Metallics JFWP31SS 10 x 1-1/2 ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$192.86
Metallics JFWP31SS 10 x 1-1/2 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

Metallics JFWP31SS 10 x 1-1/2 in. Flat Head Phillips Wood Screws - 18-8 Stainless - Each

(No reviews yet) Write a Review

Model: JFWP31SS
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$192.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
10 x 1-1/2 in. Flat Head Phillips Wood Screws - 18-8 Stainless - 100qty

  • Additional Notes

    • Other sizes and quantities available by request | Length of Thread: Length = 1 inch then 2/3 thread

  • Features

    • Screws of nominal lengths too short to accomodate the minimum thread length shall have threads extending as close to the underside of the head as practicable.
    • Flat Head with Phillips Drive
    • 10 Diameter, 1-1/2" Length
    • Stainless wood screws are usually supplied without additional finish
    • 18-8 Stainless Material

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.1
Division:
Electrical H1
Drive Type:
Phillips
Driver Size:
#3
Fastener Head Height:
0.116 in.
Fastener Head Type:
Flat
Fastener Head Width:
0.34 - 0.385 in.
Fastener Length:
1/1/02
Field Application:
Electrical, Plumbing, Heating, Air Conditioning Industries
Language Code:
EN
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Flat_Head_Wood_Screw_Steel_SS.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Phillips Recess Depth:
0.123 - 0.146
Phillips Recess Diameter:
0.245 - 0.258
Phillips Recess Width:
0.034
Product Group:
Fasteners
Product Height:
2.7 in
Product Length:
3 in
Product Weight:
1.042 lbs
Product Width:
3 in
Screw Point Type:
Tapered Point
Sub Division:
Electrical-E H2
Thread Per Inch:
13
Thread Standard:
ASME B18.6.1-1997
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Wood Screw
Type2:
Wood Screw
Series:
JFWP
Product Details:
Wood Screw
Product Material:
18-8 Stainless

Metallics JFWP31SS – Frequently Asked Questions

1) How many screws come in a jar of Metallics JFWP31SS wood screws?
The JFWP31SS ships as a jar of 100, and 100 in a jar is the order minimum. Jar weight is 1.042 lbs.
2) What size Phillips driver do I need for a #10 Metallics flat head wood screw?
A #3 Phillips bit. The recess on the JFWP31SS runs 0.245 to 0.258 in. diameter with a depth of 0.123 to 0.146 in., so a #2 bit will sit shallow and cam out when you drive these into hardwood.
3) Are these stainless screws OK for outdoor or damp locations like exterior device boxes and strut?
They are 18-8 stainless, the common austenitic grade used where plain steel or zinc would rust, so exterior trim, damp mechanical rooms, and coastal-adjacent work are all reasonable. They come with no additional finish or plating, which is normal for stainless. One caution: stainless fasteners in direct contact with aluminum or galvanized steel in a wet location can set up galvanic corrosion, so isolate where that applies.
4) Can I use these on a Buy American or ARRA-funded job?
No. The JFWP31SS is not Buy American compliant and is not ARRA compliant, and country of origin is listed as multiple. For federally funded work with domestic sourcing requirements you need a fastener qualified for it.
5) What standard are Metallics JFWP wood screws made to?
Dimensions and threads follow ASME B18.6.1, the thread callout specifically ASME B18.6.1-1997. That is the wood screw standard, so head, recess, and thread geometry are interchangeable with any other B18.6.1 #10 flat head Phillips.
6) What are #10 x 1-1/2 in. stainless flat head wood screws typically used for on an electrical or mechanical job?
These are the general-purpose fastener for mounting into wood framing and plywood backing: device boxes, straps and clamps, panel backboards, equipment brackets, hangers. Metallics lists the application as electrical, plumbing, heating, and air conditioning work. At 1-1/2 in. there's enough length to pass through sheathing or a plate and still get solid bite into a stud.
7) Is JFWP31SS the right part number if I need a different length or a bulk count?
JFWP31SS is specifically the #10 by 1-1/2 in. 18-8 stainless flat head Phillips in the JFWP series. Other sizes and quantities within the series are available by request, so if you need a shorter screw for thin trim or a larger count for a repetitive install, specify the diameter, length, and quantity rather than ordering multiple jars of this one.
