Metallics JTEK4PV 10 x 1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEK4PV 10 x 1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK4PV
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.23
$0.23
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1/2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • #2 Drill Point
    • Pan Head with Phillips Drive
    • 10 Diameter, 1/2" Length
    • Steel Zinc Material

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Color:
Silver
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
2-Jan
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
2.55 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
61 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK4PV – Frequently Asked Questions

1) Do I need a pilot hole for these #10 x 1/2 in. Metallics drill screws?
No pilot hole. It's a Type BSD self-drilling and tapping screw, so the drill point cuts its own hole and the thread taps it in one pass as long as the steel falls in the 0.035 to 0.110 inch range.
2) Are these Metallics screws acceptable on a Buy American or ARRA funded job?
The JTEK4PV is flagged compliant for both ARRA and Buy American. Country of origin is listed as multiple.
3) What size Phillips bit drives the JTEK4PV screw?
A #2 Phillips bit. The recess is 0.192 inch in diameter with a gaging depth of 0.089 to 0.113 inch, so a worn or oversized bit will cam out before the screw seats.
4) How many screws come in a jar of Metallics JTEK4PV?
They ship in a jar with an order minimum of 500 count, and the jar weighs 2.55 lbs.
5) Will a #10 x 1/2 inch pan head screw sit flush, or does the head stand proud?
The pan head stands proud. Head height runs 0.122 to 0.133 inch and head width 0.357 to 0.373 inch, so it bears on the surface rather than countersinking. If you need a flush face, you want a flat head screw instead.
6) What standards do these #10 self-drilling screws meet?
Threads are built to SAE J78 - 2013 and head dimensions to ASME B18.6.3-2010. Thread is 16 threads per inch UNC, hardness is Rockwell C32-40, and minimum torsional strength is 61 lb-in.
7) Is 1/2 inch long enough to fasten two layers of sheet metal?
Yes, for typical sheet. With a 1/2 inch length and a maximum drilling capacity of 0.110 inch, there is ample thread left past the panel for full engagement on two thin layers. If combined stack exceeds 0.110 inch, step up to a heavier drill point.
8) Can I use the zinc plated JTEK4PV screw outdoors or in a wet area?
Zinc plated steel is a dry, interior-duty finish. It handles indoor electrical work, enclosures, and strut fine, but for exterior exposure, washdown, or coastal air you want stainless rather than steel zinc.
