$0.34
10-32 x 1/2 in. Round Head Slotted Machine Screws - Brass - 100qty
Features
- 10-32 Diameter, 1/2" Length
- Brass Material
- Round head with slotted Drive
Additional Notes
- Other sizes and quantities available by request | Tensile strength values for stainless screws are offered as approximations only; there is no single standard for the performance requirements of stainless machine screws.
Manufacturer Resources
Product Specs
- Minimum Purchase:
- 100 units
- Arra Compliant:
- N
- Buy American Compliant:
- No
- Dimensional Standard:
- ASME B18.6.3
- Division:
- Electrical H1
- Drive Type:
- Slotted
- Fastener Head Height:
- 0.123 - 0.137 in.
- Fastener Head Type:
- Round
- Fastener Head Width:
- 0.334 - 0.359 in.
- Fastener Length:
- 2-Jan
- Field Application:
- Electrical, Plumbing, Heating and Air Conditioning Industries
- Language Code:
- EN
- Neurspe:
- https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Round_Head_Machine_Screw.pdf
- Order Minimum Imperial:
- 100
- Order Minimum Uom Imperial:
- JR
- Pack Type:
- Jar
- Product Group:
- Fasteners
- Product Height:
- 2.15 in
- Product Length:
- 3 in
- Product Weight:
- 0.57 lbs
- Product Width:
- 3 in
- Recess Penetration Gaging Depth:
- 0.082 - 0.108
- Slot Depth:
- 0.065 - 0.087
- Slot Width:
- 0.05 - 0.06
- Sub Division:
- Electrical-E H2
- Thread Per Inch:
- 32
- Thread Standard:
- ANSI/ASME B1.1
- Department:
- Electrical
- Product Subgroup:
- Screws
- Product Type:
- Machine Screw
- Type2:
- Machine Screw
- Series:
- JRMB
- Product Details:
- Machine Screw
- Product Material:
- Brass
Metallics JRMB95 – Frequently Asked Questions
1) Will a 10-32 brass machine screw thread into a standard electrical box or device ground screw hole?
The Metallics JRMB95 is a 10-32 screw cut to ANSI/ASME B1.1 thread standard with 32 threads per inch, which is the thread used for device mounting and grounding holes in standard outlet boxes and switch plates. At 1/2 inch long it gives enough engagement for a tapped box hole or a ground lug without bottoming out in shallow prep.
2) Do Metallics JRMB brass machine screws meet Buy American or ARRA requirements for a public project?
No. The JRMB95 is not Buy American compliant and is not ARRA compliant, with country of origin listed as multiple. If your job carries a domestic sourcing clause, this screw will not satisfy it and you need a domestically produced fastener instead.
3) Why choose brass machine screws instead of steel or stainless for electrical work?
Brass is the material here, and it is the usual pick where you want conductivity and corrosion resistance together, such as grounding connections and bonding screws in damp locations. Steel is stronger for structural clamping; stainless resists corrosion but is a poorer conductor. For electrical, plumbing, heating and air conditioning work, which is what Metallics lists as the field application for the JRMB series, brass is the trade standard for ground and bonding hardware.
4) How are these brass machine screws packaged and is there a minimum order?
They come in a jar of 100, and 100 is the order minimum for the JRMB95. The jar weighs 0.57 lbs and measures 3 x 2.15 x 3 inches, which is why it stores well on a van shelf or in a bin system rather than loose in a bag.
