Yale Commercial Yale 4602LN Grade 2 Privacy or Bedroom Non-Keyed Cylindrical Lever Lock Augusta Trim Design YAL-AU4602LN

Accentra 4602LN Grade 2 Privacy Cylindrical Lever Lock with Augusta Trim Design

(No reviews yet) Write a Review

Model: YAL-AU4602LN-626
From the 4600 Series Collection
$158.73
$56.19
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$158.73
$56.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra 4602LN Grade 2 Privacy Cylindrical Lever Lock with Augusta Trim Design

Professional Privacy Lock Solution for Commercial Applications

The Accentra 4602LN cylindrical lever lock delivers Grade 2 performance for privacy and bedroom applications in commercial settings. This non-keyed lock features adjustable door thickness from 1-3/8" to 1-3/4", 2-3/4" standard backset, and 1/2" stainless steel latchbolt throw. ANSI/BHMA Grade 2 certified and UL fire-rated up to 3 hours, this lock provides reliable security with the elegant Augusta lever design.

Professional Features & Benefits

  • ANSI/BHMA: A156.2, Series 4000 Grade 2
  • UL-cUL: UL-cUL fire-rated up to 3 hours
  • Windstorm: 4600LN Certified (refer to local codes)
  • Mechanism: Heavy-gauge steel, die-cast, zinc-plated, chromated
  • Backset: 2-3/4" standard; 2-3/8" to order
  • Latchbolt: 1/2" stainless steel throw standard
  • Guardbolt: Deadlocks latchbolt when door is closed; standard on all locking functions
  • Door Thickness: Adjustable from 1-3/8" to 1-3/4".
  • Fronts: Universal for both flat and beveled door edges
  • Cylinders: Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin not available. 6 and 7 pin SFIC available.
  • Reversibility: Non-handed
  • Strikes: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths to special order; all reversible.
  • Finishes: Available in 7 finishes
  • Warranty: 3-year mechanical

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness from 1-3/8" to 1-3/4", 2-3/4" backset, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Accentra Quality?

Accentra cylindrical lever locks deliver professional-grade reliability with heavy-gauge steel construction and ANSI/BHMA Grade 2 certification for demanding commercial applications. UL fire-rated up to 3 hours with 3-year mechanical warranty for added confidence and protection. Engineered for consistent performance where dependable privacy lock operation is essential.

Product Specs

Series:
4600 Series
Subcategory:
Cylindrical
Grade:
Grade 2
Keyed Function:
Non-Keyed
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Keyed:
No
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
Handle Type:
Lever
Lock Function:
Privacy/Bed/Bath
Product Attribute:
Cylindrical Locks
Product Model:
YAL-4602LN
Collection:
4600 Series
Product Function:
Privacy/Bed/Bath
Lever Design Name:
Augusta Lever
Product Category:
Mechanical Locks
Department:
Door Hardware

Accentra YAL-AU4602LN-626 – Frequently Asked Questions

1) Will the Accentra 4602LN privacy lever fit a 1-3/8 inch door, or is it 1-3/4 only?
Both. The 4602LN adjusts from 1-3/8 to 1-3/4 inches, so it goes on older interior doors and standard commercial doors without a separate part number. Standard backset is 2-3/4 inches, with 2-3/8 inch available to order, so it drops into either of the two usual bore layouts.
2) Does the Accentra 4602LN need a key, and how does it unlock in an emergency?
It's a non-keyed privacy/bed/bath function. You lock it from inside the room, and there is no cylinder or keyway on it at all. If you need a lock that a key opens from the corridor side, the 4602LN is the wrong function, pick an entrance or storeroom lock instead.
3) Can I put a privacy lever on a fire-rated door in a hospital or school corridor?
The 4602LN is UL-cUL fire rated up to 3 hours, so it's usable on rated openings within that limit. It's an ANSI/BHMA A156.2 Series 4000 Grade 2 lock, which is medium duty commercial rather than the Grade 1 you'd usually spec for a high traffic main corridor. For patient rooms, dorm baths, and staff washrooms it's the right weight of lock.
4) Do I have to order the Accentra 4602LN left hand or right hand?
No handing to specify. The 4602LN is non-handed and the front is universal for both flat and beveled door edges, so one part covers every door swing on the job. That's useful when you're buying a fleet of privacy locks for a building and don't want to count doors first.
5) Does the Accentra 4602LN work on doors thicker than 1-3/4 inches?
Not past 1-3/4 inches. The 4602LN tops out there. On thick doors, 2 inch stiles and up, look at the Hager 2510 or the Deltana Manchester, Morant and Linstead levers, all rated to 2 inches, or the Falcon K101 which goes to 2-1/4 inches. Note that those are passage or entry function, not privacy.
6) What is the closest equivalent to the Accentra 4602LN privacy lever if I need a Grade 2 privacy cylindrical lever from another brand?
The Hager 2540 with the Withnell lever is the nearest match on the core specs: it is a Grade 2 cylindrical privacy lock covering doors from 1-3/8 inch to 2 inch, against the 4602LN's Grade 2 privacy/bed/bath rating and adjustable 1-3/8 inch to 1-3/4 inch door thickness. Both are non-keyed privacy functions with a lever trim, so the swap is a like-for-like on a bed or bath opening. The lever styling differs - Augusta on the 4602LN, Withnell on the Hager - so if the other doors on the floor are already carrying one design, match the trim rather than mixing.
7) I need a privacy lock for doors thicker than 1-3/4 inch - what should I use instead of the 4602LN?
The 4602LN adjusts from 1-3/8 inch to 1-3/4 inch, so a thicker leaf is outside its range. The Arrow MK02-TA privacy cylindrical lock covers 1-3/4 inch to 2 inch doors and is fire rated, which puts it on the heavier leaves. It carries a Tudor knob rather than a lever, so confirm that lever trim is not required for the opening before you specify it. The Hager 2540 privacy lever runs 1-3/8 inch to 2 inch and keeps the lever handle if the trim style has to stay.
8) What is the difference between the Accentra 4602LN and a passage lever like the Falcon B101 or Hager 2510?
Function, not grade. The 4602LN is a non-keyed privacy/bed/bath lock, so it has an inside locking control for a bedroom, bathroom or lactation room. The Falcon B101 is a Grade 2 medium duty cylindrical passage lever and the Hager 2510 is a Grade 2 passage lever for 1-3/8 inch to 2 inch doors - both latch the door but never lock, which suits corridors, halls and closets. Ordering a passage set where privacy was intended is the most common mis-spec on this type of opening.
9) For a patient room or holding room, is the 4602LN the right lock or do I need an asylum function?
The 4602LN is a privacy/bed/bath function - the occupant controls the lock from inside, which is what a resident bedroom or a staff washroom wants. An asylum or institution function is the opposite: the Dexter C1000 asylum (F87) is a Grade 1 cylindrical lock for 1-3/8 inch to 2 inch doors, and the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum/institution/utility lock with a Schlage C keyway conventional cylinder, both keyed on both sides so the occupant cannot control the lock. Choose by whether the room's occupant is meant to secure the door themselves.
10) What is a guardbolt on a privacy lock and does the 4602LN have one?
Yes, and it's the small plunger beside the latch. When the door closes, the guardbolt deadlocks the latchbolt so it can't be shimmed or carded back from the corridor. On the 4602LN it's standard on the locking functions, which matters on a bathroom or bedroom door where the only thing between the room and the hallway is a half inch of latch.
11) Is a Grade 2 privacy lever heavy enough for a busy public restroom, or should I go Grade 1?
Grade 2 is medium duty. For a single tenant restroom, patient room, or dorm bath, the 4602LN holds up fine. For a high traffic public restroom door that cycles all day, a Grade 1 privacy lock is the safer spec: the Arrow MK02-TA is a Grade 1 privacy cylindrical lock, though it's a Tudor knob rather than a lever, so it won't give you the lever pull that levers do for accessibility. Falcon's K Series K101 is Grade 1 heavy duty in a lever, but it's passage function, no locking.
12) I need matching levers on doors that don't lock. Can I use the 4602LN?
No, the 4602LN only comes as a privacy function, so it always has the inside locking button. For hall and closet doors that just latch, order a passage lockset instead, and for a door that needs a lever but no latch at all, a dummy trim. In Grade 2 the Falcon B101 passage lever and the BEST 7KC single dummy trim cover those two cases; in Grade 1 it's the Falcon T101 or Corbin Russwin CL3110 for passage and the BEST 9K 1DT for dummy.
13) The opening needs a keyed lever instead of privacy - what takes the place of the 4602LN?
The 4602LN is non-keyed, so for a keyed opening in the same Grade 2 cylindrical lever family the Hager 2525 is a Grade 2 commercial cylindrical entry lever for 1-3/8 inch to 2 inch doors, and the Hager 2580 is a Grade 2 storeroom lever over the same thickness range. If the door is a storeroom with a deadlocking latchbolt requirement, the Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt covering 1-3/8 inch to 1-3/4 inch doors, which is the same thickness window the 4602LN works in.
14) If the specification calls for a Grade 1 lever instead of Grade 2, what replaces the 4602LN?
The 4602LN is certified ANSI/BHMA A156.2 Series 4000 Grade 2. For a Grade 1 cylindrical lever the Falcon K101 is a Grade 1 heavy duty non-handed passage lock, fire rated, covering 1-3/8 inch to 2-1/4 inch doors, and the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage lever, fire rated, for 1-3/4 inch to 2 inch doors. Both are passage rather than privacy, so on a bed or bath opening confirm the inside locking control is still met by the function you order.
15) Can I use a dummy lever such as the BEST 7KC 1DT in place of the 4602LN on an inactive leaf?
Only where nothing has to latch. The 4602LN is a privacy/bed/bath cylindrical lock with a 1/2 inch stainless steel latchbolt and a guardbolt that deadlocks the latch when the door closes. The BEST 7KC 1DT is a Grade 2 single dummy trim cylindrical lever with a dummy function - it is fixed trim, with no latch and no locking. The BEST 9K 1DT is the Grade 1 heavy duty equivalent in the same dummy role. Use dummy trim on an inactive leaf or a ball-catch door, and the 4602LN wherever the door must actually latch and lock.
16) We want keyless code entry on the door rather than a privacy lever - what are the alternatives to the 4602LN?
The 4602LN is a mechanical non-keyed privacy lock with no code entry. For pushbutton access on a lever, the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1-3/16 inch to 2 inch, and the Lockey 1150 is a heavy duty mechanical keypad lever set for 1-1/8 inch to 2 inch doors. The Delaney LP250 is a Grade 2 electronic keypad leverlock if you want an electronic rather than mechanical keypad. All three control access by code, which is a different job from the inside-only privacy control on the 4602LN.
17) Is the Baldwin Estate 5103 privacy lever an alternative to the Accentra 4602LN?
Both are privacy/bed/bath levers, so they answer the same opening in function. The Baldwin Estate 5103 privacy lever mounts on a 5048 rose and is styled as a residential estate product, while the 4602LN is a commercial ANSI/BHMA Grade 2 cylindrical lock certified to A156.2 Series 4000 and UL fire rated up to 3 hours. For a fire-rated corridor door or a facility standardizing on graded hardware, the 4602LN is the one that carries those certifications; for an owner's-unit door chosen on appearance, the Baldwin is a legitimate pick.
18) Is a Grade 3 lever like the Cal-Royal AUS00 or Callan Artino interchangeable with the 4602LN?
Not on grade or function. The 4602LN is a Grade 2 privacy lock; the Cal-Royal AUS00 is a Grade 3 entrance/office lever for 1-3/8 inch to 1-3/4 inch doors and the Callan Artino is a Grade 3 entrance leverset. The AUS00 shares the 4602LN's door thickness window so it will sit in the same prep, but entrance/office is a keyed outside function, not an inside privacy control, and Grade 3 will not meet a Grade 2 callout. Match on function first, then grade.
19) Our classroom doors need a keyed classroom function - what pairs with the 4602LN on the bed and bath doors?
Keep the 4602LN, a Grade 2 non-keyed privacy lever, on the washroom and staff doors, and pair it with a classroom function on the teaching spaces. The Cal-Royal AG03 is a classroom lever, Grade 2, with a 6-pin Schlage C keyway and 2-3/8 inch backset, which is one of the backsets the 4602LN can be ordered in. For a Grade 1 classroom the Dexter C1000 classroom is a keyed clutching lever for 1-3/8 inch to 1-3/4 inch doors, with a classroom security version in the same series that adds an inside keyed control.
20) What finishes does the Accentra 4602LN Augusta lever come in?
Six: 605 bright brass, 606 satin brass, 613E dark oxidized satin bronze equivalent, 625 bright chrome, 626 satin chrome, and BSP black suede powder coat. The lever itself is the Augusta design, so if you're matching existing openings in a building, the trim shape plus the finish number is what you carry over to the rest of the doors.
21) What is the Accentra 4602LN lock body made of?
The mechanism is heavy-gauge steel, die-cast, zinc-plated and chromated, with a stainless steel latchbolt. That plating package is what keeps the internals from corroding in a humid room, which is the usual duty for a bed and bath lock.
