Weslock 7900 Left Hand Carlow ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$127.00
$92.56
Weslock 7900 Left Hand Carlow Interior Single Cylinder Handleset Trim for Greystone or Rockford

Weslock 7900 Left Hand Carlow Interior Single Cylinder Handleset Trim for Greystone or Rockford

(No reviews yet) Write a Review

Model: L7900--H2SL20
From the Molten Bronze Collection
$127.00
$92.56
Selected Free Keying Option is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$127.00
$92.56
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

WESLOCK ROCKFORD SINGLE CYLINDER HANDLESET OVERVIEW

If security, safety, and style are important to you, then Weslock is your choice for quality hardware for your home. Not only are Weslock door handle and deadbolt products strong and long lasting, but they also offer a beautiful aesthetic for your home. With designs that enhance the look and feel of your home and details, such as concealed installation screws, that merge function and form, Weslock offers a product unmatched by the competition.



Standard features

  • 5-Pin Cylinder, Weslock keyway
  • Exceeds ANSI A 156.2 Grade II lock standards
  • Solid Molten Brass
  • 1” Throw bolt with two hardened steel rollers prevent sawing
  • Removable knob/lever prevents scratching during installation
  • Heavy Duty Security Strikes with 3” screws
  • Fits doors prepared with 2-1/8” top (1-5/8“ optional) and 2-1/8” bottom cross holes and 1” edge hole
  • 5-1/2” minimum center to center cross hole spacing
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Optional door thickness up to 2-1/4”
  • Adjusts to door thickness from 1-3/4” - 2”
  • Limited Lifetime Mechanical Warranty
  • Limited 10 Year Finish Warranty



DOWNLOADS & RESOURCES

Weslock Catalog

Weslock General Specifications

Installation Instruction

Manufacturer Resources

Product Specs

Product Group:
Mechanical Locks
Series:
Molten Bronze
Warranty:
Limited Lifetime Mechanical and Limited 10 Year Finish
Latch Faceplate:
1" x 2-1/4"
Collection:
Molten Bronze
Cross Bore:
2-1/8"
Keyed:
Yes
Product Subgroup:
Bored Locksets
Product Type:
Interior Trim Only
Subcategory:
Residential Handlesets
Keyed Function:
Single Cylinder
Commercial/Residential:
Residential
Cylinder and Keyways:
5 Pin Cylinder, Weslock Keyway
Lock Function:
Entry
IMAP Policy:
Yes
Backset (Distance):
2-3/8 or 2-3/4
Product Function:
Single Cylinder
Door Thickness Range:
1-3/4" to 2"
Door Strike:
2-1/4" full lip and 1" x 2-1/4", Radius & Square
Product Style:
Rockford
Product Substrate:
Brass
Product Category:
Mechanical Locks
Department:
Door Hardware

Weslock L7900--H2SL20 – Frequently Asked Questions

1) Is the Weslock 7900 Carlow interior trim a complete handleset, or just the inside half?
Inside half only. The Weslock 7900 Carlow is interior trim for a single cylinder handleset, meant to pair with a Greystone or Rockford exterior handleset. If you need the outside handle too, order the exterior handleset separately. The function is entry, keyed with a single cylinder.
2) Does the Weslock Carlow lever trim come in left hand and right hand?
Handing matters on this one. The Carlow lever interior trim is the left hand version, so stand outside the door: if the hinges are on your left, left hand is correct. A right hand opening needs the right hand trim instead.
3) What door prep does the Weslock 7900 handleset trim need?
It goes on a door bored with 2-1/8 inch cross holes and a 1 inch edge bore, with a minimum of 5-1/2 inches center to center between the top and bottom cross holes. A 1-5/8 inch top cross hole is also accommodated. The latch adjusts for either a 2-3/8 or 2-3/4 inch backset, so you do not have to know which backset your door was drilled for before ordering.
4) Can I key this Weslock handleset trim to match my other Weslock locks?
Yes, within the Weslock keyway. It uses a 5 pin cylinder on the Weslock keyway, and you choose keyed different or keyed alike when ordering, with a field for a specific key code. Keyed alike is how you get one key for several openings on the same house. It will not key into a Kwikset or Schlage system, since the keyway is different.
5) What are my options if I have a Kwikset or Schlage handleset instead of a Weslock?
Interior handleset trim is brand specific, so match the maker of your exterior handleset. For Kwikset Signature Series 800 and 687 outside trim, the Kwikset 966BRL-LH Brooklane lever left hand interior trim is a Grade 2 entry equivalent, and the 966BRNL-SQT Breton lever with square rose fits the same 687 and 800 series. On the Schlage residential side, the JH59 Broadway lever inside trim with Collins deadbolt thumbturn covers handlesets on 1-3/8 to 1-3/4 inch doors.
6) What is the closest equivalent to the Weslock 7900 Carlow left hand interior single cylinder handleset trim from another brand?
The Kwikset 966BRL-LH Brooklane lever interior single cylinder handleset trim is the nearest match in intent: it is a left hand lever interior trim for a single cylinder handleset, rated Grade 2 with an entry function. The Weslock 7900 Carlow trim is also a single cylinder entry trim with a 5 pin Weslock keyway cylinder. The lever style differs - Carlow versus Brooklane - and the keyway follows each maker's own system, so keying the Kwikset into an existing Weslock key system is not possible.
7) I need an interior handleset trim that is not handed - what should I use instead of the left hand Weslock 7900 Carlow?
The Kwikset 966BRNL-SQT Breton lever trim is built as a universal design for 687 and 800 series outside trim, so it is not ordered by hand the way the Weslock 7900 Carlow left hand trim is. It is a Grade 2 entry trim with a square rose. The tradeoff is the escutcheon and lever styling, and that it is matched to Kwikset handleset bodies rather than the Weslock Greystone or Rockford exteriors the Carlow trim pairs with.
8) Is the Schlage F59 Accent interior pack a substitute for the Weslock 7900 Carlow single cylinder trim?
They are not interchangeable in function. The Weslock 7900 Carlow trim is a keyed single cylinder entry trim with a 5 pin Weslock keyway. The Schlage Residential F59 Accent lever interior pack carries a dummy function, meaning the lever does not operate a latch, so it does not deliver the entry operation the Carlow trim does. Use the F59 Accent only where a non-operating interior lever is wanted.
9) Will the latch drop into my existing strike, or do I have to rework the frame?
The kit ships with heavy duty security strikes in 2-1/4 inch full lip and 1 inch by 2-1/4 inch sizes, in both radius and square corners, so you can usually match what is already mortised into the jamb. The latch faceplate is 1 inch by 2-1/4 inch and the faceplates are removable. Strike screws are 3 inches so they bite the stud, not just the jamb.
10) Is this Weslock trim strong enough for a rental or is it only for homeowners?
It is a residential grade product. The Molten Bronze line is solid brass and the lock exceeds ANSI A156.2 Grade II standards, with a 1 inch throw deadbolt carrying two hardened steel rollers to resist sawing. That is appropriate for single family and small multi-family entries, but it is catalogued residential, not commercial, so a high traffic commercial opening wants a Grade 1 bored lock instead.
11) What is the difference between a single cylinder handleset trim and a double cylinder one?
Single cylinder means the deadbolt is keyed from the outside only and operated by a thumbturn on the inside, which is what this Weslock entry trim is built for. A double cylinder set is keyed on both sides, used where there is glass next to the door and you do not want a thumbturn reachable from outside. Choose based on glazing near the opening and your local egress rules.
12) Will a Schlage F59 interior pack work as a substitute for Weslock handleset trim?
No, and it is a common mix up. The Schlage F59 Accent interior pack is listed with a dummy function and a 1-5/8 to 1-3/4 inch door thickness range, so it is not a keyed entry trim for a Weslock Greystone or Rockford handleset. Interior trim has to come from the same maker and series as the outside handleset for the spindles and screw spacing to line up.
13) I need the interior side to have a thumbturn rather than a keyed cylinder - what replaces the Weslock 7900 Carlow trim?
The Weslock 7900 Carlow trim is a keyed single cylinder entry trim. If the interior should operate the deadbolt by thumbturn instead, the Schlage Residential JH59 Broadway lever inside trim for handlesets includes a Collins deadbolt thumbturn and is a Grade 3 entrance trim, and the Schlage Residential FC59 Alexandria glass knob trim pack also includes a deadbolt thumbturn at Grade 2. Both are matched to Schlage handleset exteriors.
14) What interior trim options are there if I want a knob instead of the Carlow lever?
The Weslock 7900 Carlow interior trim is a lever trim for the Greystone or Rockford handlesets. For a knob interior, the Kwikset 966AO Aliso and 966BL Balboa interior packs with deadbolt keyed one side are Grade 3 entrance trims for the Signature Series 800 and 687 handlesets, and the Schlage Residential FC59 Alexandria is a Grade 2 glass knob trim pack with a deadbolt thumbturn. Each is matched to its own brand's exterior handleset, so the choice follows whichever handleset body is on the door.
15) Which of these interior handleset trims meet a Grade 2 lock standard?
The Weslock 7900 Carlow trim exceeds ANSI A156.2 Grade 2 lock standards. Among the comparable interior trims, the Kwikset 966BRL-LH Brooklane and 966BRNL-SQT Breton are Grade 2, and the Schlage Residential F59 Accent and FC59 Alexandria packs are Grade 2. The Kwikset 966AO Aliso, 966BL Balboa, and Schlage JH59 Broadway are Grade 3. Grade matters most for institutional and multi-family specs that call out a minimum.
16) Will the installation screws show on the inside of the door?
No. The Weslock Molten Bronze trim uses concealed installation screws, so the inside rose and escutcheon present a clean face. The knob or lever is also removable during install so the finish does not get scratched while you are setting the lock.
