Yale 2711 Series Door Closer, Tri-Packed (Regular, Parallle, Top Jamb Mount), Hold Open, Size 1-6

Accentra 2711 Series Architectural Door Closer with Hold Open Arm - Tri-Packed Surface Mount

(No reviews yet) Write a Review

Model: 2 711 689
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$450.45
$124.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra 2711 Series Architectural Door Closer with Hold Open Arm - Tri-Packed Surface Mount

Professional Commercial Door Control Solution

The Accentra 2711 Series Architectural Door Closer delivers reliable commercial-grade performance with adjustable spring sizes 1-6 and versatile tri-packed mounting options. This non-handed door closer features rugged aluminum construction with full plastic cover and rack and pinion operation for smooth, consistent door control. ANSI/BHMA Grade 3 certified for commercial applications requiring economical yet dependable door closing solutions.

Professional Features & Benefits

  • Adjustable spring sizes 1-6
  • Non-handed
  • Aluminum
  • Tri-packed: regular, parallel or top jamb mounting
  • Full plastic cover
  • Hold open and heavy-duty arms available
  • Sleeve nuts furnished standard with all models
  • Optional fasteners: Thrubolts and grommet nuts

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Accentra Quality?

Accentra 2700 Series door closers deliver professional-grade reliability with rugged aluminum construction and rack and pinion operation rated for commercial applications. ANSI/BHMA Grade 3 certification ensures compliance with building standards while adjustable spring sizing and comprehensive speed controls provide optimal performance tuning. Engineered for demanding commercial applications where dependable door control and ease of installation are essential.

Manufacturer Resources

2700 Series Door Closer

Product Specs

Series:
2700 Series
Product Group:
Door Controls
Product Subgroup:
Door Closers - Surface Mounted
Product Type:
Surface Mounted Door Closers
Subcategory:
Architectural Door Closers
Commercial/Residential:
Commercial
Product Model:
YAL-2700
Product Function:
Tri-Packed Hold Open Arm
Product Size:
Adjustable 1-6
Product Category:
Door Controls
Department:
Door Hardware

Accentra 2 711 689 – Frequently Asked Questions

1) Can the Accentra 2711 door closer be mounted parallel arm on the push side, or is it regular arm only?
All three mountings ship in the same box. The 2711 is tri-packed for regular arm (pull side), top jamb, and parallel arm (push side), so you decide at the door rather than at the order form. That matters on out-swinging exterior openings where the closer has to sit on the push side out of the weather, and in corridors where a pull-side closer body would stick into traffic. It is non-handed as well, so one unit covers a left or right hand door.
2) Is a Grade 3 door closer like the Accentra 2711 enough for a commercial entrance, or do I need Grade 1?
ANSI/BHMA Grade 3 is the light commercial tier, and the 2711 is built for interior and moderate traffic openings: offices, tenant suites, storage and back-of-house doors. A high-cycle main entrance or a heavy exterior door is where you step up. For Grade 1 in the same surface-mounted, tri-mount format, the Dexter DCH1000 Series and the Norton Rixson 8501A (Grade 1, adjustable size 1-6) are direct alternatives, and the BEST EHD9000 Series is the extra heavy-duty end of the range if the door takes real abuse.
3) Will one Accentra 2711 closer cover both a narrow interior door and a wider exterior door?
Spring power on the 2711 adjusts through sizes 1 through 6, which is the full practical range from a light interior door up to a wide or exterior door. For a property manager standardizing across a building that is the point of buying it: you stock one closer, then dial the spring at each opening instead of ordering a fixed size per door. Note that the size range is about door width and closing force, not door thickness.
4) Does the Accentra 2711 hold the door open, and can I use it on a fire door?
The 2711 comes with a hold open arm, so the door parks open at the point you set on the arm. That is what you want on a receiving door, a break room, or a move-in corridor. Do not put a mechanical hold open on a rated fire door assembly, which has to self-close and latch. For a rated opening use a non-hold-open arm instead: the Design Hardware 116 or 416 Series and the Orca BHDC1958RA/PA are tri-packed non-hold-open closers.
5) What is the closest equivalent to the Accentra 2711 door closer with hold open from another brand?
The Orca Hardware BHDC1958HO/PA is the nearest match. Like the Accentra 2711, it is a surface door closer with a tri-packed hold open arm, so the hold open function and the choice of regular, parallel, or top jamb mounting come the same way in the box. The Orca BHDC1958HO/PA is listed for 1-3/4 inch doors. Both close on hydraulic surface-mount hardware, so the opening prep is the same style of work either way.
6) I need a tri-mount closer but the door should not stay open - what do I order instead of the 2711?
On an opening where a held door is not wanted - a fire-rated corridor door, a stair door, an exterior door that has to latch every time - order a non-hold-open tri-pack instead. The Orca Hardware BHDC1958RA/PA is a tri-packed non-hold-open arm closer for 1-3/4 inch doors, and the Design Hardware 116 Series is a heavy duty tri-packed non-hold-open arm closer. Both give you the same regular, parallel, or top jamb mounting flexibility as the Accentra 2711 without the hold open feature in the arm.
7) The 2711 is Grade 3 - what Grade 1 surface closer should I spec for a high-traffic opening?
The Accentra 2711 carries ANSI/BHMA Grade 3 certification. When the opening or the spec calls for Grade 1, several surface closers meet it: the Norton Rixson 8501A is a Grade 1 tri-mount closer with an adjustable size 1-6 spring, matching the 2711's adjustable 1-6 sizing; the Dexter DCH1000 is a Grade 1 tri-mount closer with a full cover, mounting regular, parallel, or top jamb; and the Sargent 1431 Powerglide is a Grade 1 heavy duty surface closer with adjustable spring power. Grade 1 is the higher cycle-tested classification under ANSI/BHMA, which is what most institutional and government specs write in.
8) What surface closer holds up better than the 2711 on an exterior or heavy traffic door?
The Accentra 2711 is a Grade 3 aluminum-body closer sized 1-6. For a heavier opening - an exterior entrance, a wide or high-cycle door - step up to a heavy duty body. The BEST EHD9000 Series is an extra heavy-duty Grade 1 surface closer with adjustable spring sizes 1-6, so you keep the same sizing range. The LCN 1460T is a heavy duty closer in a powder coat finish, and the Sargent 281 Powerglide is a heavy duty Grade 1 closer with a cast iron body rather than aluminum. Cast iron and extra heavy-duty bodies are what most specifiers write for openings that see constant use.
9) Does an ADA-compliant surface closer exist as an alternative to the Accentra 2711?
Yes. The Calibre CA9901 is a Grade 1 tri-pack arm ADA surface mount closer sized 2-5, and the Calibre CA4001 is a Grade 1 hydraulic closer with adjustable spring tension for ADA. The Cal-Royal 500S is a Grade 1 barrier free closer with adjustable back-check, and the Cal-Royal N900PBF is a Grade 1 barrier free hydraulic surface closer. Where an accessible opening drives the opening force requirement, those are the closers written to it. The Accentra 2711 is adjustable across spring sizes 1-6, which is the range you tune within on any opening.
10) I want a delayed action closer instead of hold open - what should I order?
Delayed action and hold open solve different problems. Hold open, which is what the Accentra 2711's arm does, parks the door open until someone pushes it shut. Delayed action lets the door pause on its own before closing - the usual pick for a healthcare corridor or an opening where someone is moving a cart or a resident through. The Orca Hardware BHDC1958DA/PA is a delayed action closer with a regular arm and parallel bracket, tri-packed non-hold-open, for 1-3/4 inch doors. The Orca BHDC2011DA/PA is the same delayed action arrangement in the BHDC2011 Series.
11) My spec calls for spring sizes 1-6 - which closers other than the Accentra 2711 cover that full range?
The Accentra 2711 is adjustable across spring sizes 1-6, which lets one unit serve narrow interior doors and wider openings. Others covering the same 1-6 range are the BEST EHD9000 Series extra heavy-duty closer, the LCN 1450 medium duty closer with a cast aluminum body, the Norton Rixson 8501A Grade 1 tri-mount closer, the Arrow DCN325 Grade 1 tri-pack supplied less cover, and the Imperial USA TC4300 Grade 1 heavy duty ADA closer. Closers sized 1-4, like the Arrow DCN314 and the Dormakaba 7414, will not reach the top of that range.
12) Which closer should I use on an aluminum storefront door instead of the 2711?
Storefront doors have narrow top rails and stiles, and that is what drives the pick. The Norton Rixson 1600 Series aluminum storefront door closer is built for that opening, heavy duty Grade 1 with tri-style mounting. The Accentra 2711 is a tri-packed surface closer with a full plastic cover and a hold open arm, and its installation calls for verifying door thickness and stile width against the template before drilling. On a storefront, check that stile width first - it is the dimension that most often rules a closer out.
13) What fasteners come with the Accentra 2711, and do I need thrubolts for a hollow metal or wood door?
Sleeve nuts are furnished standard with every 2711. Thrubolts and grommet nuts are the optional fastener package, and that is the one to add on a hollow core wood door or any leaf where the sheet metal or skin will not hold a screw under repeated closing load. On a solid wood door or a properly reinforced hollow metal frame the standard sleeve nuts do the job.
14) I need a hold open closer that isn't Accentra. What else is comparable?
The closest match by function is the Orca Hardware BHDC1958HO/PA, a tri-packed hold open closer listed for 1-3/4 inch doors. The Stanley Security A45-501HL is a long hold open arm for top jamb mounting if hold open is what you are after specifically. If you want the same tri-mount, size 1-6 adjustable format but in Grade 1 rather than Grade 3, look at the Norton Rixson 8501A or the Dormakaba 8916-JT, though the 8916-JT uses a flat non-hold-open arm.
15) Do I have to specify handing when ordering the Accentra 2711 closer?
No handing to call out. The 2711 is non-handed, so the same unit works on a left or right hand door and you only choose finish. For a maintenance shop that means one part on the shelf covers every opening in the building regardless of swing.
16) Is the Falcon SC91A the same thing as the Accentra 2711?
They sit at the same duty point but are not the same closer. The Falcon SC91A is a light duty Grade 3 surface-mount closer with a cast aluminum body, which is the closest grade-for-grade peer to the Accentra 2711's ANSI/BHMA Grade 3 aluminum construction. The difference is the arm: the Accentra 2711 ships tri-packed with a hold open arm and adjustable spring sizes 1-6. If the opening needs the door to stay open, confirm the arm before substituting.
17) I need a hold open closer for a top jamb application - is the Stanley A45-501HL an alternative?
It is, with a difference in how it is packed. The Stanley Security A45-501HL is a top jamb closer with a long hold open arm standard, so hold open is built into the way it ships. The Accentra 2711 is tri-packed, meaning the same unit covers regular, parallel, or top jamb mounting with its hold open arm, which is useful when the mounting side is not settled until you are at the opening. If top jamb is the confirmed condition and will not change, either will hold the door.
18) What is the difference between the Accentra 2711 and the Arrow DCN325?
The cover. The Accentra 2711 comes with a full plastic cover. The Arrow DCN325 is a Grade 1 light duty surface closer supplied less cover, with a regular/parallel arm tri-pack and adjustable spring size 1-6. Both cover the same 1-6 spring range and both offer tri-pack mounting. If the closer is going somewhere visible from a lobby or a leased corridor, the covered unit is the one that reads as finished; a mechanical room or back-of-house door often does not need it.
19) Can I standardize a building on one closer family if some doors need slide track instead of a swinging arm?
Not with the Accentra 2711 alone - it is a tri-packed surface closer with a swinging hold open arm covering regular, parallel, and top jamb mounting. Where the opening calls for a track, the Corbin Russwin DC5230 is a Grade 1 surface closer with a slide track arm standard for pull side mounting on 1-3/4 inch doors, and the Dorma 8916-JT is a Grade 1 heavy duty jamb track closer for frame face mounting on the pull side, adjustable size 1-6. Track closers keep the arm tight to the frame, which is why they show up on openings where a projecting arm would be knocked or grabbed.
20) Is the Arrow DCN500DP drop plate a substitute for the Accentra 2711?
No. The Arrow DCN500DP is a parallel drop plate for the DCN500 - a mounting accessory that carries a closer body, not a closer. The Accentra 2711 is the closer itself, a surface mounted unit with a hold open arm and adjustable spring sizes 1-6, and it ships with sleeve nuts standard, with thrubolts and grommet nuts as optional fasteners. If a top rail is too narrow to take the closer directly, a drop plate is the fix, but it is ordered in addition to a closer and it has to match the closer body it is made for.
21) What is a medium duty alternative to the Accentra 2711 for interior office doors?
Between the Grade 3 Accentra 2711 and the heavy duty bodies there is a medium duty tier that suits interior office and tenant doors. The BEST HD7000 Series is a medium duty Grade 1 surface closer with adjustable spring power and backcheck control. The Falcon SC81A is a medium duty Grade 1 cast aluminum surface closer, and the Sargent 1131 is a medium duty Grade 1 adjustable surface closer for medium-traffic commercial applications. The Norton Rixson 1601P is a medium duty Grade 1 tri-mount closer with 180 degree swing, which keeps the tri-mount flexibility the Accentra 2711 gives you.
22) Is a Stanley wardrobe pivot an alternative to the Accentra 2711 closer?
No, they do different jobs. The Stanley Security 327 is a heavy wardrobe pivot for doors 1-3/8 inch or 1-3/4 inch up to 150 pounds, and the Stanley 341 is a wardrobe pivot for flush recessed or overlay doors 1-1/8 inch to 1-3/8 inch. A pivot carries the weight of the door and lets it swing; it does not close it. The Accentra 2711 is a surface mounted hydraulic closer with a rack and pinion mechanism and a hold open arm - it controls how the door closes and holds it open, and it does not hang the door.
23) What finishes does the Accentra 2711 door closer come in?
Three: 689 aluminum painted, 690 dark bronze painted, and BSP black suede powder coat. On an aluminum storefront, 689 disappears against the frame; 690 is the match for bronze anodized entrances; BSP is the textured black that holds up better on doors people touch, and it is the one to pick if the rest of the openings in the building are matte black.
24) Is the Accentra 2711 body aluminum or cast iron, and does it come with a cover?
Aluminum body with a full plastic cover included, running a rack and pinion mechanism. You are not buying a cover separately, which is worth checking against the alternatives: the Arrow DCN314 and DCN325 are supplied less cover. If you specifically want cast iron for an abused opening, the LCN 1261 is the cast iron unit in that class.
25) What Grade 2 closer options exist alongside the Grade 3 Accentra 2711?
The Cal-Royal 400 Series is a Grade 2 commercial hydraulic door closer, which sits between the Grade 3 classification the Accentra 2711 carries and the Grade 1 units. Grade under ANSI/BHMA reflects cycle testing, so where a facility standard names a minimum grade, that number is the thing to match first; the arm function and mounting style are chosen after. The Accentra 2711 brings tri-packed regular, parallel, or top jamb mounting with a hold open arm and adjustable spring sizes 1-6.
