Metallics JTEK20P 10 x 2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

Metallics JTEK20P 10 x 2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK20P
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.39
$0.39
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 2 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • Pan Head with Phillips Drive
    • #2 Drill Point
    • 10 Diameter, 2" Length
    • Steel Zinc Material

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
2
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
3.6 in
Product Length:
3 in
Product Weight:
1.23 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Torsional Strength:
61 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK20P – Frequently Asked Questions

1) What metal thickness can a #10 x 2 in. self-drilling screw with a #2 drill point actually drill through?
The Metallics JTEK20P is rated for panel thickness of 0.035 to 0.110 in. That covers roughly 20 gauge up through 12 gauge steel. Go thicker than 0.110 in. and the #2 drill point will burn before it cuts through, so a heavier drill point size is needed for structural steel.
2) Do I need a pilot hole for the Metallics JTEK20P screws?
No pilot hole. These are Type BSD self-drilling and tapping screws, so the drill point cuts its own hole and the thread taps it in one pass within the 0.035 to 0.110 in. panel range. One driver, no changing bits.
3) What standards do these #10 self-drilling screws meet, and are they Buy American compliant?
Dimensions follow ASME B18.6.3-2010 and the thread conforms to SAE J78-2013, with torsional strength of 61 lb-in minimum and case hardness of Rockwell C32-40. They are not Buy American compliant and not ARRA compliant, with country of origin listed as multiple. On federally funded work with domestic sourcing requirements, these will not qualify.
4) What driver bit do I need for the JTEK20P screws?
A #2 Phillips bit. The recess is a Phillips drive with a 0.192 in. recess diameter and a gaging depth of 0.089 to 0.113 in., so a worn or oversized bit will cam out. Keep fresh #2 bits in the gun on long runs at 2 in. length.
5) How many screws come in a jar and can I buy fewer than that?
These ship as a jar of 100, which is also the order minimum. The jar is the stock pack, so 100 pieces is the smallest quantity.
6) Will a pan head sit flush, or does it stand above the surface?
Pan head, so it stands proud of the panel. Head height runs 0.122 to 0.133 in. with a head width of 0.357 to 0.373 in. If you need the fastener flush with the sheet or inside a channel where clearance is tight, a flush or wafer head is the better choice; this one gives you a broad bearing surface instead.
7) Are these Metallics self-drilling screws OK for outdoor or damp locations?
The JTEK20P is steel with a zinc finish, which is a general indoor and dry-location plating. For wet exterior work, continuous damp, or anywhere chlorides are present, specify a stainless self-drilling screw instead; zinc plating will eventually rust through in those conditions.
8) What trades use these JTEK self-drilling screws on the job?
Metallics lists them for the electrical, plumbing, heating and air conditioning industries: mounting boxes and straps to sheet metal, hanging duct accessories, fixing bracketry to light-gauge steel. Anywhere a sheet-metal fastener goes in without pre-drilling.
9) How much does a jar of 100 of these screws weigh for shipping?
A jar of 100 of the JTEK20P comes to 1.23 lbs.
