Metallics JTSS36 12 x 1-1/2 in...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$50.40
$0.40
Metallics JTSS36 12 x 1-1/2 in. Pan Head Square Drive Tapping Screws - Steel Zinc - 100qty

Metallics JTSS36 12 x 1-1/2 in. Pan Head Square Drive Tapping Screws - Steel Zinc - Each

(No reviews yet) Write a Review

Model: JTSS36
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$50.40
$0.40
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
12 x 1-1/2 in. Pan Head Square Drive Tapping Screws - Steel Zinc - 100qty

  • Features

    • Pan head with square Drive
    • 12 Diameter, 1-1/2" Length
    • Steel Zinc Material

  • Additional Notes

    • Other sizes and quantities available by request | This type of recess has a square center opening, slightly tapered side walls and a conical bottom. | Dimensions for #9 diameter are independent of ASME B18.6.4

Manufacturer Resources

Product Specs

Minimum Purchase:
100 units
Arra Compliant:
N
Buy American Compliant:
No
Dimensional Standard:
ASME B18.6.3-2013
Division:
Electrical H1
Drive Type:
Square
Driver Size:
3R
Fastener Head Height:
0.139 - 0.151 in.
Fastener Head Type:
Pan
Fastener Head Width:
0.407 - 0.425 in.
Fastener Length:
1/1/02
Field Application:
Electrical, Plumbing, Heating and Air Conditioning Industries
Hardness:
Rockwell C28-38
Language Code:
EN
Material Standard:
AISI 1016 - 1024
Neurspe:
https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Pan_Square_Drive_Self_Tap.pdf
Order Minimum Imperial:
100
Order Minimum Uom Imperial:
JR
Pack Type:
Jar
Product Group:
Fasteners
Product Height:
3.6 in
Product Length:
3 in
Product Weight:
1.38 lbs
Product Width:
3 in
Recess Across Flats:
0.133
Recess Penetration Gaging Depth:
0.080 - 0.095
Screw Point Type:
Gimlet Point
Sub Division:
Electrical-E H2
Thread Per Inch:
11
Thread Standard:
ASME B18.6.4
Torsional Strength:
83 lb-in minimum
Department:
Electrical
Product Subgroup:
Screws
Product Type:
Type A Tapping Screw
Type2:
Type A Tapping Screw
Series:
JTSS
Product Finish:
Zinc
Product Details:
Type A Tapping Screw
Product Material:
Steel Zinc

Metallics JTSS36 – Frequently Asked Questions

1) What driver bit do I need for the Metallics JTSS36 square drive tapping screws?
Use a #3 square (Robertson) bit. The JTSS36 is specified with a square drive and a 3R driver size. The recess measures 0.133 across the flats with a gaging depth of 0.080 to 0.095 inch, so a worn or undersized bit will cam out and chew the recess.
2) Is a Type A tapping screw the right choice for sheet metal, or do I need a self-drilling screw?
A Type A tapping screw like the JTSS36 forms its own thread but does not drill its own hole. The gimlet point starts in thin sheet metal and soft materials, but you still need a pilot hole in heavier gauge stock. If you want to skip the pilot hole entirely in steel, you want a self-drilling (Type TEK) screw instead.
3) Do these Metallics screws meet Buy American requirements for a federal job?
No. The JTSS36 is not Buy American compliant and not ARRA compliant, with multiple countries of origin. If your project has domestic-sourcing language in the spec, you will need a documented domestic fastener instead.
4) What size and thread does the Metallics JTSS36 screw have?
It is a #12 diameter screw, 1-1/2 inches long, with 11 threads per inch on the Type A thread form. Threads are made to ASME B18.6.4 and head dimensions to ASME B18.6.3-2013, so it interchanges with any other #12 x 1-1/2 Type A pan head from a spec-compliant source.
5) How much room does the pan head take up, and will it sit flat against a panel?
The pan head runs 0.407 to 0.425 inch across and 0.139 to 0.151 inch high. A pan head bears on the surface rather than countersinking, so it sits proud by about an eighth of an inch and needs a flat, unrecessed landing. If you need the head flush, a flat head screw and a countersunk hole are what you want.
6) Are these Metallics tapping screws tough enough to drive without snapping heads?
They are heat treated to Rockwell C28-38 with a minimum torsional strength of 83 lb-in, made from AISI 1016-1024 steel. That is the standard duty range for Type A tapping screws. Drive them with a clutch or torque-limiting driver rather than an impact gun and you will not twist heads off.
7) Can I use zinc plated tapping screws outdoors or in a damp mechanical room?
The JTSS36 is zinc plated steel, which handles indoor and dry mechanical spaces fine but is not a marine or sustained-wet finish. For rooftop units, exterior walls, or washdown areas, step up to stainless or a hot dip galvanized fastener.
8) How do the Metallics JTSS36 screws come packaged and what is the minimum order?
They ship in a jar of 100, which is the order minimum. The jar weighs 1.38 lbs. Handy for a truck stock bin rather than a loose-count bag.
9) What trades actually use these pan head square drive tapping screws?
Metallics lists the JTSS36 for electrical, plumbing, heating and air conditioning work. Typical uses are fastening to sheet metal enclosures, duct, strut accessories and panel work where a square drive keeps the bit from camming out overhead.
