Metallics JFWP29SS 10 x 1 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

Metallics JFWP29SS 10 x 1 in. Flat Head Phillips Wood Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JFWP29SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$192.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

  • Features

    • Stainless wood screws are usually supplied without additional finish
    • Screws of nominal lengths too short to accomodate the minimum thread length shall have threads extending as close to the underside of the head as practicable.
    • 18-8 Stainless Material
    • 10 Diameter, 1" Length
    • Flat Head with Phillips Drive

  • Additional Notes

    • Other sizes and quantities available by request | Length of Thread: Length = 1 inch then 2/3 thread

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.1
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#3
Fastener Head Height:
0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.34 - 0.385 in.
Fastener Length:
1
Field Application:
Electrical, Plumbing, Heating, Air Conditioning Industries
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Wood_Screw_Steel_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.123 - 0.146
Phillips Recess Diameter:
0.245 - 0.258
Phillips Recess Width:
0.034
Product Group:
Fasteners
Product Height:
2.15 in
Product Length:
3 in
Product Weight:
0.67 lbs
Product Width:
3 in
Screw Point Type:
Tapered Point
Sub Division:
Electrical-E H2
Thread Per Inch:
13
Thread Standard:
ASME B18.6.1-1997
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Wood Screw
Type2:
Wood Screw
Series:
JFWP
Product Finish:
Zinc
Product Details:
Wood Screw
Product Material:
18-8 Stainless

Metallics JFWP29SS – Frequently Asked Questions

1) What size driver bit do I need for the Metallics JFWP29SS wood screws?
A #3 Phillips driver. The recess on these #10 screws runs 0.245 to 0.258 inch in diameter and 0.123 to 0.146 inch deep, which is larger than a #2 bit seats properly in. Using a #2 will cam out and chew the recess.
2) Are the Metallics JFWP29SS screws stainless all the way through, or just plated?
Solid 18-8 stainless, not a plated carbon steel screw. Stainless wood screws are normally supplied with no additional finish on top of the base material, so the corrosion resistance goes right through the fastener rather than sitting on the surface. That makes them suitable for damp or exterior-adjacent work where a plated screw would rust out.
3) Can I use these screws on a Buy American or ARRA-funded job?
No. The JFWP29SS stainless wood screws are not Buy American compliant and are not ARRA compliant, with multiple countries of origin. For federally funded work carrying domestic-sourcing requirements you will need a domestically produced fastener instead.
4) Will a #10 flat head screw sit flush in a countersunk hole in a device plate or strap?
Yes, if the countersink matches. The flat head on the JFWP29SS measures 0.34 to 0.385 inch across with a head height of 0.116 inch, so a standard 82 degree countersink sized for a #10 flat head screw will bring it flush or slightly below the surface. In a punched hole without a countersink the head will stand proud by about 0.116 inch.
5) How are the Metallics JFWP29SS wood screws packaged and what is the minimum I can buy?
They come in a jar, 100 screws to the jar, and 100 is the order minimum. The jar weighs 0.67 lbs. If you need a different size or a bulk count, other sizes and quantities are available by request.
6) Do these Metallics wood screws meet a published dimensional standard for spec work?
Yes. The JFWP29SS is built to ASME B18.6.1 for dimensions, with threads to ASME B18.6.1-1997. If a drawing calls out a #10 flat head Phillips wood screw to B18.6.1, this one answers the callout.
7) Do I need to drill a pilot hole for these screws, or will they self-start?
The JFWP29SS has a tapered point, not a self-drilling or type-17 point, so it starts in softwood on its own but wants a pilot hole in hardwood or near an edge. Stainless is softer than hardened carbon steel and will twist off if you overdrive it dry, so pilot the harder species and keep the drill speed down.
8) What are #10 x 1 inch stainless wood screws typically used for on an electrical or mechanical job?
They are stocked for the electrical, plumbing, heating and air conditioning trades: fastening boxes, straps, clamps, mounting boards and small brackets into wood framing or blocking. The 18-8 stainless makes them the choice over a zinc-plated screw in wet locations, coastal exposure, mechanical rooms, or anywhere treated lumber is involved.
