Weslock 0710 Mesa Knob Privacy...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$68.00
$35.82
Weslock 0710 Mesa Knob Privacy Lock with Adjustable Latch and Full Lip Strike

Weslock 0710 Mesa Knob Privacy Lock with Adjustable Latch and Full Lip Strike

(No reviews yet) Write a Review

Model: 007104N4NFR20
From the Transitional Collection
Selected Finish is
Selected Knob Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$68.00
$35.82
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WESLOCK 0710 PRIVACY LOCK  OVERVIEW

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.

Privacy Function: Weslock's privacy knobs/levers feature a push button lock on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side of this privacy knobsets/leverset features a small pin.



Standard features

  • Privacy lock where inside lever will come with a push button locking mechanism to help where privacy is a concern
  • Cylindrical Door Locks
  • ANSI Grade 3 Certified
  • Solid Zinc Construction
  • Square Spindle Construction
  • Dual Spring Housings
  • Non-Handed
  • Decorative Push Button Locking in Interior Rosette
  • Locking Device Releases Upon Turn of Interior Lever
  • Privacy Key Hole in Exterior Rosette For Emergency Unlocking
  • Adjustable Backset 2-3/8" or 2-3/4"
  • 2-1/8" Cross Bore, 1" Edge Bore
  • Fits 1-3/8" - 1-3/4" Thick Door
  • 1/2" Throwbolt
  • 1" x 2-1/4" Radius Corner Faceplate Standard (Square or Drive-in Available)
  • 2-1/4" x 1-3/4" Full Lip Radius Strike Standard (Square Available)
  • Limited 25 Year Mechanical Warranty
  • Limited 5 Year Finish Warranty



DOWNLOADS & RESOURCES

Weslock Catalog

Weslock General Specifications

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Transitional
Warranty:
Limited 25 Year Mechanical, Limited 5 Year Finish
Collection:
Transitional
Cross Bore:
2-1/8"
Latch Faceplate:
1" x 2-1/4" Radius Corner Standard
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Knobsets
Subcategory:
Residential Door Knobs
Keyed:
No
Commercial/Residential:
Residential
Lock Function:
Privacy/Bed/Bath
Product Attribute:
Cylindrical Locks
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Privacy/Bed/Bath
Door Thickness Range:
1-3/8" to 1-3/4"
Product Design:
Square Rose
Door Strike:
2-1/4" - 1-3/4" Radius Full Lip
Product Category:
Mechanical Locks
Product Substrate:
Zinc Alloy
Department:
Door Hardware

Weslock 007104N4NFR20 – Frequently Asked Questions

1) Will the Weslock 0710 Mesa privacy knob fit a standard pre-drilled interior door?
It drops into a standard residential prep: 2-1/8 inch cross bore, 1 inch edge bore, and an adjustable backset that sets to either 2-3/8 or 2-3/4 inches. Door thickness range is 1-3/8 to 1-3/4 inches, which covers both the common older interior door and the standard 1-3/4 inch slab. If your existing bore matches that, no new drilling is needed.
2) Do I have to know the backset before ordering the Weslock 0710 knob?
No. The latch is adjustable and covers both 2-3/8 and 2-3/4 inches, the two backsets used on residential doors, so one part number works whether the bore sits 2-3/8 or 2-3/4 inches from the door edge. That is useful on a turnover unit where nobody has measured yet.
3) How does the privacy lock on a Weslock 0710 bedroom knob unlock from the outside in an emergency?
Push button on the interior rose locks it, and turning the interior knob releases it. Outside there is a small emergency pin hole in the exterior rosette, so a property manager or parent can release the lock from the hall with a straight tool. There is no key and no keyway on this one, it is a non-keyed privacy function for bed and bath doors.
4) Will the Weslock 0710 latch catch in my existing strike, or do I need to replace the strike plate?
The latch throws 1/2 inch and ships with a 1 x 2-1/4 inch radius corner faceplate plus a 2-1/4 x 1-3/4 inch full lip radius strike. If the door jamb already has a radius corner strike mortise, the included strike drops straight in. Square faceplates, square strikes, and a drive-in latch are the alternate configurations if your prep is square-cornered or a drive-in bore with no faceplate mortise.
5) Is a Weslock 0710 knob heavy duty enough for an apartment building or office?
It is ANSI Grade 3 and built for residential use, so it suits bedroom and bathroom doors in homes and multi-family units. For a commercial corridor, restroom, or anywhere with heavy daily traffic, step up: the Dexter C2000 privacy ball knob is Grade 2 for 1-3/8 to 1-3/4 inch doors, and BEST 8K Series is Grade 1 heavy duty if the opening takes real abuse.
6) My door is thicker than 1-3/4 inches. What privacy knob should I use instead of the Weslock 0710?
The 0710 stops at 1-3/4 inches, so a thicker slab is out. For a privacy knob on a heavier door, the Deltana 6112 St. Thomas privacy knob covers 1-3/8 to 2 inches. Measure the slab at the edge before you order either one.
7) Is the Weslock 0710 a straight swap for the privacy knob already on my bathroom door?
In most homes, yes. Existing bored knobs sit in a 2-1/8 inch cross bore with a 1 inch edge bore at a 2-3/8 or 2-3/4 inch backset, and the 0710 matches all of that with the backset adjustable on the latch. The one thing to check is the strike mortise: the included strike is a 2-1/4 x 1-3/4 full lip radius, and if your jamb is cut square-cornered you want the square strike option rather than the standard one.
8) What is the closest cross-brand equivalent to the Weslock 0710 Mesa privacy knob for a bedroom or bath door?
The Weslock 0710 Mesa knob is a privacy/bed/bath cylindrical knob for doors 1-3/8 inch to 1-3/4 inch thick. The Pamex FTF Baron knob lockset is also a Grade 3 privacy function knob covering the same 1-3/8 inch to 1-3/4 inch door thickness, and the Cal-Royal BER20 is a Grade 3 privacy knob lock over the same thickness range. Either of those matches the 0710 on function, grade and door thickness, differing in knob styling and trim - the BER20 carries brass trim, while the 0710 uses a square rose.
9) Which privacy knob steps up from Grade 3 for a higher-traffic bedroom or restroom door?
The Weslock 0710 Mesa knob is ANSI Grade 3 certified and rated for residential use. Where a heavier cycle count is expected, the Dexter C2000 Series privacy cylindrical ball knob is Grade 2 and fits the same 1-3/8 inch to 1-3/4 inch door thickness, so the bore and door prep carry over. It is a ball knob rather than the Mesa square-rose knob.
10) What should I use instead of a privacy knob on a hall or closet door that does not need to lock?
The Weslock 0710 Mesa knob is a privacy function knob with a push button lock, which a closet or hall door does not need. For those openings the Pamex FTF Baron knob lockset comes in a Grade 3 passage function over the same 1-3/8 inch to 1-3/4 inch door thickness, and the Dexter C2000 Series passage ball knob is a Grade 2 passage/hall/closet knob over that same thickness range. Kwikset also offers the 200P Polo passage knob supplied with a 6AL latch and round corner strike.
11) Will a dummy knob work where I planned to put a Weslock 0710 privacy knob?
No - a dummy knob is not a substitute. The Weslock 0710 Mesa is a cylindrical privacy lock with a latch and a full lip strike, so it latches the door closed. Dummy trim such as the Schlage A170 single dummy, the BEST 6K Series single dummy trim, or the Bravura Biloxi dummy knobset is surface-mounted trim with no latch at all; it is used on inactive leaves and closet doors that hold shut by other means. If the door needs to latch and lock, the 0710 or another privacy function knob is the correct part.
12) My door is thicker than 1-3/4 inch - what privacy knob covers it?
The Weslock 0710 Mesa knob is built for doors 1-3/8 inch to 1-3/4 inch thick. For a thicker leaf, the Deltana 6112 St. Thomas knob is a privacy/bed/bath knob rated for doors 1-3/8 inch to 2 inch thick. If the opening is keyed rather than privacy, the Corbin Russwin CK4851 Grade 1 entrance/office knob also covers 1-3/8 inch to 2 inch.
13) Is a Grade 3 residential knob like the Weslock 0710 acceptable for a commercial corridor or school door?
The Weslock 0710 Mesa knob is ANSI Grade 3 certified and specified as residential. Commercial and institutional openings that call for a heavier grade are served by the Falcon X101 Grade 1 heavy duty cylindrical passage knobset, which is fire rated and covers doors 1-3/8 inch to 2-1/4 inch, or the Sargent 8XG04 Grade 1 heavy duty storeroom knob lock with a 2-3/4 inch backset. For a Grade 2 medium duty fire rated option, the Falcon W101 passage/closet knob lock uses a 2-3/4 inch backset.
14) Is the Weslock 0710 handed, or does one unit work on left and right hand doors?
Non-handed. The 0710 Mesa knob installs the same way on either swing, so you order one part for the whole floor and sort the doors at install. Note it is a knob, not a lever, so it is not the choice where you need ADA-friendly operable hardware.
15) What is the difference between the Weslock 0710 privacy knob and a passage knob?
Privacy means it locks. The 0710 has a push button on the inside for bedroom and bathroom doors. A passage knob does not lock at all and is what you want on a hall, closet, or pantry door, for example the Pamex FTF Grade 3 passage knob or the Dexter C2000 passage ball knob. If you need a key on the outside instead, that is an entrance function, like the Cal-Royal BER00 Grade 3 entrance knob.
16) I need a matching non-locking knob for the closet next to my Weslock 0710 bedroom door. What pairs with it?
Weslock builds the Transitional collection so privacy, passage, and entry functions share the Mesa knob and square rose, so the closet gets the passage version of the same knob and the trim matches. If you are mixing brands instead, a Grade 3 passage knob like the Pamex FTF will function the same but the rose profile will not match the square rose.
17) Is there a solid brass privacy knob alternative to the zinc alloy Weslock 0710?
The Weslock 0710 Mesa knob is built from zinc alloy with a square rose. Where solid brass is specified, the Baldwin Estate 5077 Bethpage privacy knob with R027 rose is a privacy/bed/bath knob, and the Baldwin Estate 5000 Baltimore knob with 5148 rose is a preconfigured privacy lock with a 2-3/8 inch backset and full lip strike - the same full lip strike style the 0710 uses. The Baldwin 5000 is fixed at 2-3/8 inch backset, while the 0710 adjusts between 2-3/8 inch and 2-3/4 inch.
18) Which knob do I order for a classroom or storeroom door where the privacy push button is the wrong function?
The Weslock 0710 Mesa releases its push button on a turn of the inside knob, which is the wrong behavior for a room that must stay secured. The Dexter C2000 Series classroom ball knob is Grade 2, keyed, and fits 1-3/8 inch to 1-3/4 inch doors. For storeroom function, the Sargent 6G04 is a Grade 2 standard duty storeroom/closet knob lock with a single cylinder, and the Sargent 8XG04 is the Grade 1 heavy duty version.
19) What is a keyless option if I want to avoid handing out keys but still control the door?
The Weslock 0710 Mesa is non-keyed privacy hardware - a push button inside with an emergency release outside, which anyone can open with a pin. The Lockey 3830 is a mechanical keyless combination knob lock with an auto-locking passage function, fitting doors 1 3/16 inch to 2 inch thick, so access is controlled by a code rather than a key or a button.
20) What finishes does the Weslock 0710 Mesa knob come in?
Two: matte black and satin nickel, both on the Mesa knob design with a square rose. That matters if you are matching other openings in a unit, since the square rose reads differently next to a round rose knob like the Bravura Albany.
21) What is a Weslock Mesa privacy knob made of, and will the screws show?
Solid zinc alloy body with a square spindle and dual spring housings, and the mounting screws are concealed so you do not see fasteners on the face of the rose. Zinc alloy is the usual residential casting; a solid brass alternative in a privacy knob is the Deltana 6112 St. Thomas, which fits 1-3/8 to 2 inch doors.
22) I want the same square-rose look but in a different knob shape - what else is out there?
The Weslock 0710 Mesa knob uses a square rose in the Transitional collection. Bravura offers rectangle trim on the Dallas passage knobset and round trim on the Albany and Lynchburg passage knobsets, all Grade 2. Note that those three are passage function, not privacy, so they will not give you the push button lock the 0710 provides on a bed or bath door.
