26625 Viega MegaPress tee Smart Connect technology Carbon steel, 2-1/2" x 2-1/2" x 3/4"
Manufacturer Resources
Product Specs
- Connection Type:
- P1 x P2 x FPT
- Material Type:
- Carbon Steel
- Product Dimension:
- 2-1/2" x 2-1/2" x 3/4"
- Department:
- Plumbing
- Product Group:
- Plumbing Fittings
- Product Subgroup:
- Tees
- Product Type:
- Tee
- Product Length:
- 6.299"
- Product Height:
- 3.543"
- Product Weight:
- 2.44 lbs
- Product Width:
- 4.331"
- Product Material:
- Carbon steel
Viega 26625 – Frequently Asked Questions
1) What are the three connections on the Viega MegaPress 26625 tee?
The 26625 MegaPress tee is a 2-1/2 inch x 2-1/2 inch x 3/4 inch reducing tee with a P1 x P2 x FPT configuration: the two 2-1/2 inch run ends are press connections, and the 3/4 inch branch is female pipe thread. So you press the run onto 2-1/2 inch carbon steel pipe and thread the branch outlet.
2) Do I need a threaded reducer for a 3/4 inch branch takeoff on 2-1/2 inch steel pipe?
Not with this fitting. The 26625 tee already reduces to a 3/4 inch FPT branch straight off a 2-1/2 inch pressed run, so you can thread a 3/4 inch nipple, valve, drop, or gauge assembly directly into the outlet. No bushing or separate reducing coupling needed on the branch.
3) Can I use the Viega 26625 MegaPress tee on black iron pipe for gas or does it only work on water lines?
The 26625 is a carbon steel MegaPress fitting, which is the Viega press line made for black iron and carbon steel pipe rather than copper. Material is carbon steel through the body. For the service it is approved on, follow the Viega MegaPress approval listing for the seal element you are installing, since that is what determines gas versus water use, not the fitting size.
4) How much clearance do I need around the pipe to install a 2-1/2 inch MegaPress tee?
The fitting body itself measures 6.299 inches long, 4.331 inches wide and 3.543 inches high, so plan your pocket around that plus room for the press jaw or ring and actuator. In a tight joist bay or against a wall, the 4.331 inch width is usually the dimension that decides whether the tool can seat square on the fitting.
5) What does Smart Connect mean on a Viega MegaPress fitting?
Smart Connect is Viega's unpressed-joint feature: the sealing element is shaped so an unpressed fitting weeps visibly during pressure testing instead of holding tight and failing later. On a 2-1/2 inch run like the 26625 that matters, because large-diameter presses are the ones most likely to get missed on a long rack.
