Metallics JTEK7PV 10 x 1 in. P...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.29
$0.29
Metallics JTEK7PV 10 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

Metallics JTEK7PV 10 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTEK7PV
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.29
$0.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1 in. Pan Head Phillips Self-Drilling & Tapping Screws - #2 Drill Point - Steel Zinc - 500qty

  • Additional Notes

    • Other sizes and quantities available by request | SAE J78 does not include Specifications for #7 diameter drill screws. | This table is only a guide and does not constitute a warranty of any type.

  • Features

    • #2 Drill Point
    • Steel Zinc Material
    • 10 Diameter, 1" Length
    • Pan Head with Phillips Drive

Manufacturer Resources

Product Specs

Minimum Purchase:
500 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2010
Division:
Electrical H1
Drill Point Size:
#2
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Color:
Silver
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
1
Hardness:
Rockwell C32-40
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Hd_Phil_Self-Drill_TS_Steel_and_SS.pdf
Order Minimum Imperial:
500
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Panel Thickness:
0.035 - 0.110 IN
Phillips Recess Diameter:
0.192
Product Group:
Fasteners
Product Height:
3.6 in
Product Length:
3 in
Product Weight:
3.75 lbs
Product Width:
3 in
Recess Penetration Gaging Depth:
0.089 - 0.113
Screw Point Type:
Drill Point
Sub Division:
Electrical-E H2
Thread Per Inch:
16
Thread Standard:
SAE J78 - 2013
Thread Type:
UNC
Torsional Strength:
61 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type BSD Self-Drilling & Tapping Screw
Type2:
Type BSD Self-Drilling & Tapping Screw
Series:
JTEK
Product Finish:
Zinc
Product Details:
Type BSD Self-Drilling & Tapping Screw
Product Material:
Steel Zinc

Metallics JTEK7PV – Frequently Asked Questions

1) Will a #10 x 1 in. self-drilling screw work for mounting conduit straps and device boxes to metal studs?
Yes, that is the normal use for this screw. The JTEK7PV is a #10 diameter, 1 inch long Type BSD self-drilling and tapping screw with a #2 drill point, so it drills its own hole in metal studs and sheet steel in the 0.035 to 0.110 inch range without a pilot hole. The pan head gives a flat bearing surface for straps, clips and box ears.
2) Are these Metallics screws acceptable on a Buy American or ARRA-funded job?
The JTEK7PV is flagged compliant for both Buy American and ARRA. Country of origin is listed as multiple.
3) What driver bit do I need for the Metallics JTEK7PV screws?
A #2 Phillips bit. The recess is a Phillips drive with a 0.192 inch recess diameter and a gaging depth of 0.089 to 0.113 inch, so a worn or undersized bit will cam out. Keep fresh #2 bits on the gun when you are driving a jar of 500.
4) How is the JTEK7PV packaged and what is the minimum I can order?
These #10 x 1 in. self-drilling screws ship in a jar, with an order minimum of 500 count. Package weight is listed at 3.75 lbs.
5) What specs does the #10 Metallics self-drilling screw meet, and how hard is it?
Head dimensions follow ASME B18.6.3-2010 and the thread follows SAE J78-2013. Case hardness runs Rockwell C32-40 with a minimum torsional strength of 61 lb-in, which is what lets the point cut steel without snapping the shank. Note that SAE J78 does not cover #7 diameter drill screws, so that size is outside the standard.
6) How much clearance does the pan head take up, and will it sit flush?
A pan head stands proud, it does not sit flush. On the JTEK7PV the head measures 0.357 to 0.373 inch across with a head height of 0.122 to 0.133 inch. If you need a flush surface, use a flat or wafer head screw instead; the pan head here is meant to clamp straps, plates and brackets against the panel.
7) Are these screws coated for corrosion, and can I use them outdoors?
The JTEK7PV is steel with a zinc finish and a silver head, which is a general indoor and protected-location plating. Zinc-plated carbon steel is not a stainless substitute, so for sustained wet, coastal or exterior exposure specify a stainless self-drilling screw instead.
8) What is the thread pitch on the Metallics #10 x 1 in. drill screw, and can I run it into a tapped hole?
Thread is 16 threads per inch, UNC machine screw thread. That means it will thread into an existing 10-24 tapped hole only if the hole is 10-16, not 10-24, so match the pitch before reusing a factory-tapped box. In fresh sheet steel the screw taps its own 16 TPI thread as it drills.
