Metallics JTSP29 10 x 1-1/4 in...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.19
$0.19
Metallics JTSP29 10 x 1-1/4 in. Pan Head Phillips Sharp Point Tapping Screws - Steel Zinc - 100qty

Metallics JTSP29 10 x 1-1/4 in. Pan Head Phillips Sharp Point Tapping Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTSP29
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.19
$0.19
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1-1/4 in. Pan Head Phillips Sharp Point Tapping Screws - Steel Zinc - 100qty

  • Features

    • Pan head with Phillips Drive
    • 10 Diameter, 1-1/4" Length
    • Steel Zinc Material

  • Additional Notes

    • Other sizes and quantities available by request | Dimensions for #9 diameter are independent of ASME B18.6.4

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
C
Buy American Compliant:
C
Dimensional Standard:
ASME B18.6.3-2013
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#2
Fastener Head Height:
0.122 - 0.133 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.357 - 0.373 in.
Fastener Length:
1/1/04
Hardness:
Rockwell C28 - 38
Language Code:
EN
Material Standard:
AISI 1016 - 1024
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Slot-Phil-Combo_Self_Tap.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
CT
Pack Type:
Jar
Phillips Recess Depth:
0.124
Phillips Recess Diameter:
0.186 - 0.199
Phillips Recess Width:
0.031
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
0.93 lbs
Product Width:
3 in
Screw Point Type:
Gimlet Point
Sub Division:
Electrical-E H2
Thread Per Inch:
12
Thread Standard:
ASME B18.6.4
Torsional Strength:
48 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type A Tapping Screw
Type2:
Type A Tapping Screw
Series:
JTSP
Product Finish:
Zinc
Product Details:
Type A Tapping Screw
Product Material:
Steel Zinc

Metallics JTSP29 – Frequently Asked Questions

1) What kind of screw is the Metallics JTSP29, and what is it meant to fasten into?
The JTSP29 is a Type A tapping screw, #10 diameter by 1-1/4 inch long, with a gimlet (sharp) point. Type A threads are the coarse, widely spaced sheet metal thread, and the sharp point lets it start in thin sheet steel, electrical boxes, metal studs and similar light-gauge material without a pre-tapped hole. It cuts its own thread as it drives.
2) How much clearance does the pan head on a #10 tapping screw need?
Plan for a head about 0.357 to 0.373 inch in diameter standing 0.122 to 0.133 inch proud of the surface. That matters when the screw lands under a cover plate, a device yoke, or anything that has to sit flat against the material. The pan profile is not countersunk, so the full head height stays above the work.
3) What size Phillips bit drives the Metallics JTSP29 pan head screws?
A #2 Phillips bit. The recess measures 0.186 to 0.199 inch across with a 0.124 inch depth, which is the standard #2 pocket, so a worn or undersized bit is the usual cause of cam-out on these.
4) How many threads per inch does the #10 Type A tapping screw have, and will it hold in thin sheet metal?
12 threads per inch, which is the coarse Type A pitch. Coarse, deep threads are what give sheet metal screws their bite in thin material, where a machine thread would strip out. With 1-1/4 inch of length you get plenty of reach through a box plus the substrate behind it.
5) Will these screws snap when driven with an impact driver?
Torsional strength is rated at 48 lb-in minimum, with the body case hardened to Rockwell C28 to 38 from AISI 1016 to 1024 steel. That is enough for normal gun driving into light-gauge steel, but an impact driver set on full will exceed 48 lb-in once the head seats. Back the clutch off and stop when the head is flush.
6) Are the Metallics JTSP29 screws okay for outdoor or damp locations?
These are carbon steel with a zinc plating, which is a mild indoor corrosion coating. Fine for dry interior work, panel and box work, and concealed locations. For exterior, wet, or coastal exposure, go to a stainless or hot dip galvanized fastener instead; plated zinc will rust through in that service.
7) Do these Metallics tapping screws meet a dimensional spec for a submittal?
The head and recess geometry conform to ASME B18.6.3-2013 and the threads to ASME B18.6.4. The product is flagged ARRA compliant and Buy American compliant in the manufacturer data, with country of origin China. If your project carries a domestic-content requirement, that origin is the line to check against your contract language.
8) How are these #10 x 1-1/4 tapping screws packaged, and what is the minimum order?
They ship in a jar of 100, and 100 count is the order minimum. The packed jar runs 0.93 lbs, so it is an easy item to stock several of on a service van.
