Weslock 0610 Savannah Knob Privacy Lock with Adjustable Latch and Full Lip Strike

Weslock 0610 Savannah Knob Privacy Lock with Adjustable Latch and Full Lip Strike

(No reviews yet) Write a Review

Model: 00610Z1Z1SL20
From the Traditionale Collection
$84.20
$54.73
Selected Finish is
Selected Knob Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$84.20
$54.73
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Weslock TRADITIONALE COLLECTION 0610 PRIVACY Lock

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.

Privacy: Weslock's privacy knobs feature a push button Lock on the interior for use on bedroom and bathroom doors where Locking is needed. The exterior side of this privacy knobset features a small pin hole to unlock the lever from the outside. Emergency release tool included (small pin).


Standard features

  • Cylindrical Door Locks
  • Exceeds ANSI A 156.2 Grade II Lock standards
  • Removable Knobs/Levers Prevents Scratching During Installation
  • Pre-installed screws concealed behind snap-on rosette
  • Push Button Locking in rosette
  • All brass knobs and rosettes
  • Panic-Proof Keylock/Privacy– one turn of interior knob/lever unlocks & opens door
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Fits doors prepared with 2-1/8” cross hole & 1” edge hole
  • Adjusts to door thickness from 1-3/8” to 1-3/4”
  • Optional door thickness up to 2-1/4”
  • Limited Warranty


Downloads and Resources

Weslock Catalog

Weslock General Specifications

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Traditionale
Warranty:
Limited Lifetime Mechanical and Limited Lifetime Finish
Latch Faceplate:
1" x 2-1/4"
Collection:
Traditionale
Cross Bore:
2-1/8"
Keyed:
No
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Knobsets
Subcategory:
Residential Door Knobs
Commercial/Residential:
Residential
Lock Function:
Privacy/Bed/Bath
Product Attribute:
Cylindrical Locks
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Privacy/Bed/Bath
Door Thickness Range:
1-3/8" to 2"
Product Dimension:
2-1/2" x 5" Rose and 2-1/4" Projection
Door Strike:
Round Corner Full Lip Strike
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Weslock 00610Z1Z1SL20 – Frequently Asked Questions

1) Does the Weslock 0610 knob work with a 2-3/8 or a 2-3/4 inch backset?
Both. The latch that ships with the 0610 Savannah is adjustable between 2-3/8 and 2-3/4 inch backset, so you do not have to measure before ordering, and one part covers both preps you will find in a house. The faceplate is removable, and the strike is a round corner full lip type.
2) What door prep does a Weslock Savannah knob need, and will it drop into my existing bored holes?
It mounts in the standard bored prep: a 2-1/8 inch cross bore through the face of the door and a 1 inch edge bore. If your old knob was a standard residential cylindrical set, the holes are almost certainly already right and this goes straight in. The latch faceplate measures 1 x 2-1/4 inches, which is the common round-corner mortise in the door edge.
3) Is the Weslock 0610 Savannah keyed, or is it a push button privacy lock?
Non-keyed. Locking is a push button in the interior rosette, and the outside knob has a small pin hole for emergency release. The release pin is included in the box. It is a bed and bath function, so there is no cylinder and no key to cut or rekey.
4) Can someone get out of the bathroom if the Weslock privacy knob is locked?
Yes. It is a panic-proof privacy function: one turn of the interior knob unlocks and opens the door in a single motion, so nobody is trapped inside. From the hall side, push the included pin into the small hole in the knob face to release it. That is the behavior a property manager wants on bedroom and bath doors in a rental.
5) What is the closest privacy knob equivalent to the Weslock 0610 Savannah from another brand?
The Deltana 6112 St. Thomas knob is a privacy/bed/bath knob covering a 1-3/8 inch to 2 inch door thickness range, which matches the 1-3/8 inch to 2 inch range the Weslock 0610 Savannah covers. Both are privacy function, so both use a push-button interior lock with an emergency release from the outside rather than a keyed cylinder. If the door is thinner than 1-3/4 inch and the range matters less, the Pamex FTF Baron privacy knob is a Grade 3 privacy knob for 1-3/8 inch to 1-3/4 inch doors, and the Dexter C2000 privacy ball knob is a Grade 2 privacy knob over that same 1-3/8 inch to 1-3/4 inch range.
6) I need a bathroom lock for a commercial building - is the Weslock 0610 Savannah the right pick?
The Weslock 0610 Savannah is designated residential and its knob and rosettes are brass. For a commercial opening, the Dexter C2000 privacy ball knob is a Grade 2 privacy lock for 1-3/8 inch to 1-3/4 inch doors, and the Cal-Royal BER20 is a Grade 3 privacy knob with brass trim over that same thickness range. Both carry a stated ANSI grade for the privacy function, which is what a facility spec typically calls out for a restroom or patient room door.
7) My door is thicker than 2 inches - what knob lock covers it if the Weslock 0610 Savannah does not?
The Weslock 0610 Savannah covers 1-3/8 inch to 2 inch. For a thicker leaf, the Falcon X101 is a heavy duty Grade 1 cylindrical knobset rated for 1-3/8 inch to 2-1/4 inch doors, fire rated, with an interchangeable core. It is a passage/hall/closet function, so it does not lock - on a bedroom or bath door that needs privacy, confirm the function before ordering.
8) How much does the Savannah knob stick out from the door face, and how big is the rose?
Projection is 2-1/4 inches with a 2-1/2 x 5 inch rose. That matters where a door swings back against a wall or a cabinet, or where two doors in a corner can knuckle into each other. The rose is a snap-on that hides the mounting screws, so nothing shows on the finished face.
9) Is the Weslock 0610 knob rated for commercial use or is it residential hardware?
It is residential hardware. Weslock states the 0610 exceeds ANSI A156.2 Grade II lock standards, with all brass knobs and rosettes, which is fine for homes, apartments and light hospitality. For a commercial corridor or a school, step up to a purpose-built Grade 1 or Grade 2 commercial knob such as the Corbin Russwin CK4300 Series or the Falcon X Series.
10) What is a good alternative to the Weslock Savannah privacy knob if I need a commercial grade privacy lock?
For a graded commercial privacy knob, the Dexter C2000 Series privacy knob is Grade 2 and fits 1-3/8 to 1-3/4 inch doors. The Cal-Royal BER20 and the Pamex FTF Baron are Grade 3 privacy knobs over the same thickness range and are the cheaper-spec route for high-turnover multifamily. The Weslock stays the pick when appearance matters, since it is a decorative brass set with concealed screws rather than a plain commercial ball knob.
11) I need matching knobs for the whole house, not just the bathroom. What do I use on the hall and closet doors?
The 0610 Savannah is the privacy function only, for bedrooms and baths. Hall, closet and pantry doors take a passage knob that never locks, and a decorative-brass equivalent is the Baldwin Estate 5000 Baltimore passage knob or the Baldwin Estate 5011 Colonial passage knob. If you want the whole house on one look, decide the design first, then order privacy where a door needs to lock and passage everywhere else.
12) Will the Weslock 0610 strike work with my existing strike mortise, or do I need to re-chisel the jamb?
It ships with a round corner full lip strike. If the strike currently in your jamb is a round corner type, which is what most residential prep uses, the new one drops into the same mortise. A square corner mortise will need the corners rounded or the plate filed to suit. The lip on the strike wraps the jamb edge and guides the latch in on a door that has settled slightly.
13) Which knob should I use on the hall and closet doors if I am putting the Weslock 0610 Savannah on the bedrooms?
The Weslock 0610 Savannah is privacy/bed/bath function, so it locks and is not what a hall or closet door wants. For those openings use a passage knob: the Pamex FTF Baron passage knob is Grade 3 for 1-3/8 inch to 1-3/4 inch doors, the Dexter C2000 passage ball knob is Grade 2 over the same range, and the Kwikset 200P-CP Polo passage knob ships with a round corner adjustable latch and round corner strike. The Weslock 0610 also uses a round corner full lip strike, so a round corner strike prep on the jamb suits both.
14) Is the Cal-Royal BER20 the same thing as the Weslock 0610 Savannah?
Both are privacy/bed/bath knob locks, so both give a push-button lock on a bedroom or bathroom door. The Cal-Royal BER20 is a Grade 3 knob lock with brass trim covering 1-3/8 inch to 1-3/4 inch doors. The Weslock 0610 Savannah is an all-brass Traditionale knob covering 1-3/8 inch to 2 inch, with an adjustable latch for 2-3/8 inch or 2-3/4 inch backset and a round corner full lip strike. On a 1-3/4 inch door either one fills the same opening; above that thickness the ranges differ.
15) What matches the Weslock 0610 Savannah on a decorative brass job where the knob shape matters?
For a traditional brass look in privacy function, the Baldwin Estate 5077 Bethpage privacy knob with R027 rose and the Baldwin Estate 5000 Baltimore privacy knob with 5148 rose are both privacy locks, and the 5000 Baltimore is preconfigured with a 2-3/8 inch backset and a full lip strike - the same full lip strike style the Weslock 0610 Savannah uses. The Deltana 6112 St. Thomas is another privacy knob and covers doors from 1-3/8 inch to 2 inch.
16) We are standardizing an apartment building - can one knob line cover bedroom, hall, and entry doors alongside the Weslock 0610 Savannah?
The Weslock 0610 Savannah handles the bed and bath doors as a privacy function knob. To keep one line across the rest of the unit, the Dexter C2000 series runs the same ball knob in Grade 2 across privacy, passage, entry/office and classroom functions, all for 1-3/8 inch to 1-3/4 inch doors. The Pamex FTF Baron series does the same in Grade 3 with privacy, passage and entrance/office over that same thickness range.
17) Do the Weslock knobs come off during installation so I do not scratch the finish?
They do. The knobs are removable for install, which keeps the finish off the door face and out of the way while you set the chassis, and the mounting screws come pre-installed behind a snap-on rosette. On an oil rubbed bronze set that detail is worth having, since scuffs in that finish show.
