Yale Commercial Yale 5402LN Pacific Beach Heavy Duty Grade 1 Privacy Door Cylindrical Lever Lock YAL-PB-5402LN

Accentra 5402LN Pacific Beach Heavy Duty Grade 1 Privacy Cylindrical Lever Lock

(No reviews yet) Write a Review

Model: PB-5402LN-626
From the 5400 Series Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$851.57
$485.93
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Accentra 5402LN Pacific Beach Heavy Duty Grade 1 Privacy Cylindrical Lever Lock

Commercial-Grade Privacy Lock Solution

The Accentra 5402LN Pacific Beach lever lock delivers Grade 1 performance for commercial privacy applications. This heavy-duty cylindrical lockset features adjustable door thickness from 1-3/4" to 2-1/4", 2-3/4" standard backset, and 1/2" stainless steel latchbolt throw. ANSI/BHMA A156.2 Series 4000 Grade 1 certified with UL/cUL fire rating up to 3 hours for demanding commercial environments.

Professional Features & Benefits

  • ANSI/BHMA: A156.2, Series 4000 Grade 1
  • UL/cUL: UL/cUL fire-rated up to 3 hours
  • Windstorm: Certified (refer to local codes)
  • Mechanism: Heavy-gauge steel, zinc-plated, dichromated
  • Backset: 2-3/4" standard; 3-3/4" or 5" extension link available to order
  • Latchbolt: 1/2" stainless steel throw standard; 3/4" throw available to order
  • Guardbolt: Deadlocks latchbolt when door is closed; standard on all locking functions
  • Door Thickness: Adjustable from 1-3/4" to 2-1/4"
  • Fronts: 2-1/4" x 1-1/8" beveled standard; flat fronts available to order
  • Lead Shielding: Available to order
  • Cylinders: Brass, 6-pin, keyed-random cylinder with two keys furnished standard, 7-pin available to order. For other cylinder and keying options, see page 31.
  • Reversibility: Non-handed
  • Strikes: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths available to order; all reversible
  • Finishes: Available in 13 finishes, including PVD lifetime finish options for 613. PVD is standard for 605 and 606
  • Warranty: 7-year mechanical

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness from 1-3/4" to 2-1/4", 2-3/4" standard backset, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Accentra Quality?

Accentra cylindrical lever locks deliver professional-grade reliability with heavy-gauge steel construction and Grade 1 certification for demanding commercial applications. UL/cUL fire-rated up to 3 hours with 7-year mechanical warranty for added confidence. Engineered for demanding commercial applications where dependable performance is essential.

Product Specs

Series:
5400 Series
Subcategory:
Lever Locksets
Keyed Function:
Non-Keyed
Grade:
Grade 1
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Leversets
Keyed:
No
Commercial/Residential:
Commercial
Lock Type:
Cylindrical
Handle Type:
Lever
Lock Function:
Privacy/Bed/Bath
Product Attribute:
Cylindrical Locks
Product Model:
YAL-5402LN
Collection:
5400 Series
Product Function:
Privacy/Bed/Bath
Lever Design Name:
Pacific Beach Lever
Product Category:
Mechanical Locks
Department:
Door Hardware

Accentra PB-5402LN-626 – Frequently Asked Questions

1) Will the Accentra 5402LN privacy lever fit a 1-3/8 inch door?
No. The 5402LN Pacific Beach privacy lockset adjusts from 1-3/4 inch up to 2-1/4 inches, so a 1-3/8 inch interior door is below its range. For thinner doors, the Falcon K101 covers 1-3/8 to 2-1/4 inches, and the Dexter C1000 passage covers 1-3/8 to 1-3/4 inches. Where the 5402LN earns its place is on thick doors: at 2-1/4 inches it handles gasketed or lead-lined leaves most Grade 2 locks top out well below.
2) Does the 5402LN need to be ordered left or right hand?
No handing to specify. The 5402LN is non-handed and the strike is reversible, so one part number works on either swing. That is what makes it easy to stock as a fleet item across a building instead of carrying two versions.
3) Will the Accentra 5402LN latch into the strike already in my frame?
Standard build is a 1/2 inch stainless steel latchbolt throw with a 1-1/4 inch curved lip strike cut for a 1-3/4 inch door. If your existing frame has a deeper pocket or your door sits proud of the jamb, a 3/4 inch throw is available to order, and other strike lip lengths can be specified. Backset is 2-3/4 inches standard, with 3-3/4 inch or 5 inch extension links available if your cross-bore is set back further.
4) Can I use this privacy lock on a fire rated door?
Yes. The 5402LN is UL/cUL fire rated up to 3 hours, and it carries ANSI/BHMA A156.2 Series 4000 Grade 1. It is also windstorm certified, subject to your local code. For a fire opening, remember privacy function means no outside key override in the lock itself.
5) Is the 5402LN keyed, and how does the privacy function actually operate?
Non-keyed. Privacy/bed/bath function means an inside turn button locks the lever and there is no cylinder to key. If you need a keyed opening in the same Pacific Beach trim, you want a different function in the 5400 Series, not this one. Note the 5400LN cylinder options described for keyed functions (brass 6-pin, 7-pin available) do not apply to the 5402LN.
6) What is the closest Grade 1 privacy lever alternative to the Accentra 5402LN Pacific Beach?
The Accentra 5402LN is a Grade 1 non-keyed privacy/bed/bath cylindrical lever lock. For a cross-brand Grade 1 privacy alternative, the Arrow MK02-TA is listed as Grade 1 with a privacy/bed/bath function and a fire rating, but it uses a Tudor knob rather than a lever, so it will not match a lever-trim opening or ADA lever requirements. If the lever shape matters, staying on the 5402LN Pacific Beach lever is the way to keep both the Grade 1 rating and the lever trim.
7) The door does not need to lock at all. What replaces the 5402LN for a plain latching door?
The 5402LN is a privacy/bed/bath function, so it has an inside locking device. If the opening only needs a latch with no locking, the Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, a fire rating, and a 1-3/8 to 2-1/4 inch door thickness range, which overlaps the 5402LN range. The Corbin Russwin CL3110 is another Grade 1 fire-rated passage lever, rated for 1-3/4 to 2 inch doors.
8) Is the Hager 2540 a direct substitute for the Accentra 5402LN privacy lever?
Not a like-for-like one. The Hager 2540 with the Withnell lever is Grade 2 and covers 1-3/8 to 2 inch doors, while the Accentra 5402LN Pacific Beach is Grade 1 and adjusts from 1-3/4 to 2-1/4 inch. On a 2-1/4 inch door or where the spec calls out ANSI/BHMA A156.2 Series 4000 Grade 1, the 5402LN is the one that meets it.
9) What finishes does the Pacific Beach 5402LN lever come in?
Nine orderable finishes: 605 bright brass, 606 satin brass, 612 satin bronze, 613E dark oxidized satin bronze equivalent, 619 satin nickel, 625 bright chrome, 626 satin chrome, plus BSP black suede and WSP white suede powder coat. PVD is standard on 605 and 606, which matters if you are matching brass across a lobby and do not want the tarnish. 626 satin chrome is the usual choice for matching existing commercial openings.
10) Why pay for a Grade 1 privacy lever on a restroom door instead of a Grade 2?
Traffic and abuse. The 5402LN uses a heavy-gauge steel, zinc-plated and dichromated mechanism and is certified to Grade 1, which is the cycle and strength tier for high-use commercial openings such as public restrooms and healthcare corridors. If the door is low traffic, Grade 2 privacy sets like the Arrow MK02-TA or the Hager 2540 cover the same function at a lighter duty tier; the Hager also fits down to 1-3/8 inch doors.
11) I need privacy, passage, and dummy levers to match on a suite of doors. Can I get that in this trim?
The 5402LN is the privacy function in the Accentra 5400 Series with the Pacific Beach lever, so matching functions come from the same series and lever design rather than from this part number. If you are matching across brands instead, Grade 1 non-keyed companions exist elsewhere: Corbin Russwin CL3110 for passage/closet, and the BEST 9K Series 1DT single dummy trim.
12) Can I get the 5402LN with a flat front and lead shielding for an X-ray room?
Yes, both are order options. Standard front is a 2-1/4 x 1-1/8 inch beveled front; flat fronts are available to order, and lead shielding is also available to order. Pair that with the 2-1/4 inch maximum door thickness and the set works on the lead-lined leaves used in imaging suites.
13) I need a privacy lever but Grade 1 is more than the opening calls for. What is a lighter option?
For a residential-duty bath or bedroom door, the Kwikset 300BRNL Breton privacy lever set is Grade 3 with a privacy/bed/bath function and a 1-3/8 to 1-3/4 inch door thickness range. The Accentra 5402LN Pacific Beach is the Grade 1 commercial option and covers 1-3/4 to 2-1/4 inch doors, so on a thicker commercial door the Kwikset will not reach.
14) Can a dummy lever be used in place of the Accentra 5402LN on an inactive leaf?
No. The 5402LN is a privacy cylindrical lock with a working latch and an inside locking device. On an inactive or pull-only leaf you want dummy trim such as the BEST 9K Series 1DT single dummy, which is Grade 1 heavy duty non-keyed dummy function, or the Grade 2 BEST 7KC Series 1DT. Dummy trim has no latch, so it cannot hold a bath or bedroom door closed.
15) The door needs a key, not just a privacy turn. What should I order instead of the 5402LN?
The 5402LN Pacific Beach is a non-keyed privacy function, so it will not accept an outside key. For a keyed opening, the Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt for 1-3/8 to 1-3/4 inch doors, and the Dexter C1000 classroom is a Grade 1 keyed clutching lever for 1-3/8 to 1-3/4 inch doors. Confirm your door thickness against those ranges before ordering.
16) For a patient room or behavioral health door, is the 5402LN the right function?
No. The Accentra 5402LN is a privacy/bed/bath function with an inside locking device that an occupant controls. Asylum or institution function locks operate by key on both sides with no occupant thumbturn, which is what those rooms usually specify. The Dexter C1000 asylum (F87) is Grade 1 for 1-3/8 to 2 inch doors; the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum lock with a ball knob and Schlage C keyway.
17) We want decorative levers on interior doors. How does a Baldwin Estate privacy lever compare to the Accentra 5402LN?
The Baldwin Estate 5103 privacy lever with the 5048 rose is a privacy/bed/bath function built as residential decorative trim. The Accentra 5402LN Pacific Beach is a commercial Grade 1 cylindrical privacy lever carrying ANSI/BHMA A156.2 Series 4000 Grade 1 and UL/cUL fire rating up to 3 hours, and it comes in 13 finishes including satin chrome and powder coat options. Choose the Baldwin where appearance drives the interior door and the Accentra where a fire-rated or graded opening is specified.
18) What is the guardbolt on the 5402LN for?
It deadlocks the latchbolt once the door closes, so the latch cannot be shimmed or carded back. It is standard on all locking functions in the line, including this privacy set, which is the practical difference between a privacy lever and a passage lever that just holds the door shut.
19) Is there a keyless pushbutton lever I could use instead of the Accentra 5402LN privacy lock?
If you want coded entry rather than an occupant privacy turn, the Lockey 2835 mechanical pushbutton keyless lever lock is a passage function for 1-3/16 to 2 inch doors, and the Lockey 1150 keypad lever set covers 1-1/8 to 2 inch doors. Both are passage-function trim rather than privacy, so they do not give the inside occupant a lock; the Accentra 5402LN Pacific Beach does, across 1-3/4 to 2-1/4 inch doors.
20) If I standardize on the Accentra 5400 Series for privacy doors, what Grade 1 passage lever pairs with it on the non-locking openings?
The Accentra 5402LN Pacific Beach covers the privacy/bed/bath openings at Grade 1. For the corridor and closet doors in the same facility, Grade 1 passage levers include the Falcon K101, heavy duty, fire rated, 1-3/8 to 2-1/4 inch doors, the Falcon T101 heavy duty passage, and the Design Hardware X75 flat lever passage for 1-3/4 inch doors. Matching finish across brands should be confirmed by finish code.
