Metallics JTEK19P 10 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

Metallics JTEK19P 10 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK19P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.37
$0.37
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1-1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

  • Features

    • Steel Zinc Material
    • #2 Drill Point
    • Pan Head with Phillips Drive
    • 10 Diameter, 1-1/2" Length

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
1/1/02
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
0.98 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Torsional Strength:
61 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK19P – Frequently Asked Questions

1) What thickness of steel can the Metallics JTEK19P self-drilling screw drill through?
The JTEK19P is rated for panel thickness of 0.035 to 0.110 inch. That covers sheet metal, light-gauge stud, strut and enclosure walls in that range. Below 0.035 inch the #2 drill point will punch through before the threads engage well; above 0.110 inch you need a heavier drill point size.
2) Does the JTEK19P need a pilot hole, or does it drill its own?
No pilot hole. It is a Type BSD self-drilling and tapping screw with a #2 drill point, so it cuts its own hole and forms its own thread in one pass through metal within the 0.035 to 0.110 inch panel range. Thread pitch is 16 threads per inch.
3) Do these Metallics self-drilling screws qualify for a Buy American or ARRA job?
No. The JTEK19P is not Buy American compliant and is not ARRA compliant; country of origin is listed as multiple. If your contract carries a domestic-sourcing clause, this is not the fastener to submit.
4) What driver bit do I need for the Metallics JTEK19P screws?
A #2 Phillips bit. The recess is a Phillips drive with a 0.192 inch recess diameter and a gaging depth of 0.089 to 0.113 inch, so a worn or oversized bit will cam out under drilling torque. Keep a fresh #2 on the gun.
5) How much torque will a #10 self-drilling pan head screw take before it snaps?
61 lb-in minimum torsional strength on the JTEK19P, with a case hardness of Rockwell C32-40. That is the figure to watch if you are driving with an impact or a high-torque screwgun into the upper end of the gauge range: set the clutch rather than relying on the driver to stall.
6) Are these Metallics screws made to a recognized standard?
Two apply to the JTEK19P: head and recess geometry follow ASME B18.6.3-2010, and the thread and point conform to SAE J78 - 2013. Worth noting for anyone matching a submittal, SAE J78 does not cover #7 diameter drill screws, so #10 like this one is within scope of the standard.
7) Can I use zinc plated self-drilling screws outdoors or in a wet area?
These are steel with a zinc finish, which is a dry-interior plating. For rooftop, exterior or washdown work, go to a stainless self-drilling screw in the same #10 x 1-1/2 size instead. Indoors, the zinc suits electrical, plumbing, heating and air conditioning work, which is what the JTEK19P is built for.
8) How are the Metallics JTEK19P screws packaged, and what is the minimum order?
They ship in a jar of 100, and 100 is the order minimum. Plan quantities in jar multiples rather than loose counts when you are buying for a job.
