Wiremold RC3ATCGY RC3 Series Multi-Service Poke-Thru Assembly, Gray

Wiremold RC3ATCGY RC3 Series Multi-Service Poke-Thru Assembly, Gray

(No reviews yet) Write a Review

Model: RC3ATCGY

In Stock (leaves warehouse same day if ordered before 3pm ET)

$552.77
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Wiremold RC3ATCGY RC3 Series Multi-Service Poke-Thru Assembly, Gray

The Wiremold RC3ATCGY is a flush multi-service poke-thru assembly from the RC3 Series, engineered to deliver power and communications access directly through the floor at the point of need. Finished in Gray, this poke-thru device installs flush with the floor surface, providing a clean, low-profile solution for delivering electrical and low-voltage services to workstations, conference tables, and open-office furniture layouts without the need for surface-mounted raceway or unsightly cable runs. As part of the Wiremold RC3 platform, the RC3ATCGY is built to integrate with compatible RC3 Series poke-thru components for a coordinated, code-conscious floor-service installation.

Key Features

  • Flush Installation: Designed as a flush multi-service poke-thru device, allowing it to sit level with the finished floor for a clean, low-profile appearance and minimal trip-hazard exposure.
  • Multi-Service Capability: Supports multiple service types through a single floor penetration, simplifying the delivery of power and communications to furniture and workstations above.
  • RC3 Series Compatibility: Part of the Wiremold RC3 Series poke-thru platform, engineered for coordinated fit and function with other RC3 Series components.
  • Gray Finish: Finished in Gray to blend with common commercial flooring and furniture finishes.

Technical Specifications

  • Series: RC3
  • Type: Flush Multi-Service Poke-Thru Device
  • Color: Gray

Typical Applications

  • Open-Office Workstation Power & Data Access
  • Conference Room Table Floor Boxes
  • Commercial Floor-Service Installations
  • Renovation and New Construction Floor Wiring

Why Wiremold?

Wiremold is a recognized name in floor and surface electrical distribution systems, and the RC3 Series poke-thru platform is built to deliver coordinated, flush-mounted power and communications access for demanding commercial environments. Choosing the RC3ATCGY means specifying a component engineered to work within the broader Wiremold RC3 Series ecosystem for reliable, code-conscious floor-service delivery.

Manufacturer Resources

Spec Sheet

Product Specs

list_batch:
WIRE-20260924
Product Type:
Poke-Thru Device
Series:
RC3
Configuration:
Flush Multi-Service Poke-Thru
Department:
Electrical
Product Subgroup:
Floor Boxes
Product Color:
Gray
Product Group:
Boxes & Enclosures
Product Width:
7.5 in
Product Depth:
16 in
Product Material:
Steel
Product Weight:
5.247 lb
Product Height:
7.5 in

Wiremold RC3ATCGY – Frequently Asked Questions

1) How much floor opening and below-floor clearance does the Wiremold RC3ATCGY poke-thru need?
Plan the slab penetration and the space below it around the assembly's stated dimensions: 7.5 inches wide by 7.5 inches high by 16 inches deep. The 16 inch figure is the one that usually catches people out, since that depth has to clear ductwork, beams and ceiling systems under the slab. Verify your core location against those three numbers before you cut.
2) Can I run power and data through the same Wiremold RC3 poke-thru, or do I need two cores?
One core does both. The RC3ATCGY is a flush multi-service poke-thru, meaning power and low-voltage communications are carried through a single floor penetration and separated inside the assembly. That is the point of specifying a multi-service unit instead of a power-only device: fewer cores drilled in the slab for the same workstation feed.
3) Will a poke-thru like the RC3ATCGY stick up above the finished floor and create a trip hazard?
No. The RC3ATCGY is a flush device, so it sits level with the finished floor surface rather than standing proud of it. That makes it workable in open-office walkways, conference rooms and other circulation areas where a surface-mounted raceway or a raised box would be a problem.
4) Should I use a poke-thru or a cast-in floor box for workstation power in a concrete slab?
Poke-thrus like the RC3ATCGY are the retrofit answer: you core an existing slab and drop the assembly in, so they suit renovations and tenant fit-outs where the floor is already poured and furniture layouts have moved. A cast-in floor box has to be set before the pour, so it only works on new construction where the device locations are fixed early. If you are chasing a changed desk plan in an occupied building, the poke-thru is the one that does not require breaking out and repouring floor.
5) Will the RC3ATCGY work with other Wiremold RC3 poke-thru parts I already stock?
Yes, it is built on the RC3 platform and is intended to go together with other RC3 Series poke-thru components. For a property manager or MRO buyer already carrying RC3 parts, that means covers, inserts and accessories from the same series are the ones to pair it with rather than mixing series.
6) What is the Wiremold RC3ATCGY made of, and how heavy is it to handle on install?
Steel construction, 5.247 lb for the assembly. That is a one-hand lift for an electrician working off a lift or on their knees at the core, and the steel body is what lets it take foot traffic loading at floor level.
7) What color is the RC3ATCGY cover, and will it match other floor devices in the building?
Gray. It is the neutral choice for commercial carpet tile, VCT and sealed concrete, and it coordinates with the rest of the Wiremold RC3 Series so a facility standardizing on one platform gets a consistent look across openings. If you need the exact part on a reorder for matching, the manufacturer number is RC3ATCGY.
8) Where is the Wiremold RC3ATCGY manufactured? I have country-of-origin reporting on a government job.
Mexico. That is the stated country of origin for the RC3ATCGY, which is the figure to carry on submittal and procurement paperwork for public or institutional contracts that require it.
