Von Duprin 2670 Guard-X Exit Device Only, No Trim, for 3–4 Ft. Doors, Satin Aluminum Clear Anodized
Commercial-Grade Exit-Only Door Hardware for 3 to 4 Foot Door Applications
The Von Duprin 2670 Guard-X Exit Device is a professional-grade, exit-only panic hardware solution designed for commercial door applications. Engineered for doors ranging from 3 to 4 feet in width, this device is supplied without trim and features a Satin Aluminum Clear Anodized finish. As part of the 2670 Guard-X Series, it delivers Grade 1 performance for demanding commercial environments where reliable, code-compliant egress is essential.
Professional Features & Benefits
- Door Width Compatibility: Designed for 3 to 4 foot doors, making it suitable for a wide range of standard commercial door openings.
- Exit-Only Configuration: Configured for exit-only operation with no trim included, providing a clean, streamlined installation for one-way egress applications.
- Grade 1 Performance: Rated Grade 1 for commercial-grade durability and reliability, meeting the demands of high-traffic commercial facilities.
- Satin Aluminum Clear Anodized Finish: The Satin Aluminum Clear Anodized finish provides a professional aesthetic while offering corrosion resistance suitable for commercial interiors.
- 2670 Guard-X Series: Part of Von Duprin's established Guard-X Series, engineered for consistent performance across compatible commercial door hardware installations.
- Commercial Application Ready: Classified for commercial use, this exit device meets the requirements of professional door hardware installations in a variety of building types.
Technical Specifications
- Product Group: Exit Devices and Trim
- Series: 2670 GUARD-X Series
- Grade: Grade 1
- Product Subgroup: Parts and Accessories
- Subcategory: Parts and Accessories
- Product Type: Exit Devices Parts
- Commercial/Residential: Commercial
- Parts and Accessories Type: Installation Accessories
- Product Attribute: Parts and Accessories
- Fire Rating: No
- Product Category: Exit Devices and Trim
- Department: Door Hardware
Professional Applications
- Commercial Office Buildings
- Educational Facilities
- Healthcare Institutions
- Retail Establishments
- Industrial and Warehouse Facilities
- Multi-Tenant Residential Properties
- Government and Municipal Buildings
Why Choose Von Duprin Quality?
Von Duprin exit device products are engineered to deliver professional-grade reliability, with the 2670 Guard-X Series achieving Grade 1 performance standards for commercial applications. The Satin Aluminum Clear Anodized finish ensures lasting durability and a consistent professional appearance in demanding environments. Trusted by commercial door hardware professionals, Von Duprin products are built to perform where dependable egress hardware is essential.
Manufacturer Resources
Von Duprin 55 Series Catalog
Product Specs
- Product Group:
- Exit Devices and Trim
- Series:
- 2670 GUARD-X Series
- Grade:
- Grade 1
- Product Subgroup:
- Parts and Accessories
- Subcategory:
- Parts and Accessories
- Product Type:
- Exit Devices Parts
- Commercial/Residential:
- Commercial
- Parts and Accessories Type:
- Installation Accessories
- Product Attribute:
- Parts and Accessories
- Fire Rating:
- No
- Product Category:
- Exit Devices and Trim
- Department:
- Door Hardware
Von Duprin 2670 US28 – Frequently Asked Questions
1) What type of exit device is the Von Duprin Guard-X?
The Guard-X is a rim-style exit device engineered for high-security applications. It features a reinforced pushbar and enhanced internal components designed to resist forced entry attempts while maintaining code compliance for emergency egress.
2) What door thickness and width does this device accommodate?
Standard Von Duprin rim devices typically fit doors 1-3/4" to 2-1/4" thick and up to 4' wide. Verify specific dimensions with the manufacturer template as door preparation requirements may vary based on frame type and installation conditions.
3) Is this device handed or can it be field-configured?
Most Von Duprin rim exit devices are field-reversible for left-hand or right-hand doors. The latch mechanism and pushbar can typically be configured during installation. Consult the installation instructions for proper handing procedures.
4) What finishes are available for the Guard-X series?
Von Duprin typically offers standard architectural finishes including aluminum, dark bronze, and stainless steel options. Specific finish availability may vary by model. Contact your distributor to confirm available finishes for this particular device.
5) What grade rating does this exit device carry?
Von Duprin Guard-X devices are typically Grade 1 rated per ANSI/BHMA A156.3 standards. This rating indicates the highest level of performance for commercial exit hardware including cycle testing and security requirements.
6) Does this meet fire door and building code requirements?
Von Duprin exit devices are designed to meet IBC and NFPA egress requirements. Fire door compatibility depends on the complete door assembly listing. Verify that all components including the device, trim, and strikes are properly listed for your specific application.
7) What trim and accessories are compatible with this device?
The Guard-X works with Von Duprin's standard trim series including lever handles, thumbpieces, and cylinder pulls. Electric latch retraction, request-to-exit, and monitoring options may also be available. Browse our Von Duprin collection for compatible components.
8) What are the basic installation requirements?
Installation requires precise door preparation per the manufacturer template. Mount the device securely to the door, install the strike in the frame, and adjust the latch for proper engagement. Use only the specified fasteners and follow torque specifications for security applications.
9) How do I maintain and adjust the Guard-X device?
Regular maintenance includes checking latch engagement, lubricating pivot points with manufacturer-approved lubricant, and testing pushbar operation. Adjust the latch projection and dogging mechanism as needed. Inspect mounting hardware periodically for security applications.
10) Are there related Von Duprin models for different security levels?
Von Duprin offers various security-focused exit devices including the 99 series for standard commercial use and specialized models for detention applications. The Guard-X provides enhanced security between standard commercial and institutional-grade devices.
11) What field conditions affect installation and performance?
Consider door weight, frame material, and environmental conditions. Heavy doors may require additional support. Exterior applications need weather-resistant finishes. High-traffic areas benefit from the Guard-X's reinforced construction to withstand frequent use and potential abuse.
12) What measurements should I verify before ordering?
Measure door thickness, width, and backset requirements. Verify frame type and strike location. Check clearances for the device body and pushbar operation. Note any existing prep that might affect installation or require modification.
