2 1/2inch RIGID T CONDUIT BODY
Manufacturer Resources
Product Specs
- Application:
- For Use with Rigid/IMC Conduit
- Number Of Batteries:
- 0
- Product Group:
- Conduit & Fittings
- Product Type:
- Conduit Body - Series A - Rigid/IMC
- Department:
- Electrical
- Product Subgroup:
- Conduit Bodies
- Product Material:
- Aluminum Die Cast
Red Dot AT-7 – Frequently Asked Questions
1) Will the Red Dot AT-7 work with EMT, or is it rigid conduit only?
Rigid and IMC only. The AT-7 is a Series A conduit body built for threaded rigid metal conduit and intermediate metal conduit, so the hubs are threaded, not set-screw or compression. If your run is EMT, you need an EMT-style body or a threaded adapter at each hub.
2) What size conduit does the Red Dot AT-7 T conduit body take?
It's a 2-1/2 inch body, so all three openings are threaded for 2-1/2 inch rigid or IMC conduit. That's a large trade size, typically feeder or service work rather than branch circuits.
3) Is the Red Dot AT-7 aluminum or malleable iron?
Die cast aluminum. That matters in two places: weight on a large 2-1/2 inch body hanging off a conduit run, and dissimilar metal contact. Aluminum bodies are commonly used with galvanized rigid, but in corrosive or chemical environments many specs call for malleable iron or a PVC-coated body instead.
4) Does the Red Dot AT-7 come with a cover and gasket?
The AT-7 is the conduit body itself. Covers for Series A bodies are ordered separately and sized to the body, so for a 2-1/2 inch T you need the matching 2-1/2 inch Series A cover, plus a gasket if the location calls for a wet-location seal.
5) Can I use the AT-7 as a pull point for large feeder conductors?
That's the normal use for it. A 2-1/2 inch T body gives you access at a branch or direction change so conductors can be pulled rather than fished through a long threaded run. Conductor fill and bending space still have to be worked out to code for the wire you're pulling; the body only gives you the access.
6) What part number do I order for a 2-1/2 inch Red Dot T body?
AT-7 is the Red Dot manufacturer part number for the 2-1/2 inch rigid/IMC Series A T conduit body in die cast aluminum.
