Weslock 6625 Addy Escutcheon Dummy with Utica Lever

Weslock 6625 Addy Escutcheon Dummy with Utica Lever

(No reviews yet) Write a Review

Model: 066253N3N0020
From the Transitional Collection
Selected Finish is
Selected Trim Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$257.50
$135.20
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WESLOCK ADDY ESCUTCHEON DUMMY DEADBOLT OVERVIEW

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.



Standard features

  • Dummy Exterior and Interior Handle set, with a non-active thumb press
  • Standard 5 1/2" center to center door prep
  • Fits 1-3/8" to 2-1/4" door thickness & with a adjustable foot screw
  • Exposed screws for easy install
  • Pair with active Brookside handle set version on double door
  • Limited 25 Year Mechanical Warranty
  • Limited 5 Year Finish Warranty
  • 25 Year Limited Mechanical Warranty
  • 5 Year Limited Finish Warranty

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Transitional Series
Warranty:
Limited 25 Year Mechanical, Limited 5 Year Finish
Collection:
Transitional
Keyed:
No
Cross Bore:
2-1/8"
Product Subgroup:
Bored Locksets
Product Type:
Handlesets
Subcategory:
Residential Handlesets
Commercial/Residential:
Residential
Keyed Function:
Non-Keyed
Lock Function:
Dummy
IMAP Policy:
Yes
Product Function:
Dummy
Product Dimension:
11" length x 2.8" width with a 2.5" projection
Product Category:
Mechanical Locks
Product Substrate:
Zinc Alloy
Department:
Door Hardware

Weslock 066253N3N0020 – Frequently Asked Questions

1) Does the Weslock 6625 Addy dummy handleset actually latch, or is it just trim?
It is trim only. The Addy escutcheon dummy is a non-keyed dummy set with a non-active thumb press, exterior and interior handles, no latch and no bolt. Use it on an inactive door leaf of a pair, a closet door, or a French door slab that is held by a roller catch or flush bolts. If you need the door to latch or lock, you need an active entrance handleset instead.
2) What door prep does the Weslock 6625 Addy dummy need, and can it go into an existing handleset prep?
It uses the standard 5-1/2 inch center-to-center handleset prep with a 2-1/8 inch cross bore. If the door already has a 5-1/2 inch centers handleset prep, the Addy dummy drops straight in with no new boring. On a door bored only for a knob or lever, you get the 2-1/8 inch cross bore but you still have to add the second bore at 5-1/2 inch centers.
3) I need a pair of French doors done with one working handle and one dummy. What do I order with the Weslock 6625 Addy?
Pair the Addy escutcheon dummy on the inactive leaf with the active Brookside handleset version on the leaf that works. Both sit on the same 5-1/2 inch centers prep, so the two leaves read identically from the street while only one of them operates.
4) Is the Weslock 6625 Addy handleset rated for commercial use?
No. The Addy is a residential handleset in zinc alloy. For a commercial opening, apartment corridor, or anything taking real traffic, go to graded hardware instead, such as the Grade 2 Schlage Residential F60 Addison keyed entry handleset with Accent lever or the Grade 2 Master Lock HDLB series single cylinder deadbolt handleset.
5) What is the closest dummy handleset to the Weslock 6625 Addy if a different style is wanted?
The Weslock 6625 Addy is a dummy-function handleset with the Utica lever, non-keyed, with a non-active thumb press. In the same dummy function, Emtek offers four brass mortise entrance handlesets: the 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan. All four carry a dummy product function, so any of them fills the same role on an inactive leaf or a closet door where the trim only needs to be pulled, not latched. The difference is the design family and the brass body rather than the function.
6) The 6625 Addy dummy will not lock the door - what handleset should be ordered for the active leaf instead?
The 6625 Addy is a dummy, meaning both handles are inoperable and there is no cylinder. For the leaf that actually has to secure, a keyed entrance handleset is the substitute: the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever is an entrance function Grade 2 unit fitting 1-3/8 to 1-3/4 inch doors, and the Kwikset 687AMD Amador single cylinder handleset is a Grade 3 entrance unit for 1-3/4 inch doors. The Baldwin Wesley handleset is also entrance function, offered with the Alcott knob or the Carnaby knob as interior trim.
7) What looks like a substitute for the Weslock 6625 Addy dummy but is not?
The Yale Real Living Ridgefield handlesets read as handlesets but carry an electronic deadbolt: the BYRD226NRRX is a standalone touchscreen deadbolt with Ridgefield handleset and the BYRD226CBARX is the Wi-Fi and Bluetooth version, both for 1-3/4 to 2-1/4 inch doors. The BYRD256 CBARX pairs a key free touchscreen deadbolt with a Ridgefield passage handleset. The Weslock 6625 Addy is a non-keyed dummy with no bolt and no electronics, fitting 1-3/8 to 2-1/4 inch doors. Swapping one for the other changes the door from unsecured trim to a powered locking opening and requires a deadbolt bore.
8) What should be used instead of the Weslock 6625 Addy on a mortise-prepped door?
The Weslock 6625 Addy uses a 2-1/8 inch cross bore and a 5-1/2 inch center to center prep, which is bored-door prep. On a door prepared for mortise trim, the Baldwin Estates 6542 Tremont entry mortise trim is the alternative, offered in single cylinder and double cylinder entrance versions for 1-3/4 inch doors. The Emtek 3002 Memphis and 3006 Manhattan are brass mortise handlesets in dummy function if the mortise-prepped door only needs inactive trim.
9) How much does the Weslock Addy handleset stick out from the door face?
Projection is 2.5 inches, on an escutcheon measuring 11 inches by 2.8 inches. That projection is what matters if the door swings toward a return wall, a sidelite, or a storm door, since the grip has to clear before the door opens fully.
10) I ordered a dummy handleset by mistake and need a keyed entry one. What replaces the Weslock Addy on the same door?
You need an entrance-function handleset. On a 1-3/8 to 1-3/4 inch door, the Schlage Residential F60 Addison with Accent lever or the Pamex FS7P31 Lexington single cylinder handleset both cover that range. If the door is 1-3/4 inch flat, the Kwikset 687AMD Amador single cylinder handleset with SmartKey is an option. Note the Addy dummy goes up to 2-1/4 inch doors, so on a thick slab check the entrance set's range before swapping.
11) Do I need to worry about handing when ordering the Weslock 6625 Addy dummy?
No handing to specify. It is a non-keyed dummy with no latch, no strike, and no cylinder, so there is nothing that has to be oriented left or right. The only choices on the order are finish and the Utica lever trim.
12) The Weslock 6625 Addy is residential zinc alloy - what solid brass handleset is comparable?
The Weslock 6625 Addy Addy escutcheon dummy is a zinc alloy residential unit. For a solid brass body, Deltana offers entry handlesets in several series: the 803871B Hanover, the 815871 St. Ann, and the 825871 Kingston, all solid brass entry function. The Emtek 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan are brass mortise handlesets in dummy function, which is the brass option that matches the Addy's non-operating role.
13) Is there a non-keyed handleset alternative to the Weslock 6625 Addy that still operates the latch?
Yes. The Weslock 6625 Addy has a non-active thumb press, so nothing retracts. The Schlage Residential JE285 Barcelona style handleset with Seville lever is a non-keyed unit in the J Series, Grade 2, for 1-3/8 to 1-3/4 inch doors, so it gives the handleset look with working trim and no cylinder to key. Choose between them by whether the door needs to latch or is purely decorative.
14) Which handlesets fit the same door thicknesses as the Weslock 6625 Addy?
The Weslock 6625 Addy fits 1-3/8 inch to 2-1/4 inch doors using an adjustable foot screw, which is a wide span. Among comparable handlesets, the Deltana 810871 Montego covers 1-3/8 to 2 inch, and the Pamex FS7P31 Lexington and the Schlage Residential F60 Addison cover 1-3/8 to 1-3/4 inch. On the thick end, the Yale Ridgefield BYRD226NRRX covers 1-3/4 to 2-1/4 inch. For a door outside 1-3/8 to 1-3/4, confirm the range before substituting.
15) For a facility that specifies a graded handleset, which comparable products carry an ANSI grade?
The Weslock 6625 Addy is a residential dummy. Where a graded product is required on the drawing, the Schlage Residential F60 Addison keyed entry handleset and the JE285 Barcelona non-keyed handleset are Grade 2, as is the Master Lock HDLBA0615/4D single cylinder deadbolt handleset in the HDLB Series. The Kwikset 687AMD Amador and 687BW Belleview single cylinder handlesets are Grade 3 entrance units. Because the Addy is a dummy with no latch or bolt, a graded entrance product is a different function, not a like-for-like swap.
16) If a keypad or keyless handleset is wanted on the same opening as the Weslock 6625 Addy dummy, what are the options?
The Addy dummy is non-keyed with no bolt, so it pairs with an active unit rather than replacing one. For an electronic active leaf, the Kwikset 815SCEHFL-CP913CNT San Clemente handleset carries a contemporary SmartCode keypad electronic deadbolt with Halifax lever interior trim, in the Signature Series for 1-3/4 inch doors. The Yale Real Living BYRD256CBARX Assure Lock 2 is a key free touchscreen deadbolt with Wi-Fi and a Ridgefield handleset for 1-3/8 to 2-1/4 inch doors. Both need a deadbolt bore that the dummy does not require.
17) Is an interconnected lock an alternative to the Weslock 6625 Addy on an apartment entry door?
They solve different problems. The Weslock 6625 Addy is a dummy, so it neither latches nor locks. The Schlage Residential JI18/19 interconnected unit in the JI Series is a passage lock with a keyed deadbolt and Torino lever in satin stainless steel, Grade 2, for 1-3/8 to 1-3/4 inch doors, which is the common multi-family entry configuration because one motion retracts both. Use the Addy only where the trim is decorative, such as the inactive leaf of a pair.
18) What finishes does the Weslock Addy dummy with Utica lever come in?
Three: Satin Nickel, Oil Rubbed Bronze, and Matte Black, all with the Utica lever interior trim. If you are matching existing openings in a building, those are the three to hold against what is already hung.
19) Are the mounting screws on the Weslock Addy handleset visible after install?
Yes, the Addy mounts with exposed screws. That makes the install straightforward and the set easy to pull later if you rekey or re-trim the opening, but if you want a clean escutcheon face with nothing showing, this is not that set.
20) Which comparable handleset comes in satin nickel to match the Weslock 6625 Addy?
The Weslock 6625 Addy with Utica lever is offered in satin nickel, oil rubbed bronze, and matte black. Among comparable handlesets, the Pamex FS7P31 Lexington single cylinder handleset is supplied in satin nickel finish, so it can be paired with a satin nickel Addy dummy where the active leaf needs a keyed unit and the inactive leaf needs matching trim.
