Weslock 0600 Savannah Knob Pas...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$52.40
$28.82
Weslock Weslock 0600 Savannah Knob Passage Lock with Adjustable Latch and Full Lip Strike WES-0600Z

Weslock 0600 Savannah Knob Passage Lock with Adjustable Latch and Full Lip Strike

(No reviews yet) Write a Review

Model: 00600ZNZNSL20
From the Traditionale Collection
$52.40
$28.82
Selected Finish is
Selected Knob Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$52.40
$28.82
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Weslock TRADITIONALE COLLECTION 0600 Passage Lock

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition..

Passage: Passage door hardware has no Locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a Lock isn't needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.


Standard features

  • Cylindrical Door Locks
  • Exceeds ANSI A 156.2 Grade II Lock standards
  • Removable Knobs/Levers Prevents Scratching During Installation
  • Pre-installed screws concealed behind snap-on rosette
  • Push Button Locking in rosette
  • All brass knobs and rosettes
  • Passage - Free Turning on Both Sides of Door
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Fits doors prepared with 2-1/8” cross hole & 1” edge hole
  • Adjusts to door thickness from 1-3/8” to 1-3/4”
  • Optional door thickness up to 2-1/4”
  • Limited Warranty


Downloads and Resources

Weslock Catalog

Weslock General Specifications

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Traditionale
Warranty:
Limited Lifetime Mechanical and Limited Lifetime Finish
Latch Faceplate:
1" x 2-1/4"
Collection:
Traditionale
Cross Bore:
2-1/8"
Keyed:
No
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Knobsets
Subcategory:
Residential Door Knobs
Commercial/Residential:
Residential
Lock Function:
Passage/Hall/Closet
Product Attribute:
Cylindrical Locks
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Passage/Hall/Closet
Door Thickness Range:
1-3/8" to 2"
Product Dimension:
2-1/2" x 5" Rose and 2-1/4" Projection
Door Strike:
Round Corner Full Lip Strike
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Weslock 00600ZNZNSL20 – Frequently Asked Questions

1) Will the Weslock 0600 Savannah passage knob fit my existing door prep?
It drops into a standard residential bore: 2-1/8 inch cross bore with a 1 inch edge bore, which is the common prep on nearly every modern interior door. The latch adjusts between 2-3/8 and 2-3/4 inch backset, so you don't need to know which one your door was drilled for before ordering. The latch faceplate is 1 x 2-1/4 inches, and it comes with a round corner full lip strike.
2) What door thickness does the Weslock 0600 passage knob handle, and do I have to order anything different for a thick door?
Standard build covers 1-3/8 to 1-3/4 inch doors. Door thickness is a required choice at order time, and there is a second option covering 1-3/4 to 2-1/4 inch. The catalogued thickness range for the 0600 is 1-3/8 to 2 inches, with the thicker configuration going up to 2-1/4. Pick the thickness option that matches your slab before you order, because it changes the spindle and screw length in the box.
3) Is the Weslock 0600 rated for a commercial building or apartment corridor?
It's classified as residential hardware. Weslock states the 0600 exceeds ANSI A156.2 Grade 2 lock standards, but the set is built for homes. For a commercial corridor or a multi-family common area, look at a purpose-built commercial passage knob: the Falcon X101 is Grade 1 heavy duty and covers 1-3/8 to 2-1/4 inch doors, and the Corbin Russwin CK4310 is a Grade 1 passage/closet knob covering 1-3/8 to 2 inches.
4) I'm replacing a builder-grade Kwikset passage knob. Will the Weslock 0600 go straight in?
In most cases yes. A Kwikset 200P Polo passage knob uses the same standard bore and an adjustable round corner latch with a round corner strike, and the Weslock 0600 uses the same 2-1/8 inch cross bore, the same 2-3/8 or 2-3/4 adjustable backset, and a round corner full lip strike. The lip strike is deeper than a plain round corner strike, so if the existing strike mortise is shallow you may need to widen the jamb cutout slightly.
5) I need the same knob on a bedroom or bathroom door - what do I order instead of the 0600 passage?
The 0600 is a passage function with no locking mechanism, free turning on both sides, so it is not suitable for a bed or bath door. For a privacy knob, the Dexter C2000 Series privacy is a Grade 2 non-keyed cylindrical ball knob for doors 1-3/8 to 1-3/4 inches, the Pamex FTF Baron is a Grade 3 privacy knob lockset for the same thickness range, and the Baldwin Estate 5000 Baltimore privacy knob with 5148 rose comes preconfigured with a 2-3/8 inch backset and full lip strike, matching the 0600 strike style.
6) What is the closest equivalent to the Weslock 0600 Savannah passage knob from another brand?
For a like-for-like residential passage knobset, the Kwikset 200P Polo passage knob is the nearest match - it is an interior hall/closet knob supplied with a 6AL adjustable latch and an RCS round corner strike, the same latch-and-strike arrangement as the Weslock 0600, which ships with an adjustable 2-3/8 or 2-3/4 inch backset latch and a round corner full lip strike. The Weslock uses all-brass knobs and rosettes and adjusts to doors 1-3/8 to 2 inches thick; the Kwikset 200P-CP is the clear-pack version of the same Polo passage knob with a round corner adjustable latch and round corner strike.
7) The Weslock 0600 is residential duty - what passage knob should I use on a commercial corridor or classroom door instead?
Step up to a commercial cylindrical passage lock. The Falcon X101 is a Grade 1 heavy duty cylindrical passage knobset with an interchangeable core prep, fire rated, covering doors 1-3/8 to 2-1/4 inches thick. The Corbin Russwin CK4310 is a Grade 1 passage/closet cylindrical lock with a Global knob for doors 1-3/8 to 2 inches. For medium duty work, the Falcon W101 is a Grade 2 passage/closet knob lock with a 2-3/4 inch backset and a fire rating. The Weslock 0600 is a residential passage knobset, so it is the wrong tool for a rated or high-traffic commercial opening.
8) What do I use instead of the Weslock 0600 if the door needs to lock with a key?
The 0600 is non-keyed, so for a keyed opening choose an entrance function knob. The Kwikset 400P Polo keyed entry knob ships with a 6AL latch and RCS strike, the same latch and strike family as the Polo passage; the 400P-CP is Grade 3 for doors 1-3/8 to 1-3/4 inches. Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway for the same thickness range. For commercial keyed work, the Corbin Russwin CK4851 is an entrance/office cylindrical lock with a conventional cylinder for doors 1-3/8 to 2 inches.
9) How far does the Weslock Savannah knob stick out from the door, and how big is the rose?
Projection is 2-1/4 inches off the face of the door, on a 2-1/2 by 5 inch rose. Worth checking if the door sits close to a wall return or an adjacent cabinet, and worth measuring against your old rose if you're replacing hardware on a painted or stained door where a smaller rose would leave a witness mark.
10) Can I use this passage knob on a back door if I add a deadbolt?
Yes. Because the 0600 has no locking mechanism of its own, it's commonly paired with a separate deadbolt on an exterior or back door, with the deadbolt doing all the security work and the knob just operating the latch. If you'd rather have the locking built into the knob, a keyed entry knob is the other route, like the Kwikset 400P Polo entry or the Cal-Royal BER00 entrance/office knob.
11) I need matching hardware on a closet door that doesn't need a latch at all. What's the alternative?
A dummy knob is what you want there, not the 0600. The Savannah passage set carries a working latch and strike, so it needs a full bore and a jamb prep. On a false door or a double closet door that catches on a roller, a surface-mounted dummy such as the Schlage A170 single dummy trim or the Bravura Biloxi dummy knobset mounts to the face with no latch bore.
12) Is a dummy knob the same thing as the Weslock 0600 passage knob?
No. The Weslock 0600 is a passage latchset - the knobs turn and retract a live latch into a round corner full lip strike, and it needs a door bored with a 2-1/8 inch cross bore and 1 inch edge bore. A dummy knob is surface trim with no latch at all, used on inactive or closet doors that are held shut some other way. Products like the Schlage A170 single dummy trim, the BEST 6K single dummy trim, the Cal-Royal BA40 dummy knob, and the Bravura Biloxi dummy knobset are all dummy function and will not latch a door. Order the 0600 when the door must latch, a dummy when it must not.
13) Which passage knobs besides the Weslock 0600 cover doors thicker than 1-3/4 inches?
The Weslock 0600 adjusts to doors 1-3/8 to 2 inches thick, with a door thickness option selected at order. Among passage knobs, the Corbin Russwin CK4310 Grade 1 passage/closet lock also covers 1-3/8 to 2 inches, and the Falcon X101 Grade 1 passage knobset goes to 1-3/8 to 2-1/4 inches. Most residential-scale passage knobs stop at 1-3/4 inches - the Dexter C2000 passage, Arrow MK01 and RK01, Corbin Russwin CK4410 Grade 2, and Pamex FTF Baron passage are all specified 1-3/8 to 1-3/4 inches.
14) I want a decorative traditional passage knob rather than the Weslock Savannah - what else matches that look?
The Weslock 0600 Savannah is a Traditionale Collection solid brass knobset with a 2-1/2 by 5 inch rose and 2-1/4 inch projection. For a comparable traditional-style passage knob, the Baldwin Estate 5011 Colonial passage knob with 5058 rose and the Baldwin Estate 5000 Baltimore 2 inch knob with 5048 rose are both passage function, the Baltimore preconfigured with a 2-3/8 inch backset and full lip strike. Omnia 434/PA is a traditional egg-shaped knob latchset in solid brass with a 3 inch projection, a deeper reach than the Savannah.
15) What is the Savannah knob actually made of?
Solid brass. Weslock builds the Traditionale knobs and rosettes in all brass, and the 0600 ships in a satin nickel finish over that brass. Installation screws come pre-installed and hide behind a snap-on rosette, and the knobs pull off during install so you don't scratch the finish fitting them.
16) If I'm standardizing knobs across a whole house, is the 0600 Savannah part of a wider family?
It's the passage function in Weslock's Traditionale collection, so the same Savannah knob design and rose carry across the other functions in that collection for privacy, entry and dummy openings. That's how you keep hallways, bedrooms and the front door reading the same. Order the 0600 for hall and closet doors and the matching function for the rest.
17) What is a simpler passage knob if I do not need the Weslock brass trim and concealed screws?
The Weslock 0600 Savannah uses all brass knobs and rosettes with pre-installed screws concealed behind a snap-on rosette. If exposed trim screws are acceptable, the Pamex FTF Baron passage knob is a Grade 3 passage lockset for doors 1-3/8 to 1-3/4 inches, the Bravura Albany and Lynchburg are Grade 2 passage knobsets with round trim, and the Dexter C2000 passage is a Grade 2 non-keyed ball knob for the same door range. All four are passage function like the 0600.
18) Can a Lockey 3830 keyless knob replace the Weslock 0600 passage knob?
Not as a straight swap in intent. The Weslock 0600 is a plain passage knob with no locking mechanism, free turning on both sides, for halls and closets. The Lockey 3830 is a mechanical keyless combination knob lock with an auto-locking passage function for doors 1 3/16 to 2 inches thick - it requires a code to pass through from the outside. If the goal is controlled access without keys it is a valid alternative; if the goal is simple free passage, the 0600 is the correct function.
