ordered by adding the “-F” suffix.

  • No suffix: rim devices
  • 27: surface-mounted vertical rod
  • 47: concealed vertical rod (5/8” bottom bolt)
  • 47WDC: wood door concealed vertical rod
  • 48: concealed vertical rod (1-1/2” bottom bolt)
  • 49: concealed vertical cable
  • 50WDC: wood door concealed vertical cable
  • 52: 1-point concealed vertical cable
  • 57: 3-point latching
  • 75: mortise lock devices



FUNCTIONS & TRIM

A variety of functions and trim options are available, but only the standard options are listed below. Refer to the 98/99 Series catalog for more information.

 Functions

  • Classroom: the key locks and unlocks the lever or knob
  • Dummy: the rigid mechanical trim for pull operation
  • Exit only: no outside trim
  • Passage: the lever or knob is always active
  • Storeroom: the key retracts the latchbolt, the lever or knob is rigid



98/99 Series popular trims

  • 990: pull trim, 5 standard functions:
    • Classroom (TP)
    • Storeroom (NL)
    • Dummy trim (DT)
    • Passage (TP-BE)
    • Exit only (EO)
  • 996: lever or knob trim, 4 standard functions:
    • Classroom (L, K)
    • Storeroom (L-NL, K-NL)
    • Dummy (L-DT, K-DT)
    • Passage (L-BE, K-BE)



LEVERS & FINISHES

The 98/99 Series offers many choices for levers and finishes. Refer to the 98/99 Series catalog for more information.



OPTIONS

With the 98/99 Series, the devices can be retrofitted to keep up with evolving technology with various retrofit kits. Refer to the 98/99 Series catalog for more information.

Retrofitting an existing device

  • CDSI/HDSI: security dogging indicators provide at-a-glance verification of the panic device status
  • QEL: electronic latch retraction with limited operational noise
  • Electronic switches: can be used as part of an access control system or in a standalone application
    • Request to exit (RX)
    • Latchbolt monitoring (LX)



Upgrading to a new device

  • AX: an accessible device that is certified to meet the 5 lb. force requirements for the 2010 American Disabilities Act (ADA) (Chapters 404.2.7 and 30934) and 2013 California Building Code (Chapter 11B-309.4)
  • CX: CHEXIT meets NFPA and IBC requirements for delayed egress; a standard device keeps doors secure for 15 seconds after a request to exit while a nuisance alarm sounds
  • XP: patented 2-piece latchbolt design, available for 98/99 Series panic and fire applications



ACCESSORIES

From mullions to powers transfers and strikes, the 98/99 Series offers a range of accessories to meet the evolving needs of any facility. Refer to the 98/99 Series catalog for more information.
