Weslock 7645 Tramore Dummy Handleset with Carlow Lever

Weslock 7645 Tramore Dummy Handleset with Carlow Lever

(No reviews yet) Write a Review

Model: R7645H1H10020
From the Molten Bronze Collection
$353.00
$208.50
Selected Finish is
Selected Trim Design is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$353.00
$208.50
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Weslock TRAMORE DUMMY DEADBOLT HANDLE

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.


Standard features

  • Exceeds ANSI A 156.2 Grade II Lock standards
  • Solid Molten Brass
  • Removable knob/lever prevents scratching during installation
  • Heavy Duty Security Strikes with 3” screws
  • Dummy - Inactive Lock for Inactive Door, all parts rigid
  • Adjusts to door thickness from 1-3/4” - 2”
  • Limited Lifetime Mechanical Warranty
  • Limited 10 Year Finish Warranty


Weslock Catalog

Weslock General Specifications

Installation Instructions

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Molten Bronze Series
Warranty:
Limited Lifetime Mechanical and Limited 10 Year Finish
Collection:
Molten Bronze
Cross Bore:
2-1/8"
Keyed Function:
Non-Keyed
Product Subgroup:
Bored Locksets
Product Type:
Handlesets
Subcategory:
Residential Handlesets
Keyed:
No
Commercial/Residential:
Residential
Lock Function:
Dummy
IMAP Policy:
Yes
Product Function:
Dummy
Door Thickness Range:
1-3/8" to 2"
Product Style:
Tramore
Product Category:
Mechanical Locks
Product Substrate:
Brass
Department:
Door Hardware

Weslock R7645H1H10020 – Frequently Asked Questions

1) Does the Weslock 7645 Tramore handleset actually latch or lock the door?
No. The Tramore 7645 is a dummy handleset, meaning it is an inactive trim set with all parts rigid, intended for an inactive door leaf. There is no latch, no deadbolt mechanism and no key cylinder (it is non-keyed). It mounts as a pull and matching interior lever only, so the door needs a separate flush bolt, surface bolt or roller catch to hold it shut.
2) Why does a dummy handleset need a hand specified?
Handing matters because the Tramore handleset with Carlow lever is an active-looking trim set with a thumbpiece and lever that must point the correct way on the door. It is offered in left hand and right hand, so pick the one that matches the leaf the trim is going on. Order the wrong hand and the lever and grip sit backwards.
3) Will the Weslock 7645 fit a 1-3/4 inch door, and what about a thicker one?
Yes on 1-3/4 inch, which is the standard exterior door thickness. The 7645 covers 1-3/8 inch through 2 inch, so it also handles thicker custom entry slabs up to 2 inches without a special kit. Below 1-3/8 inch it is out of range.
4) What door prep does the Tramore dummy handleset need?
A 2-1/8 inch cross bore is the prep called out for the 7645. That is the same bore as a standard tubular lockset, so an existing door already drilled for a handleset or lockset usually takes it. Installation screws are concealed once assembled, and the knob/lever is removable during install so the finish does not get scratched.
5) I have a double entry door. Which leaf gets the dummy and what goes on the active side?
The dummy goes on the inactive leaf, the one held by flush bolts, since it has no working latch. The active leaf needs a keyed or entry-function handleset in a matching style. If you want the same look across the pair, keep both in Weslock's Molten Bronze Tramore style with Carlow lever trim so the escutcheon, grip and lever profile match.
6) My door is 2 inches thick and most handlesets don't fit. What works?
The Weslock 7645 Tramore adjusts up to 2 inches, so it covers that slab. Among other handlesets we carry, the Deltana 810871 Montego also spans 1-3/8 to 2 inches. Schlage's residential F and J series and the Pamex FS7P31 stop at 1-3/4 inches, so those are out on a 2 inch door.
7) What is the closest alternative to the Weslock 7645 Tramore dummy handleset if I need another brand's dummy handleset for an inactive door?
The Weslock 7645 Tramore is a dummy function handleset, meaning all parts are rigid and there is no latch operation. Emtek's dummy mortise entrance handlesets cover the same role in other styling: the 3002 Memphis, 3004 Hamilton, 3005 Melrose, and 3006 Manhattan are all cataloged as dummy function brass mortise entrance handlesets. If the inactive leaf of a pair of doors just needs a gripping handle and matching trim, any of those four fills the same job as the Tramore.
8) I ordered the Weslock 7645 Tramore but the door actually needs to lock. What should I order instead?
The 7645 Tramore is non-keyed and dummy function, so it will not secure anything. For a keyed opening, the Schlage Residential F60 Addison single cylinder keyed entry handleset with Accent lever is a Grade 2 entrance handleset for doors 1-3/8 inch to 1-3/4 inch thick. Kwikset's 687AMD Amador and 687BW Belleview single cylinder handlesets are Grade 3 entrance units for 1-3/4 inch doors and ship as exterior trim only. Master Lock's HDLBA0615/4D is a Grade 2 single cylinder deadbolt handleset.
9) My door is thicker than 2 inches - the Weslock 7645 will not fit. What handleset covers that?
The Weslock 7645 Tramore adjusts to doors 1-3/8 inch through 2 inch. For thicker slabs, the Yale Real Living Assure handlesets with Ridgefield trim cover 1-3/4 inch to 2-1/4 inch, including the BYRD226CBARX Wi-Fi and Bluetooth touchscreen deadbolt version and the BYRD226NRRX standalone touchscreen version. Note those are electronic keyed deadbolt handlesets rather than a rigid dummy, so the opening has to be one that accepts a locking function.
10) Is a passage or non-keyed entry handleset the same thing as the Weslock 7645 Tramore dummy?
No. The 7645 Tramore is a dummy - all parts are rigid, nothing retracts, and it mounts to an inactive door. A non-keyed handleset such as the Schlage Residential JE285 Barcelona with Seville lever is a Grade 2 unit with a working latch for doors 1-3/8 inch to 1-3/4 inch; it operates without a key but the door still latches. Schlage's JI18/19 is a passage lock interconnected with a keyed deadbolt, also Grade 2. Order the dummy only where the leaf stays fixed.
11) Is this handleset rated for commercial use?
No, the Molten Bronze Series Tramore is classed as residential hardware. Weslock states it exceeds ANSI A156.2 Grade II lock standards, which is a respectable residential and light-duty rating, but for a commercial opening with traffic and code requirements you want a Grade 1 commercial lockset instead.
12) What are my alternatives if I need a dummy handleset in a different look?
Emtek's brass mortise dummy handlesets cover the same job in other designs: the 3002 Memphis, 3004 Hamilton, 3005 Melrose and 3006 Manhattan are all dummy function. If instead you need the active side of the opening, look at keyed entry handlesets such as the Schlage F60 Addison with Accent lever or the Kwikset 687 Amador.
13) The Weslock 7645 Tramore comes with a Carlow lever. What if I want a knob instead?
The Weslock 7645 Tramore Tramore-style handleset is paired with the Carlow lever as its interior trim. For knob interior trim on a handleset, Baldwin's Wesley handleset is offered as the 180WYHXATK with the Alcott knob and the 180WYHXCYK with the Carnaby knob, both entrance function. Those are keyed entrance units rather than dummies, so use them where the door operates.
14) What solid brass handleset alternatives are there to the Weslock 7645 Tramore if I want a different style in the same material?
The Weslock 7645 Tramore is built from brass in the Molten Bronze collection. Deltana offers several solid brass handlesets in other styling: the 803871B Hanover, 815871 St. Ann, and 825871 Kingston are all solid brass entry handlesets, and the 810871 Montego covers the same 1-3/8 inch to 2 inch door thickness range as the Tramore. The Deltana units are entry function rather than dummy, so they are a style swap only where the door needs to latch.
15) I need a handleset for a door where the backset is not confirmed yet. Is the Weslock 7645 Tramore adjustable?
The Weslock 7645 Tramore is a bored dummy handleset with a 2-1/8 inch cross bore and no latch, so backset is not the governing dimension the way it is on a functioning lock. If you need a working handleset that can land on either backset without a second order, the Sure-Loc handlesets are built with an adjustable backset - the AN507 Aspen single cylinder keyed entry, MA507 Madison keyed entry, AT507 Alta tubular, and CR507 Coral.
16) Can I use the Weslock 7645 Tramore on a mortise-prepped door?
The Weslock 7645 Tramore is a bored lockset with a 2-1/8 inch cross bore, so it expects a standard bored door prep. For a door already prepped for mortise trim, look at the Baldwin Estates 6542 Tremont entry mortise trim, offered in single cylinder and double cylinder versions for 1-3/4 inch doors. Emtek's 3002, 3004, 3005 and 3006 are mortise entrance handlesets in dummy function if you need the fixed-leaf equivalent on a mortise door.
17) I want a keypad handleset instead of the Weslock 7645 Tramore for a rental turn. What are the options?
The Weslock 7645 Tramore is a non-keyed dummy with no locking mechanism at all. For keyless code entry, the Kwikset 815SCEHFL-CP913CNT San Clemente handleset pairs a Halifax lever interior with a contemporary SmartCode keypad electronic deadbolt for 1-3/4 inch doors. Yale's BYRD256 CBARX Assure key free touchscreen deadbolt with Ridgefield passage handleset is a Wi-Fi unit for doors 1-3/4 inch to 2-1/4 inch.
18) Does the Weslock Tramore dummy handleset come with a strike?
Weslock ships heavy duty security strikes with 3 inch screws as a standard feature of these sets. Bear in mind the dummy itself has no latch to engage a strike, so on an inactive leaf your holding hardware is flush or surface bolts, which are ordered separately.
19) Which handleset should I use on a 1-3/8 inch door if the Weslock 7645 Tramore does not fit my function needs?
The Weslock 7645 Tramore itself covers 1-3/8 inch through 2 inch as a dummy. If you need a latching unit on a 1-3/8 inch door, the Pamex FS7P31 Lexington single cylinder entry handleset in satin nickel covers 1-3/8 inch to 1-3/4 inch, and the Schlage Residential JE285 Barcelona with Seville lever covers the same range as a non-keyed entrance. The Deltana 810871 Montego matches the Tramore's full 1-3/8 inch to 2 inch range.
