Weslock 6625 Addy Dummy Handleset with Philtower Lever

Weslock 6625 Addy Dummy Handleset with Philtower Lever

(No reviews yet) Write a Review

Model: 066257N7N0020
From the Transitional Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$257.50
$152.40
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WESLOCK ADDY ESCUTCHEON DUMMY DEADBOLT OVERVIEW

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.



Standard features

  • Dummy Exterior and Interior Handle set, with a non-active thumb press
  • Standard 5 1/2" center to center door prep
  • Fits 1-3/8" to 2-1/4" door thickness & with a adjustable foot screw
  • Exposed screws for easy install
  • Pair with active Brookside handle set version on double door
  • Limited 25 Year Mechanical Warranty
  • Limited 5 Year Finish Warranty
  • 25 Year Limited Mechanical Warranty
  • 5 Year Limited Finish Warranty



DOWNLOADS & RESOURCES

Weslock Catalog

Weslock General Specifications

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Transitional Series
Warranty:
Limited 25 Year Mechanical, Limited 5 Year Finish
Collection:
Transitional
Keyed:
No
Cross Bore:
2-1/8"
Product Subgroup:
Bored Locksets
Product Type:
Handlesets
Subcategory:
Residential Handlesets
Commercial/Residential:
Residential
Keyed Function:
Non-Keyed
Lock Function:
Dummy
IMAP Policy:
Yes
Product Function:
Dummy
Product Dimension:
11" length x 2.8" width with a 2.5" projection
Product Category:
Mechanical Locks
Product Substrate:
Zinc Alloy
Department:
Door Hardware

Weslock 066257N7N0020 – Frequently Asked Questions

1) Does the Weslock 6625 Addy dummy handleset actually latch, or is it just trim?
It's trim only. The Addy 6625 is a dummy set, exterior and interior handle with a non-active thumb press, so nothing retracts and nothing locks. It's non-keyed. Use it on an inactive leaf of a double door, a closet or pantry door, or anywhere you want the handleset look without a working latch. If you need the door to latch or lock, this is the wrong part.
2) Will the Weslock Addy handleset fit my door thickness?
The Addy 6625 covers 1-3/8 inch through 2-1/4 inch doors, using an adjustable foot screw to take up the range. That spans standard 1-3/4 inch entry doors as well as thicker custom slabs, so it's a wider range than most residential handlesets carry.
3) What door prep does the Weslock 6625 Addy need, and will it cover my existing holes?
Standard 5-1/2 inch center-to-center prep with a 2-1/8 inch cross bore. That's the common residential handleset layout, so if your door was previously prepped for a 5-1/2 inch CTC handleset with a 2-1/8 inch bore, the Addy drops onto the same holes. If your door is bored for a knob or lever only, you'll need the second bore added for the handleset spacing.
4) What do I pair with the Addy dummy handleset on a double door?
Weslock specifies the active Brookside handleset for the working leaf, with the Addy dummy on the inactive leaf. That's the intended pairing, so the two leaves read the same from the street while only one operates.
5) I need a keyed entry handleset, not a dummy. What are my options?
The Addy 6625 will not lock, so look at a keyed set. The Schlage Residential F60 Addison with Accent lever is a single cylinder keyed entry handleset fitting 1-3/8 to 1-3/4 inch doors, the Pamex FS7P31 Lexington single cylinder handleset covers the same 1-3/8 to 1-3/4 inch range in satin nickel, and the Baldwin Estates 6542 Tremont is entrance mortise trim for 1-3/4 inch doors in single or double cylinder. If your door is thicker than 1-3/4 inches, the Yale Assure Lock deadbolt with Ridgefield handleset covers 1-3/4 to 2-1/4 inches.
6) What is the closest dummy handleset to the Weslock 6625 Addy from another brand?
The Weslock 6625 Addy is a dummy-function handleset, meaning the exterior thumb press is non-active and there is no latch or bolt operation. Emtek's brass mortise entrance handlesets in dummy function cover the same job: the 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan are all listed as dummy function. The difference is styling and material family - the Addy is zinc alloy with a Philtower lever, while the Emtek 3002 through 3006 are brass and carry the Memphis, Hamilton, Melrose, and Manhattan trim designs. If the door needs a non-operating handleset for an inactive leaf or a fixed panel, any of those four are the direct cross-brand equivalents.
7) I need a handleset that actually locks, not a dummy. What should I order instead of the Weslock 6625 Addy?
The 6625 Addy is non-keyed, dummy function - it will not secure an opening. For a keyed exterior door, the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever is Grade 2 and fits 1-3/8 inch to 1-3/4 inch doors. The Kwikset 687AMD Amador single cylinder handleset is Grade 3 for 1-3/4 inch doors, offered with SmartKey as the 687AMD SMT and with SC1 keyway SmartKey as the 687AMD SMC. The Master Lock HDLBA0615/4D is a Grade 2 single cylinder deadbolt handleset. Any of these replace the Addy where an entry door needs to lock; the Addy is for the inactive side of a pair or a fixed panel.
8) My doors are 2 inches thick. Will the Weslock 6625 Addy fit, or do I need something else?
The Weslock 6625 Addy fits 1-3/8 inch to 2-1/4 inch door thickness with an adjustable foot screw, so a 2 inch door is inside its range. Most residential handlesets are narrower: the Schlage F60 Addison and the JE285 Barcelona both stop at 1-3/4 inch, the Kwikset 687BW Belleview and 687AMD Amador are listed at 1-3/4 inch, and the Pamex FS7P31 Lexington covers 1-3/8 inch to 1-3/4 inch. On thick doors the peers that reach the same territory are the Yale Real Living Assure handlesets - the BYRD226CBARX and BYRD226NRRX cover 1-3/4 inch to 2-1/4 inch, and the BYRD410BLERX covers 1-3/8 inch to 2-1/4 inch - though those are electronic deadbolt handlesets rather than dummies.
9) What is the difference between a non-keyed handleset like the Schlage JE285 and the Weslock 6625 Addy dummy?
Both are non-keyed, but they are not the same function. The Weslock 6625 Addy is dummy function with a non-active thumb press - nothing moves a latch, and it is surface mounted to a door leaf that does not need to operate. The Schlage Residential JE285 Barcelona handleset with Seville lever is listed as non-keyed entry function, Grade 2, for 1-3/8 inch to 1-3/4 inch doors - it has a working latch that retracts, it just has no key cylinder. If the leaf needs to open and close and only the locking is unnecessary, the JE285 is the right part; if the leaf is fixed or held by flush bolts, the Addy is.
10) How much does the Weslock Addy handleset stick out from the door face?
Projection is 2.5 inches, with the plate measuring 11 inches in length by 2.8 inches in width. Worth checking against a storm door or screen door swing, and against any sidelight trim or stop the grip could foul.
11) Is the Weslock Addy handleset suitable for a commercial building or an apartment entry?
It's a residential-rated set in zinc alloy, built for single-family and light-duty openings. For a leased commercial entry or a high-traffic multi-family door you want a graded product instead. The Schlage Residential F60 Addison handleset and the Master Lock HDLB Series single cylinder deadbolt handleset are Grade 2, and the Kwikset 687 Amador exterior handleset is Grade 3.
12) What other dummy handlesets are there besides the Weslock Addy?
Emtek's brass mortise handleset trim comes in four dummy styles: the 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan. Those are solid brass rather than the Addy's zinc alloy. Design difference aside, the practical split is prep: the Addy is a bored-lockset handleset on 5-1/2 inch centers with a 2-1/8 inch cross bore, so check what your door is already machined for before you switch families.
13) Is the Philtower lever on the Weslock 6625 handed left or right?
Being a dummy, there's no latch and no handing to specify. Both the exterior grip and the interior Philtower lever are fixed, so the same part works on a left-hand or right-hand door. Orientation is only about which leaf you mount it on.
14) Can I use the Weslock 6625 Addy on a double door with an active handleset on the other leaf?
Yes - the 6625 Addy is intended to pair with the active Brookside handleset version on a double door, with the Addy carrying the dummy side. If you would rather build the pair from a single other brand, Emtek offers the dummy half in its brass mortise handlesets - the 3002 Memphis, 3004 Hamilton, 3005 Melrose and 3006 Manhattan are all dummy function. Among keyed handlesets that would serve as the active leaf, the Schlage F60 Addison with Accent lever is Grade 2, and the Baldwin Estates 6542 Tremont mortise entry trim comes in single cylinder and double cylinder for 1-3/4 inch doors.
15) Is the Baldwin Wesley handleset a substitute for the Weslock 6625 Addy?
No. The Baldwin Wesley handleset is entrance function, sold with an Alcott knob as the 180WYHXATK or a Carnaby knob as the 180WYHXCYK - it operates a latch and is built for an active door. The Weslock 6625 Addy is dummy function with a non-active thumb press and a lever rather than a knob. The similar name is the only thing they share. If you want an operating Baldwin handleset the Wesley is the right family; if you need the fixed, non-operating half, stay with a dummy such as the Addy or the Emtek 3006 Manhattan.
16) What handleset should I use if I want a keypad or smart lock instead of a mechanical dummy?
The Weslock 6625 Addy is a mechanical, non-keyed dummy with no electronics. For an electronic exterior handleset, the Kwikset 815SCEHFL-CP913CNT San Clemente handleset with Halifax lever interior trim pairs a contemporary SmartCode keypad electronic deadbolt with an RCAL latch and RCS strike, Signature Series, for 1-3/4 inch doors. Yale Real Living covers touchscreen options: the BYRD226NRRX Assure standalone touchscreen deadbolt with Ridgefield handleset, the BYRD226CBARX with Wi-Fi and Bluetooth, and the BYRD256 CBARX key-free Wi-Fi touchscreen deadbolt with Ridgefield passage handleset, all for 1-3/4 inch to 2-1/4 inch doors.
17) I want a solid brass handleset rather than zinc. What are the options?
The Weslock 6625 Addy is zinc alloy. For solid brass, Deltana lists several entry handlesets: the 803871B Hanover, the 815871 St. Ann, and the 825871 Kingston are all solid brass entry function. The Deltana 810871 Montego handleset fits 1-3/8 inch to 2 inch doors. Emtek's dummy handlesets - the 3002 Memphis, 3004 Hamilton, 3005 Melrose and 3006 Manhattan - are brass mortise handlesets in dummy function, which is the brass route if the function needs to stay non-operating like the Addy.
18) If I only need the exterior half of a handleset, is the Weslock 6625 Addy the right part?
No - the 6625 Addy is a complete dummy set with both exterior and interior handles, so you would be buying an interior trim you do not need. For exterior-only, Kwikset lists the 687AMD Amador single cylinder keyed entry handleset exterior only in two SmartKey versions, the 687AMD SMT and the 687AMD SMC with SC1 keyway, and the 687BW Belleview SMT single cylinder keyed entry handleset exterior only - all Grade 3 for 1-3/4 inch doors. Those let you keep existing interior trim.
19) What finishes does the Weslock 6625 Addy handleset come in?
Three: Satin Nickel, Oil Rubbed Bronze, and Matte Black. If you're matching an inactive leaf to an active Brookside set already on the building, order both in the same finish code from the same run where you can, since finish batches on plated and living finishes are not always identical.
20) Does the Addy dummy handleset mount with visible screws?
Yes, exposed screws, which Weslock calls out as making install straightforward. Note that the brand's concealed-screw treatment appears elsewhere in the line, so if a fastener-free face is the requirement on a front door, the Addy isn't it.
