Yale Residential Yale YH Collection Dartmouth Passage Door Knobset YR10DM

Yale YH Collection Dartmouth Passage Door Knobset

(No reviews yet) Write a Review

Model: 10DM-SP-15-01D64-02000
From the Dartmouthh Collection
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$57.10
$52.01
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

YALE YH COLLECTION YR10DM DARTMOUTH PASSAGE DOOR KNOB SET WITH ROUND ROSE OVERVIEW

Superior light commercial quality with push button locking, removable knobs for simple re-keying, and a lifetime limited finish and mechanical warranty.

The YH Collection continues a legacy of distinctive design, high manufacturing standards and demanding performance started by Linus Yale in the mid -19th century. The YH Collection leverages years of engineering refinement with artful execution to offer a series of ANSI Grade 2 superior light commercial quality locks that will beautifully serve any home for generations. They offer superior functionality such as push-button locking and removable knobs for simple re-keying.

PASSAGE FUNCTIONS

  • Ideal for closets, hallways or rooms where no locking mechanism is needed
  • Box Contents: 2x Knobss, 2x rose, interior chasis, strike plate, 4x screws, latch, exterior chasis

ROSETTE DIMENSIONS

  • Oval 2-9/16" W x 4-7/32" H
    Center Hole: Knob 15/16" – Lever 1-1/32"
  • Traditional 2-9/16" W x 4-7/32" H
    Center Hole: Knob 15/16" – Lever 1-1/32"

FEATURES & BENEFITS

  • Exceeds criteria for ANSI/BHMA A156.2 Grade 2 certification
  • Constructed from quality materials with a focus on durability
  • Easy Install Mounting System — Square Spindle Simplifies Installation - Knobs, Levers
  • Pre-Installed Mounting Screws
  • Concealed Mounting Screws — Clean Upgraded Look
  • Provide easy re-keying
  • Reduces wear and provides smooth operation
  • Limited Lifetime Mechanical and Finish Warranty

DOWNLOADS

Manufacturer Resources

Product Specs

Series:
YH Collection
Collection:
Dartmouthh
Features:
Concealed Screws
Edge Bore:
1"
Warranty:
Limited Lifetime Mechanical
Keyed Function:
Non-Keyed
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Product Type:
Knobsets
Subcategory:
Residential Door Knobs
Cross Bore:
2-1/8"
Keyed:
No
Commercial/Residential:
Residential
Handle Type:
Knob
Lock Function:
Passage
Grade:
Grade 2
Product Attribute:
Cylindrical Locks
Product Function:
Passage/Hall/Closet
Door Thickness Range:
1-3/8" to 1-3/4"
Product Design:
Round
Mounting Method:
Surface
Product Category:
Mechanical Locks
Product Substrate:
Metal
Department:
Door Hardware

Yale Residential 10DM-SP-15-01D64-02000 – Frequently Asked Questions

1) Will the Yale YH Collection Dartmouth passage knob fit a 1-3/8 inch interior door?
Yes. The Dartmouth passage knobset covers 1-3/8 inch to 1-3/4 inch doors, so it handles both the thinner older interior doors and standard 1-3/4 inch slabs without an extension kit.
2) Does the Yale Dartmouth knobset drop into an existing 2-1/8 inch bore, or do I have to redrill the door?
It goes into the standard bored prep: 2-1/8 inch cross bore through the face and 1 inch edge bore for the latch. If the door already has a cylindrical knob or lever in it, the holes are almost certainly already right and it is a straight swap.
3) Is a Grade 2 knob enough for an apartment building or light commercial corridor?
Grade 2 is the middle ANSI/BHMA tier, and the Dartmouth is built to it. That suits multifamily interiors, offices, and light commercial traffic. For a heavy-traffic opening you want Grade 1: the Corbin Russwin CK4310 Grade 1 passage knob or the Falcon X101 heavy duty Grade 1 passage knobset are the step up in the same passage function.
4) Can I use the Yale Dartmouth passage knobset on a fire rated door?
Use a device with a stated fire rating for a rated opening. Among passage knobs, the Falcon W101 Grade 2 and the Falcon X101 Grade 1 both carry a fire rating on their specs, and the X101 also covers thicker doors up to 2-1/4 inches.
5) The Dartmouth passage knob will not lock - what do I order for a bedroom or bathroom door instead?
Passage function has no locking mechanism at all, so for a bedroom or bath you want a privacy knob with a push button. The Dexter C2000 Series privacy cylindrical ball knob lock is Grade 2, non-keyed, and fits doors 1-3/8 inch to 1-3/4 inch, matching the Dartmouth on grade and door thickness. Cal-Royal BER20 is a Grade 3 privacy knob lock with brass trim over the same 1-3/8 inch to 1-3/4 inch door range, and Pamex FTF Baron is a Grade 3 privacy knob lockset at that same range.
6) Is a dummy knob the same as a passage knob?
No, and this is the most common mis-order on a closet or pantry door. A passage knob like the Yale Dartmouth YR10DM has a working latch that retracts when you turn the knob. A dummy knob is fixed trim with no latch - the Schlage A170 single dummy trim, the BEST 6K single dummy trim, the Bravura Biloxi dummy knobset and the Cal-Royal BA40 dummy knob are all dummy function. Use dummy only where the door is held shut by a ball catch or roller catch, or on the inactive leaf of a pair.
7) What is the closest equivalent to the Yale YR10DM Dartmouth passage knobset from another brand?
The Dexter C2000 Series passage cylindrical ball knob lock is the nearest match on the specs that matter for a passage opening. Both are Grade 2 non-keyed passage/hall/closet knobsets fitting doors 1-3/8 inch to 1-3/4 inch thick, so the same door prep and the same function apply. The Dartmouth uses a round rose knob design; the Dexter C2000 uses a ball knob. Corbin Russwin CK4410 is a second Grade 2 passage/closet knob at the same 1-3/8 inch to 1-3/4 inch door thickness range, with a Global knob design.
8) My door is 2 inches thick - which knobs cover that range?
The Yale Dartmouth YR10DM covers 1-3/8 inch to 1-3/4 inch doors. For a 2 inch door, the Corbin Russwin CK4310 Grade 1 passage/closet knob covers 1-3/8 inch to 2 inch, and the Falcon X101 Grade 1 passage knobset covers 1-3/8 inch to 2-1/4 inch. On the decorative side, Deltana 6171 Round Knob entry and Deltana 3381 Egg Knob entry both cover 1-3/8 inch to 2 inch, though those are entry rather than passage function.
9) What passage knob holds up better than a Grade 2 on a high-traffic corridor or stairwell door?
Step up to a Grade 1 passage knobset. The Corbin Russwin CK4310 is a Grade 1 passage/closet cylindrical lock with a Global knob, and it takes doors 1-3/8 inch to 2 inch thick. The Falcon X101 is a heavy duty Grade 1 cylindrical passage knobset that is fire rated and accepts an interchangeable core, with a 1-3/8 inch to 2-1/4 inch door thickness range. The Yale Dartmouth YR10DM is Grade 2 and covers 1-3/8 inch to 1-3/4 inch doors, so on a thicker corridor door the Grade 1 options are also the ones with the range to fit.
10) What do I use on an exterior or office door that needs a key, instead of the Dartmouth passage knob?
The Dartmouth YR10DM is non-keyed, so for a keyed opening move to an entrance function knob. The Dexter C2000 Series entry/office cylindrical ball knob lock is Grade 2 and keyed, fitting doors 1-3/8 inch to 1-3/4 inch. Corbin Russwin CK4851 is an entrance/office cylindrical lock with a Global knob and a conventional cylinder, covering 1-3/8 inch to 2 inch doors. On the lighter end, Cal-Royal BER00 is a Grade 3 entrance/office knob lock with a Kwikset keyway, which matters if the building is already keyed to Kwikset.
11) What comes in the box with the Yale Dartmouth passage knobset, and do I need to buy a latch or strike separately?
Everything for one opening is included: two knobs, two roses, interior and exterior chassis, the latch, a strike plate, and four screws. No separate latch or strike purchase. The mounting screws come pre-installed and sit concealed behind the rose, so no screw heads show on the finished trim.
12) What finishes does the Yale YH Dartmouth knob come in for matching other doors in a building?
Six finishes across the range: 619 Satin Nickel, 605 Polished Brass, 10BP Oil Rubbed Bronze Permanent, 613E Dark Oxidized Satin Bronze, BSP Black Suede Powder Coat, and GM Gun Metal. If you are standardizing a floor or a whole property, order the passage, privacy, and entry functions in the same finish code so the openings read as one set.
13) Do I need to worry about handing when ordering a Yale Dartmouth passage knob?
No. It is a non-handed cylindrical bored lockset with knobs on both faces and no keyed cylinder, so the same part works on a left or right hand door. The only thing to get right at install is that the latch bevel faces the stop.
14) I want a decorative passage knob rather than a plain round one - what are the options?
The Yale Dartmouth YR10DM is a round design knob with a round rose. For a more traditional look, the Baldwin Estate 5011 Colonial passage knob comes with a 5058 rose, and the Baldwin Estate 5000 Baltimore 2 inch knob with 5048 rose is a preconfigured passage lock with a 2-3/8 inch backset and full lip strike. Omnia 434/PA is a traditional egg-shaped knob latchset in solid brass with a 3 inch projection. Bravura offers passage knobsets in the Albany and Lynchburg round trim styles and the Dallas rectangle trim style, all Grade 2.
15) What passage knob should I standardize on across a facility that also needs storeroom and classroom doors?
If you want one manufacturer across the opening types, Sargent covers the range: the 6G04 is a Grade 2 storeroom/closet knob lock with a single cylinder in standard duty, and the 8XG04 is the Grade 1 heavy duty storeroom/closet single cylinder knob with a 2-3/4 inch backset. Dexter also spans it within one series - the C2000 Series includes a Grade 2 classroom ball knob lock, a Grade 2 entry/office, a Grade 2 privacy and a Grade 2 passage, all at 1-3/8 inch to 1-3/4 inch door thickness, which is the same door range the Yale Dartmouth YR10DM fits.
16) Will a keyless combination knob work where I would otherwise put a passage knob?
The Lockey 3830 is a mechanical keyless combination knob lock with an auto-locking passage function, covering doors 1 3/16 inch to 2 inch. It differs from the Yale Dartmouth YR10DM in that the Dartmouth is a straight non-keyed passage knob with no locking mechanism, while the 3830 auto-locks behind the user and requires a combination to re-enter. Use the Lockey where you need controlled access without issuing keys; use the Dartmouth on closets and hallways where the door only needs to latch.
17) Is the Yale Dartmouth knob solid metal or plastic inside?
Metal substrate, with a round rose and round knob profile. The chassis uses a square spindle drive, which is the part that carries the turning load on a knob and the reason the assembly stays tight through repeated use.
